HAWS AG • Bachweg 3 • CH-3401 Burgdorf • Switzerland • www.haws.ch
HAWS Corporation • P.O.Box 2070 • 1455 Kleppe Lane • Sparks,Nevada 89431/USA www.hawsco.com
Model
8901RFK Axion
NOTE TO INSTALLER: please leave this information with the maintenance departement.
105
SCALE 1:10
Free acces to the eye/facewash & body spray 8901RFK Axion must be guaranteed at all times.
The operator is responsible for the observance of this requirement.
Jeannine Ruf
HAWS DRINKING FAUCET COMPANY
INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS
81
1 1/4" G
Supply
2,4m
THESE DIMENSIONS MAY VARY +/- 12,7mm (1/2")
8901RFK Axion
Eye/Face Wash & Body Spray
28
•
86
No.
2080192/1
TÜV tested
1/5
28.10.2011
Advertisement
Related Manuals for Haws 8901RFK Axion
Summary of Contents for Haws 8901RFK Axion
- Page 1 TÜV tested THESE DIMENSIONS MAY VARY +/- 12,7mm (1/2") SCALE 1:10 Free acces to the eye/facewash & body spray 8901RFK Axion must be guaranteed at all times. The operator is responsible for the observance of this requirement. 8901RFK Axion Jeannine Ruf...
- Page 2 Eye/Face Wash & Body Spray 2080192/1 Shower location: The eye/facewash & body spray 8901RFK Axion must be installed in the vicinity of potential danger zones. It must be highly visible and easily accessible. Connection conduit: You are recommended to use a 1/2" G conduit, capable of withstanding pressures of 2 - 6BAR (30 - 90PSI).
