- Page 1 Assembly Instructions Model No. BWKSEC207 Blonde Wicker Sectional Set - Chaise Lounge Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
-
Page 2: Table Of Contents
Contents Safety Instructions Parts List Assembly Securing The Sectional Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. BWKSEC207... -
Page 3: Safety Instructions
Do not place heavy objects on the chaise lounge. WARNING When not in use, secure the product in a cool and covered location. WARNING Do not locate the product near any heat source. WARNING Warning: Weight limit for the chaise lounge is 250lbs (113.4Kg). BWKSEC207... -
Page 4: Parts List
Flat Washer + Bolt (M6x20MM) - 5+1 Seat - 1 Flat Washer + Bolt (M6x45MM) - 2+1 Flat Washer + Bolt (M6x50MM) - 10+1 Back - 1 Allen Wrench - 1 Leg - 5 Seat Cushion - 1 Back Cushion - 1 BWKSEC207... -
Page 5: Assembly
Place seat (B) on a flat protected surface while holding it on its side as shown. Attach back (C) to seat (B) with flat washer and short bolt (G), flat washers and long bolts (H) using Allen Wrench (J). Do not tighten completely. BWKSEC207... - Page 6 Requires: A, B, C, G, J Rotate assembled unit to the position as shown. Attach left arm (A) to seat (B) and back (C) with flat washers and short bolts (G) using Allen Wrench (J). Do not tighten completely. BWKSEC207...
- Page 7 Assembly STEP 3 Requires: A, C, G, J Rotate assembled unit to the standing position. Connect left arm (A) to back (C) with flat washer and short bolt (G), using Allen Wrench (J). Do not tighten completely. BWKSEC207...
- Page 8 Connect legs (D) to left arm (A), seat (B) and back (C) with flat washers and long bolts (I) using Allen Wrench (J). Do not tighten completely. Completely tighten all bolts with Allen Wrench (J) from steps 1 through 4. BWKSEC207...
- Page 9 Assembly STEP 5 Requires: E, F Rotate assembled unit to the standing position. Place seat cushion (E) on chaise lounge. Place back cushion (F) on chaise lounge. Assembly is complete. BWKSEC207...
-
Page 10: Securing The Sectional
Securing the Sectional STEP 1 BWKSEC207... -
Page 11: Cleaning & Maintenance
• Do not clean with abrasive materials, bleach, or solvents. • Store the seating set in a dry, sheltered place when not in use. weather such as rain, hail, sleet, snow, or wind. BWKSEC207... -
Page 12: Warranty
Do not stand or climb on chaise lounge. In order to prolong the life of your chaise lounge, please store in dry sheltered place when not in use or during inclement weather. **We recommend that you save the Allen Wrench and periodically tighten all bolts. BWKSEC207... - Page 13 ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. BWKSEC207 Contact Customer Service at 1-866-988-3300...
- Page 14 Assembly Instructions Model No. BWKSEC207 Blonde Wicker Sectional Set - Loveseat Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
- Page 15 Contents Safety Instructions Parts List Assembly Securing The Sectional Cleaning & Maintenance Warranty IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. BWKSEC207...
-
Page 16: Safety Instructions
Do not place heavy objects on the loveseat. WARNING When not in use, secure the product in a cool and covered location. WARNING Do not locate the product near any heat source. WARNING Warning: Weight limit for the loveseat is 500lbs (226.8Kg). BWKSEC207... -
Page 17: Parts List
Flat Washer + Bolt (M6x20MM) - 5+1 Seat - 1 Flat Washer + Bolt (M6x45MM) - 3+1 Flat Washer + Bolt (M6x50MM) - 8+1 Back - 1 Allen Wrench - 1 Leg - 4 Seat Cushion - 1 Back Cushion - 2 BWKSEC207... -
Page 18: Assembly
Requires: B, C, G, H, J Place back (C) on a flat protected surface. Connect seat (B) to back (C) with flat washer and short bolt (G), flat washers and long bolts (H) using Allen Wrench (J). Do not tighten completely. BWKSEC207... - Page 19 Assembly STEP 2 Requires: A, B, C, G, J Connect right arm (A) to seat (B) and back (C) with flat washers and short bolts (G) using Allen Wrench (J). Do not tighten completely. BWKSEC207...
- Page 20 Assembly STEP 3 Requires: A, C, G, J Rotate assembled unit to the standing position. Connect back (C) to right arm (A) with flat washer and short bolt (G), using Allen Wrench (J). Do not tighten completely. BWKSEC207...
- Page 21 Connect legs (D) to right arm (A), seat (B) and back (C) with flat washers and long bolts (I) using Allen Wrench (J). Do not tighten completely. Completely tighten all bolts with Allen Wrench (J) from steps 1 through 4. BWKSEC207...
- Page 22 Assembly STEP 5 Requires: E, F Rotate assembled unit to the standing position. Place seat cushion (E) on loveseat. Place back cushions (F) on loveseat. Assembly is complete. BWKSEC207...
-
Page 23: Securing The Sectional
Securing the Sectional STEP 1 BWKSEC207... -
Page 24: Cleaning & Maintenance
• Do not clean with abrasive materials, bleach, or solvents. • Store the seating set in a dry, sheltered place when not in use. weather such as rain, hail, sleet, snow, or wind. BWKSEC207... -
Page 25: Warranty
Do not stand or climb on loveseat. In order to prolong the life of your loveseat, please store in dry sheltered place when not in use or during inclement weather. **We recommend that you save the Allen Wrench and periodically tighten all bolts. BWKSEC207... - Page 26 ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. BWKSEC207 Contact Customer Service at 1-866-988-3300...
