- Page 1 OWNER's INSTRUCTIONS MANUAL Gas Fire Table User's Guide and Instruction Manual ITEM #72716.00BRN-40K The assembly step is from page 8 to page 10. Noble house Home Furnishings LLC...
-
Page 2: Carbon Monoxide Hazard
Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. If you are assembling this unit for someone else, give this Owner's Manual to them to read. Noble house Home Furnishings LLC... -
Page 3: Limitation Of Warranty And Liability
This Limitation of Warranty and Liability may not be amended by any oral or written agreement. Noble house Home Furnishings LLC... -
Page 4: Safety Information
・ Use LP propane tanks with the following dimensions: diameter 12 in, height 18 in - capacity 20lbs. ・ You must use a Propane Gas Tank that has a collar to protect the Gas Valve. Noble house Home Furnishings LLC... - Page 5 ・ Keep all electrical cords and fuel supply hose away from heated surfaces. ・ Combustible material should NOT be within 72 inches of the top of the unit, and within 48 inches around the entire unit. Noble house Home Furnishings LLC...
- Page 6 ・ The LP Gas tank must have a listed overfilling prevention device and a QCCI or Type I, LP Gas tank connection. ・ This heating appliance should NOT be used on plastic, artificial wood decks or any deck. Noble house Home Furnishings LLC...
- Page 7 : 1- 818-435-3985. NOTE: You must follow all steps to properly assemble this Fire Table / Column. Make sure the Gas Valve is turned “OFF” before assembling. DO NOT attempt to assemble without proper tools. Noble house Home Furnishings LLC...
-
Page 8: Parts List
Description Table Top Burning System Table Leg Safety Guard Hardware Label Picture Description Wrench Bolt (M6*25mm) Bolt (M6*16mm) Flat Washer Ring(M6) Nut(M6) Screwdriver Baseplate Bolt (M8*16mm) Bolt (M8*20mm) Flat Washer(M8) Spring Washer(M8) Allen Wrench Leveller Noble house Home Furnishings LLC... -
Page 9: Assembly Steps
2.Position it, then affix it using Bolts(b),Flat Washer Rings(d) and Nuts(e) with the Wrench(a) as pictured. 3.Affix it using Flat Washer Rings(d), Bolts(c),with the Screwdriver(f) as pictured. Tighten the Screws fully in a sequential manner. Caution: Assistance from your adult partner is needed in this assembly process. Noble house Home Furnishings LLC... - Page 10 Attach the Safety Guard(D1) to the bottom of burner plate using Flat Washer Rings(d) and Bolts(c) with Screwdriver(f) as pictured above. Step 5 Stand the Fire table,with assistance from an adult partner. Your Fire Table assembly step is completed. Caution: Assistance from your adult partner is needed in this assembly process. Noble house Home Furnishings LLC...
- Page 11 ) is pre- connected to the Fire Table / Column. the different components and parts of the Gas Tank and the Fire Table / Column Regulator, as show on the picture to the left here. Noble house Home Furnishings LLC...
- Page 12 Turn the wing screw on the outer part of metal stand clockwise to secure the gas tank tightly. Connect the regulator to gas tank through the bottom of the metal stand. Put the cover on the metal stand. Noble house Home Furnishings LLC...
- Page 13 Each part is different and holds its own function. DO NOT attempt to change and or remove any part(s) thereof. In the event of servicing and or operational issues, contact Qualified Services Technical Support and or seek Qualified Service Technician. Noble house Home Furnishings LLC...
- Page 14 For your conveneince all of the above components are individually desribed herebelow. Tabulated here below are the description to all parts as shown in above Picture . Item Picture Description Guard Thermocouple Ignition Pin Main Frame of Fire Table Noble house Home Furnishings LLC...
- Page 15 Tabulated herebelow is the User's Guide to various Parts and Accessories to form your complete Fire Table /Column. Before you start to assemble this product, make sure all parts are present. Compare parts with package contents list. If any parts are missing or damaged, DO NOT attempt to assemble the product. Noble house Home Furnishings LLC...
- Page 16 Before Beginning Assembly: Description : Part I. Item Picture Description Lava Rocks 1 Box AAA Battery 1 pc Tank Holder 1 pc Mainframe of Fire Table 1 pc Protective Cover 1 pc Noble house Home Furnishings LLC...
- Page 17 Turn the wing screw on the outer part of metal stand clockwise to secure the gas tank tightly. STEP 3 3. Connect the regulator to gas tank through the bottom of the metal stand. Put the cover on the metal stand. Noble house Home Furnishings LLC...
- Page 18 6. Remove the Electronic Ignitor Cap (14) on the electronic Ignitor (14) by unscrewing and slide the Battery (B) into the battery slot (14). Make sure the positive side of the Battery( B ) faces outwards. Screw the Electronic Ignitor Cap (14) over the battery, tightly. Noble house Home Furnishings LLC...
- Page 19 WARNING: Fire Table and LP-Cylinder must be at a minimum of 60 inches apart. To ensure proper function, the Guard (01) on the Burner (08) should never have lava rocks (A) covered over it. Noble house Home Furnishings LLC...
- Page 20 To Shut Down your Fire Table / Column, please proceed / adopt the following steps : 1. Turn Control Knob (15) clockwise to the “OFF” position. 2. Close the Cylinder Valve (22) on the Propane Gas tank if you DO NOT intend to use it for a long time. Noble house Home Furnishings LLC...
- Page 21 Cover your product with an outdoor Protective Cover(E) when not in use to protect it from the elements. Store your product indoors during winter months, leave the gas tank outside. Avoiding extreme cold temperatures, as extreme cold temperatures may cause cracking of the tabletop. Noble house Home Furnishings LLC...
-
Page 22: Troubleshooting
・ Use and installation other than what is listed in this Owner's Manual. Please contact the manufacturer for replacement parts. CONTACT Part R. If you have any questions or concerns, our Trained Staff are ready to assist you. Contact: 1-818-435-3985 Monday-Friday 8 a.m. to 5 p.m. PST Noble house Home Furnishings LLC...
