ETHERNET/IP ACCESS:

By Pressing the "EtherNet/IP
appears (Fig. 5).
This section is used to define the list of the EtherNet/IP Slave to read/write with the OPC UA Client.
Figure 5: "Set EtherNet/IP Slave Access" window
The means of the fields are:
If the field "Enable" is checked, the polling to the EtherNet/IP Slave is enabled;
In the field "IP Address" the IP Address of the EtherNet/IP Slave is defined;
In the field "Start Input" the starting Input byte of the EtherNet/IP Slave to map on OPC UA side is defined;
In the field "Num Input" the number of consecutive Input byte to map on OPC UA side is defined;
In the field "Start Output" the starting Output byte of the EtherNet/IP Slave to write from OPC UA side is defined;
In the field "Num Output" the number of consecutive Output byte to write from OPC UA side is defined;
In the field "Time Poll" the polling time in ms is defined;
In the field "Instance T >
In the field "Conn. Point T >
In the field "Instance O >
In the field "Conn. Point O >
In the field "Dim Header T >
In the field "Dim Header O >
In the field "Mnemonic" a brief description is defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Access" button from the main window for SW67B38 (Fig. 2) the window "Set EtherNet/IP Master Access"
O" the instance of the assembly for the Target to Originator data direction is defined;
O" the connection point of the assembly for the Target to Originator data direction is defined;
T" the instance of the assembly for the Originator to Target data direction is defined;
T" the connection point of the assembly for the Originator to Target data direction is defined;
O" the dimension of the header for the Target to Originator data direction is defined;
T" the dimension of the header for the Originator to Target data direction is defined;
