3.4.2

NEW ROCY DISTRIBUTION FRAME FOR C8 (INFRA + FOR FRANCE)

Simultaneous use of
the S0 and T0
interfaces is not
possible
The RJ45 (J3G)
connector is not
used.
OCY card equipment wiring:
Connection
point
Eqt
16
Digital phone
15
14
Digital phone
13
12
11
General bell
10
(80 V)
9
8
Computer
7
terminal
6
(RS232C)
5
4
3
External
music
2
1
Connection point legend:
BFM
PME
V12ME : 12 V voltage
Note: loop V12ME on PME to simulate presence of external music.
Note: The new main distribution frame does not allow synchronization by additional
pair. If more than one base station is installed, it is therefore necessary to have
an EOCU card and to use m-bit synchronization.
PAGE 52/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
J7
Signals Eqt No.
B
08
A
B
09
A
Not used
GND -
SG2 -
SG1 -
GND
-
CTS
-
TD (TDI)
-
RD (RDI) -
V12ME -
PME -
BFM -
GND -
: modulated low frequency input
: external music present
J6
Digital
terminals
Signals Eqt No.
B
07
A
B
06
A
B
05
A
B
04
A
B
03
A
B
02
A
B
01
A
B
00
A
LCAH-30521-001-05=01/EN
J5
Analog
terminals
Signals Eqt No.
Not used
B 15
A
B 14
A
B 13
A
B 12
A
B 11
A
B 10
A
