- Page 1 TITAN II APPLIANCE CART INSTRUCTION MANUAL 67101-75 Revised: JULY 2017...
- Page 2 Granite Industries. Any defective products that meet warranty specifications and Granite Industries approval, may be returned to the factory to be repaired or replaced free of charge. (Granite Industries will pay to ship replacement item(s) to the customer; however the customer is responsible for shipment of products to the factory.) This remedy...
- Page 3 SPECS Overall Dimensions: 26” 16” 61” Foot Plate: 26” 5” Weight: 70 lbs. Capacity: 600 lbs.
- Page 4 PARTS DIAGRAM ITEM NO PART NO DESCRIPTION MI-12-2009 CART 67101 MI-08-0543 Track for rubber belt MI-15-0015 Bushing - 25/64" ID x 1" MI-04-0121 Crank PI-06-0032 10” Flat free offset wheel PI-11-0016 Strap PI-04-0115 Rubber cap for crank handle PI-01-0002 1/2” Washer PI-01-0073 Cotter Pin - 5/32"...
- Page 5 TIE STRAP SETUP Lift the center roller. Slide the strap under the center roller. Lower the center roller and insert the strap Your strap should now lock in place when back through, this time going above the tightened. roller.
- Page 6 NOTES:...
- Page 7 NOTES:...
- Page 8 GRANITE INDUSTRIES 595 EAST LUGBILL ROAD 877-447-2648 SUPPORT@GRANITEIND.COM...
