Superstack® ii baseline 10/100 switch 12-port (3c16464) and 24-port (3c16465)
Hide thumbs
Table of Contents

Advertisement

Quick Links

I
NTRODUCTION
®
The SuperStack
II Baseline 10/100 Switch is a versatile, easy-to-use
unmanaged switch. It is ideal for users who want the high-speed
performance of 10/100 switching but do not need sophisticated
management capabilities. The Baseline 10/100 Switch is shipped
ready for use. No configuration is necessary.
The Baseline 10/100 Switch has 12 or 24 shielded RJ45, 10/100Mbps
auto-sensing ports on the front panel. Each port automatically senses
the speed and duplex mode of the connected equipment and
provides a suitable switched connection.
The Baseline 10/100 Switch is suited for office use where it can be
free standing, wall mounted, or rack mounted (in a wiring closet or
equipment room).
The Baseline 10/100 Switch comes with:
3
One power cord for use with the Baseline 10/100 Switch
3
Four self-adhesive rubber pads
3
One mounting kit
3
A Warranty Registration card for you to fill in and return
The Switch can be powered either from the AC mains supply, or
through an optional 3Com SuperStack
Power System (3C16070). Contact your supplier for details.
®
SuperStack
II Baseline 10/100 Switch
12-Port (3C16464) and 24-Port (3C16465)

User Guide

®
II Advanced Redundant
DUA1646-4AAA01
The Baseline 10/100 Switch provides high performance switched
connections to 10Mbps and 100Mbps hubs, servers and
workstations that require a dedicated switched link:
