CHARACTERISTICS:

The HD67D19-B2 is a LoRaWAN / CAN Converter.
It allows the following characteristics:
Electrical isolation between CAN and Power Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 12...35V DC and 8...24V AC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67D19 software on your PC in order to perform the following:
Define the parameter of LoRaWAN line;
Define the parameter of CAN line;
Define the list of LoRaWAN messages in uplink and downlink to the LoRaWAN gateway;
Define the list of CAN messages in transmission and reception;
Update the device.
