- Page 1 Assembly Instructions Caution: You should read this carefully before you proceed Sofa Noble House Home Furnishings LLC Page 1 OF 10...
-
Page 2: Parts List
Parts List Label Picture Description Backrest Back cushion Left Armrest Right Armrest Seat Seat Cushion Sofa Leg Middle Support Leg Noble House Home Furnishings LLC Page 2 OF 10... -
Page 3: Assembly Preparation
Hardware Label Picture Description ① Bolt (M8*70MM) ② Washer ③ Bolt (M8*30MM) ④ Allen Key ⑤ Spring Washer ⑥ Gasket Assembly Preparation Before Beginning Assembly: X 11 X 19 X 19 Noble House Home Furnishings LLC Page 3 OF 10... -
Page 4: Assembly Steps
Note: It is recommended that you have an adult partner to assist you during the entire assembly process. Noble House Home Furnishings LLC Page 4 OF 10... - Page 5 Rather, In a sequential manner, gradually tighten each Bolt until all Bolts are evenly secured. This methodology will ensure maximum evenness once all Bolts are fully tightened. Caution: Ensure that your fingers do not get caught or pinched in the assembly process. Noble House Home Furnishings LLC Page 5 OF 10...
- Page 6 Armrests(C&D) . Fully locked postion: Check and assess that the base of the Backrest(A) and Seat(E) are aligned and level. Assistance from an adult partner is needed for this assembly process. Noble House Home Furnishings LLC Page 6 OF 10...
- Page 7 This methodology will ensure maximum evenness once all Bolts are fully tightened. Note: If you can not insert the Bolts into position, please go back to Step 2 to "push the Backrest downwards". Noble House Home Furnishings LLC Page 7 OF 10...
- Page 8 Some Legs may need more than one while other legs may not need any. Please keep well the Allen key, tighten the Bolts again with Allen key If the product is loosen during use. Noble House Home Furnishings LLC Page 8 OF 10...
- Page 9 Place the sofa in an upright position, then Place the Seat Cushions(F) and the Back Cushion (B) onto the Sofa. Your Sofa is ready for use. This Sofa can only be used on a flat, level surface. Noble House Home Furnishings LLC Page 9 OF 10...
- Page 10 Noble House Home Furnishings LLC Page 10 OF 10...
