Menu Item Description
Link Aggregation Contains tabs that allow you to:
Display link aggregation summary.
■
Create an aggregation group.
■
Modify the port memberships.
■
Remove an aggregation group.
■
Spanning Tree per Contains tabs that allow you to:
Port
Display selected spanning tree
■
information for every port.
Display individual port spanning tree
■
information.
Modify the spanning tree settings for a
■
port.
Port Mirroring Monitor traffic going in and out of ports.
Statistics Display statistics for a selected port.
QoS Configures QoS settings.
VoIP Traffic Setting Contains tabs that allow you to:
Display Voice VLAN summary.
■
Configure Voice VLAN global settings.
■
Configure Voice VLAN port settings.
■
Display port information for Voice VLAN
■
and Trunk details.
Display OUI summary.
■
Add or remove OUI.
■
Security Configures security settings.
Radius Client Contains tabs that allow you to:
Display Radius Client information.
■
Configure Radius Client settings and set
■
authentication parameters.
Navigating the Web Interface
Menu Item Description
802.1X Settings Contains tabs that allow you to:
Display 802.1X information.
■
Display 802.1X detailed information per
■
port.
Configure 802.1X settings.
■
Monitoring Display Switch monitoring information.
Address Table Displays MAC address table information for
ports and VLANs.
Cable Diagnostics Contains tabs that allow you to:
Display selected cable diagnostics
■
information for all ports.
Display all cable diagnostics information
■
per port.
Help Direct link to help pages.

Buttons

Depending on the screen that is currently displayed,
the following buttons may appear:
Apply – Click to save and apply any changes that
■
you have made
Cancel – Click to discard any unsaved changes
■
