D 10-32 cage nut (4x)
I Flat washer (4x)
H 10-32 pan head
screw (4x)
F R O N
T
A M4 Screw for
7.1 mm hole (4x)
Lyve Mobile Rackmount Receiver
CAUTION
TWO-PERSON
LIFT REQUIRED
Receiver weight (empty): 47.52 lb/21.6 kg
Do not attempt to lift or assemble
Lyve Mobile Rackmount Receiver
with compatible devices inserted.
G M4 flat pan
head screw (4x)
Front rail left
B M4 Screw for
0.375" hole (4x)
Removing Lyve Mobile Rackmount Receiver from its packaging
and carrying the unit must be performed by at least two people.
F Stepped washer (8x)
Back rails (2x)
Front rail right
E 10-32 flat head screw (8x)
B A C K
C M4 nut (X4)
