The OCY2 card for the MC 6501-C4E PBX is a customized version of OCY2 card for the
MC 6501-C8 PBX.
Equipment connectors J1, J3 and J4 are used to install three telephone extension cards
chosen from the optional cards available:
Connector J1 is used to fit a telephone extension card or POCY card.
Connectors J3 and J4 (*) are used to fit all card types except the POCY card.
(*) this position is not available on the MC 6501-C4E PBX
3.2.2

DESCRIPTION OF THE CONNECTORS (MC 6501-C8 PBX)

J1
J3
J4
J5
J6 (3.1)
J7 (3.0)
J8 (2.1)
J9 (2.0)
J10 (0.6; 0.7; 0.8; 0.9)
J11 (0.2; 0.3; 0.4; 0.5)
J12 (1.4; 1.5; 0.0; 0.1)
J13 (1.0; 1.1; 1.2; 1.3)
J14 (s2, s1)
J15 (SG)
J16 (MUS)
J17 (COM2)
J18 (COM1)
J19 (BASC)
Legend: The digits shown between brackets (following the connector reference) indicate the
position of the cards and equipment, e.g. (3.0) corresponds to card 3 equipment 0.
PAGE 36/171
This confidential document is the property of MATRA NORTEL COMMUNICATIONS and may not be copied or circulated without permission.
Ce document confidentiel est la propriété de MATRA NORTEL COMMUNICATIONS et ne doit pas être reproduit ou communiqué sans autorisation.
Connector on POCY or Elxx or CHPW or EOCx card (except
EOCT, EOCV and MVE cards)
Connector on Elxx or CHPW or EOCx card
Connector on Elxx or CHPW or EOCx card
Connector on AOCY card (power supply card)
Tx/Rx connector for the second T0/S0_2 equipment, according to
configuration of CA5
Tx/Rx connector for the second T0_2 equipment
Tx/Rx connector for the first T0/S0_1 equipment, according to
configuration of CA5
Tx/Rx connector for the first T0_1 equipment
Connector for four digital sets
Connector for four digital sets
Connector for four sets: two analog, two digital
Connector for four analog sets
Ringing current power supply connector for Elxx, EOCA card
General bell connector
Connector for external music-on-hold
Printer connector
Connector for operating console (PC or Minitel)
12 V power supply connector for call transfer module
Table 1: Description of OCY2 card connectors
