Models
ADPB25PPT/R/P/G
ADPB25PPS/R/P/G
Read this manual carefully before installing, operating or servicing this equipment. It's the responsi-
bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
This document is issued with Product Serial No
Operation and Maintenance Guide
ADPB 25 PPX
Descriptions
Polypropylene with PTFE fitments
Polypropylene with Santoprene fitments
Advertisement
Table of Contents
Related Manuals for Teryair ADPB 25 PPX
Summary of Contents for Teryair ADPB 25 PPX
- Page 1 Operation and Maintenance Guide ADPB 25 PPX Models Descriptions ADPB25PPT/R/P/G Polypropylene with PTFE fitments ADPB25PPS/R/P/G Polypropylene with Santoprene fitments Read this manual carefully before installing, operating or servicing this equipment. It’s the responsi- bility of the employer to ensure this manual is read by the operator. Please preserve this manual.
-
Page 2: Table Of Contents
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 2 Table of Contents Pump Nomenclature Operating and Safety instructions Operating Instructions Suggested site selection and installation recommendations Troubleshooting Maintenance Diassembly and Re-assembly Bill of Materials for ADPB 25 PPTR Pump Bill of Materials for ADPB 25 PPSR Pump Exploded View for ADPB 25 Pumps Dimensional Data... -
Page 3: Pump Nomenclature
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 3 Pump Nomenclature Air Valve Type Pump Size Material of Construction Material of Bolted or Threading on Inlet Diaphragm Clamped and Outlet 06 - 1/4” 12 - 1/2” 15 - 1/2” DP - Classic AL - Aluminium R- NPT... -
Page 4: Operating Instructions
Operating Instructions The Teryair Stroke diaphragm pump generates a alternate stroking of the diaphragms against the fluid in the liquid chambers of the Pump. This reciprocatory action is responsible for the fluid being pumped. -
Page 5: Suggested Site Selection And Installation Recommendations
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 5 Caution: Temperature limitations and diaphragm options Excellent choice when pumping highly aggressive fluids such as aromatic or chlorinated hydrocarbons, PTFE acids, caustics, ketones and acetates. Temperature range +4°C to +104°C (+40°F to +220°F) Suggested Lubricants Brand Above 27 Deg C (... - Page 6 Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 6 Location selection Suction Pump location must be easily accessible with reasonable Ensure that the suction head after installation is well space around for maintenance operations. within the pumps suction capabilities Pump dimensional data for each variant is available in section showing exploded views Muffler...
-
Page 7: Troubleshooting
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 7 Troubleshooting Serial No Description Causes Remedial Action Pump stops and Insufficient Air Pressure Check air pressure is as recommended will not start at the pump air inlet Air Filter Blocked Check if debris has clogged the inlet fil- ter on the FRL unit/pump inlet air valve ( some models have air filter on the air... -
Page 8: Maintenance
Follow the instructions clearly in “Disassembly and Reassembly” of the pump and in the troubleshooting section. Use genuine Teryair spares and if possible mention the serial number of the pump when ordering spares. Always replace elastomers as a set, eg diaphragms, balls and seats. - Page 9 Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 9 Now we can remove the end support Replacement of Primary (32), spacer (8) and orings (31). Examine for Shaft & seals wear and replace the same. Follow the procedure a,b & c of dia- Now assemble in reverse manner as phragm replacement and thereafter we can per exploded view.
-
Page 10: Bill Of Materials For Adpb 25 Pptr Pump
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 10 Bill of Materials for ADPB 25 PPTR Pump Illu Part Illu Part Description Description Number Number Combined Shaft 6129005S Plain Washer 6124019 Housing 6129004S Hex. Nut 6120805 Outer Chamber Side 6129003S Hex Bolt 6123009... -
Page 11: Bill Of Materials For Adpb 25 Ppsr Pump
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 11 Bill of Materials for ADPB 25 PPSR Pump Illu Part Illu Part Description Description Number Number Combined Shaft 6129005S Plain Washer 6124019 Housing 6129004S Hex. Nut 6120805 Outer Chamber Side 6129003S Hex Bolt 6123009... -
Page 12: Exploded View For Adpb 25 Pumps
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 12 Exploded View for ADPB 25 Pumps FF-MM-405-REV - 01... - Page 13 Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 13 Exploded View A & B for ADPB 25 Pumps A- OUTLET ASSEMBLY B- INLET ASSEMBLY FF-MM-405-REV - 01...
-
Page 14: Dimensional Data
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 14 Dimensional Data 1/4" NPT 1" NPT AIR INLET FLUID OUTLET 1/2" BSPP AIR EXAUST 1" NPT FLUID INLET 1" ANSI FLANGE 8.50 198.5 ADPB 25 PPT/S FF-MM-405-REV - 01... -
Page 15: Air Valve Repair Kits For Adpb 25 Pumps
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 15 Air Valve Repair Kits for ADPB 25 Pumps Repair KIT Suitable for Ordering No 612 97 07 ADPB 25 PPT 612 97 07S ADPB 25 PPS Air Valve Replacement Kits for ADPB 25 Pumps Replacement KIT Suitable for Ordering No... -
Page 16: Test Certificate Of Materials, Performance
Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 16 TEST CERTIFICATE OF MATERIALS, PERFORMANCE Date : Model number : Part description & s.No. : We hereby certify that the above referenced product has tested and inspected in accordance with our standard test proce- dures and meets the specifications for material and performance values as published in our literature. -
Page 17: Eu Declaration Of Conformity
Palghar – 401208, Maharashtra, India. CE certification registration no – C E 16832 Issued by – BMQR Certifications Pvt Ltd. www.cemarking-india.com Valid Till – 03/11/2021 Signed for and on behalf of TERYAIR EQUIPMENT PVT. LTD. Place of Issue: Date: FF-MM-405-REV - 01... -
Page 18: Warranty Certificate
Teryair; (vii) the issue with a Product is directly or indirectly attributable to, or directly or indirectly results from or arises out of, compliance with any design, specification or other specific requirement of Dealer/End User;... - Page 19 Operation and Maintenance Guide ADPB 25 Plastic Pump Series Page 19 This page is intentionally Left blank. FF-MM-405-REV - 01...
