Connection on J3 and J4:
Note:
In this case, connector J2 will receive the power supply for S0 interface.
Note:
RT: T-interface (receive)
AND: T-interface (transmit)
PAGE
62/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
RS: S-interface (receive)
ES: S-interface (transmit)
LCAH-30521-001-05=01/EN
