Summary of Contents for Granite American Cart & Rack 67283
- Page 1 CHURCH CHAIR CART INSTRUCTION MANUAL 67283 Revised: JULY 2017...
- Page 2 Granite Industries. Any defective products that meet warranty specifications and Granite Industries approval, may be returned to the factory to be repaired or replaced free of charge. (Granite Industries will pay to ship replacement item(s) to the customer; however the customer is responsible for shipment of products to the factory.) This remedy...
- Page 3 SPECS Overall Dimensions: 25” 53” 61” Overall Dimensions:* 25” 54” 50” Weight: 53 lbs. Capacity: 500 lbs. *Measurements taken on 4 wheels...
- Page 4 PARTS DIAGRAM ITEM NO PART NO DESCRIPTION PI-06-0124 10” Plastic Hub Flat Free Offset Tire MI-12-4751 Cart Chassis MI-12-4752 Rear Caster Mount MI-12-4753 Chair Lifting Bar PI-01-0226 1/8” x 1 1/4” Cotter Pin PI-01-0451 3/4” Washer 38057 5” Caster with 1 1/4” Stem PI-06-0044 4”...
- Page 5 STEP 1: REAR WHEEL ASSEMBLY COMPONENTS ITEM NO DESCRIPTION Cart Chassis 5” Caster with 1 1/4” Stem 3/8” Hex Bolt 3/8” Locknut TOOLS 9/16” Wrench 9/16” Socket Position the rear caster mount onto the Secure in place using a 3/8” hex bolt and cart chassis as shown.
- Page 6 STEP 2: FRONT WHEEL ASSEMBLY COMPONENTS ITEM NO DESCRIPTION 10” Plastic Hub Flat Free Tire 1/8” x 1 1/4” Cotter Pin 3/4” Washer TOOLS Needle Nose Pliers Slide the wheel onto the axle, making sure the offset side is facing inwards, toward the Slide a washer onto the axle.
- Page 7 STEP 3: INSTALL LIFTING BAR COMPONENTS ITEM NO DESCRIPTION Chair Lifting Bar Chair Stop Bar 3/8” Hex Bolt 3/8” Locknut TOOLS 9/16” Wrench 9/16” Socket Secure in place using four 3/8” hex bolts Align the chair lifting bar onto the chart and lock nuts.
- Page 8 STEP 4: INSTALL FRONT CASTER COMPONENTS ITEM NO DESCRIPTION 1/2” Washer 1/2” Lock Washer 1/2” Nut TOOLS 3/4” Socket Insert the caster into the mount on the chair Secure into place using a 1/2” nut and a lifter bar, then slide a 1/2” washer and a 1/2” 3/4”...
