Model
8901B Axion
NOTE TO INSTALLER: please leave this information with the maintenance departement.
THESE DIMENSIONS MAY VARY +/- 12,7mm (1/2")
SCALE 1:18
Free acces to the eye/facewash & body spray 8901B Axion must be guaranteed at all times.
The operator is responsible for the observance of this requirement.
Jeannine Ruf
HAWS DRINKING FAUCET COMPANY
INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS
Eye/Face Wash and Body Spray
85
81
1/2" G
Supply
8901B Axion
•
No.
57
2.4m
TÜV tested
12.10.2011
2080191/3
1/4
