- Page 1 TITAN II APPLIANCE CART FOLD DOWN REAR WHEELS WITH INSTRUCTION MANUAL 67106-75 Revised: JULY 2017...
- Page 2 Granite Industries. Any defective products that meet warranty specifications and Granite Industries approval, may be returned to the factory to be repaired or replaced free of charge. (Granite Industries will pay to ship replacement item(s) to the customer; however the customer is responsible for shipment of products to the factory.) This remedy...
- Page 3 SPECS 17 1/2" 60" 26" 4 15/16" 15 3/4" Default/ ITEM NO. PART NUMBER DESCRIPTION QTY. 67101-75 24"X60" APPLIANCE CART MADE IN USA MI-12-2081 CART 67106 MI-04-0068 BAR RD HR 3/8" x 8" PI-14-0001 G-PIN SPRING PI-01-0004 PIN-ROLL 3/16" x 1" Overall Dimensions: 26”...
- Page 4 PARTS DIAGRAM ITEM NO PART NO DESCRIPTION 67101 CART 67101 MI-12-2081 WELDMENT FOLD OUT WHEELS MI-04-0068 BAR RD HR 3/8” x 8” PI-14-0001 G-PIN SPRING PI-01-0004 PIN-ROLL 3/16” x 1” PI-04-0104 1” Square Tube Cap - black MI-04-0493 BAR RD CR 1/2” x 18 1/2” PI-01-0002 WASHER-USS FLAT 1/2”...
- Page 5 REAR WHEEL SETUP Pull the spring loaded lock down located on the back of the cart that holds the support Swing the support bar downwards. bar in place. Pull the locking pin back on the support Lift up on the rear wheel assembly. bar, and secure it onto the lower axle of the cart.
- Page 6 TIE STRAP SETUP Lift the center roller. Slide the strap under the center roller. Lower the center roller and insert the strap Your strap should now lock in place when back through, this time going above the tightened. roller.
- Page 7 NOTES:...
