WARNING:
This unit employs components that tend to produce arcs or sparks. To
prevent fire or explosion, do not install in compartments containing
batteries or flammable materials - SHOCK HAZARD. DO NOT OPEN.
CAUTION:
OUTPUT NON-SINUSOIDAL REFER TO MANUAL - Provided with integral
protection against overloads. To prevent fire, do not cover or obstruct
ventilation openings. Do not mount in zero clearance compartment.
Overheating may result.
EN150
Owner's Guide
Toll Free 1-866-295-6775
Conforms to / Conforme à UL std. 458,
Printed in China
CSA std. C22.2 No. 107.1
Advertisement
Table of Contents
Related Manuals for Energizer EN150
Summary of Contents for Energizer EN150
- Page 1 OUTPUT NON-SINUSOIDAL REFER TO MANUAL - Provided with integral protection against overloads. To prevent fire, do not cover or obstruct ventilation openings. Do not mount in zero clearance compartment. Overheating may result. EN150 Owner's Guide Toll Free 1-866-295-6775 Conforms to / Conforme à UL std. 458, Printed in China CSA std.
-
Page 2: Important Safety Information
Thank you for purchasing the Energizer EN150 Connected to the 12-volt outlet in your vehicle, the EN150 efficiently and reliably powers a wide variety of loads through both the AC outlet and USB port. Read this guide before connecting or using the EN150 and save it for future reference . - Page 3 Warnings and Cautions The EN150 housing may become uncomfortably warm, reaching 60 °C (140 °F) under extended high power operation. During operation, keep it away from materials that may be affected by high temperatures. EN150 in the presence of Do not use the flammable fumes or gases, such as in the bilge of a gasoline powered boat, or near propane tanks.
- Page 4 CAUTION: Risk of Fire. Do not replace any vehicle fuse with a rating higher than recommended by the Vehicle Manufacturer. Ensure that the electrical system in your vehicle can supply this product without causing the vehicle fusing to open. Information on the vehicle fuse rating is typically found in the vehicle operator’s manual.
- Page 5 CAUTION Do not connect live AC power to the EN150 AC outlets. This will damage the inverter, and the damage is not covered by warranty. Do not connect any AC load that has its neutral...
-
Page 6: Additional Safety Guidelines
Additional Safety Guidelines • Do not insert foreign objects in the EN150 out l ets o r othe r ope ning s. • Never connect the inverter to power utility AC distribution wiring. • Do not use the EN150 in te mperatu res over 40 °C (100 °F). -
Page 7: Inverter Features
4 Inverter Features EN150 AC Outlet LED Light indicator USB QC3.0 5V/3A, 9V/3A, 12V/2.5A Ventilation opening... -
Page 8: Using The Inverter
Through its AC outlet, the EN150 is capable of powering most 120V AC products that use 150W or less. The EN150 cup inverter can also power or charge most consumer electronics that have USB power ports. The EN150 AC output waveform, called “modified sine wave”... - Page 9 Plug a DC cable into the DC cable port on the EN150 and connect to a 12V cigarette lighter receptacle. Plug the device you want to operate into the EN150 When the inverter is not in use, unplug it from the 12V outlet to prevent slight discharge of the battery.
-
Page 10: Inverter Operation
DC input has dropped to 10.5V, the inverter automatically shuts down and the light glows RED, indicating a fault. This prevents the battery from being damaged. Turn off any devices that the EN150 is p owering. - Page 11 Vehicle batteries are designed to provide brief periods of very high current needed for engine starting. T hey are not intended for constant deep discharge.Regularly operating the EN150 from a vehicle battery until low-voltage shutdown occurs willshorten the life of the battery. •...
-
Page 12: Battery Operating Time
CAUTION Although the EN150 incorporates l tage, it may still be protection against over-vo damaged if the input voltage exceeds 16 V. • In the event of an overload, low battery voltage or overheating, the EN150 automatically shuts down. Battery Operating Time... -
Page 13: Interference With Electronic Equipment
Generally the o ,nly solution is an audio product with a higher quality filter. Television interference The EN150 i s shie l ded to minimiz e i tsinterference with TVsignals. However, with weak TV signals interference may be visible in the form of lines scrolling across the screen. -
Page 14: Troubleshooting
7 Troubleshooting PROBLEM: AC product will not operate, no inverter lights are Possible cause Solution Battery is defective. Check battery and replace if required. Loose connections. Check connections. PROBLEM: Measured inverter output is to o low. Possible cause Solution Standard “average- Inverter’s “modi ed sine reading”... - Page 15 Possible cause Solution Battery voltage is too low. Recharge battery. PROBLEM: AC product will not operate, RED FAULT light ON. Possible cause Solution AC product(s) connected Use a product with a power are rated at more than the rating less than the inverter’s inverter’s continuous continuous power rating.
- Page 16 Specifications are subject to change without notice. AC Power Outpu t EN150 AC output voltage (nominal) 115VAC/60Hz 150W Continuous AC output power 150W Modified sine wave AC output waveform 300W Maximum AC output surge power 60 ± 3Hz AC output frequency...
- Page 17 DC Power EN150 DC input voltage range (VDC) 13.8V DC, 15A Max Battery drain with no AC load 0.4A (at 12 V input) Efficiency (maximum) Low voltage shutdown point (nominal) 10.5V+ 0.5V High voltage shutdown point 15.5V+ 0.3V (nominal) Physical Dimensions (milimetres ) (L)5.5 in...
-
Page 18: Warranty And Return
This Limited Warranty is provided by PowerBright and covers defects in workmanship and materials in your EN150. This warranty period lasts for 24 months from the date of purchase at the point of sale to you, the original end user customer. You require proof of purchase to make warranty claims. - Page 19 shipment to the customer, whichever is greater. All replaced products and all parts removed from repaired products become the property of PowerBright. PowerBright covers both parts and labor necessary to repair the product, and return shipment to the customer via a PowerBright selected non-expedited surface freight within the contiguous United States and Canada.
- Page 20 What does this warranty not cover? This Limited Warranty does not cover normal wear and tear of the product or costs related to the removal, installation, or troubleshooting of the customer's electrical systems. This warranty does not apply to, and PowerBright will not be responsible for, any defect in or damage to: the product if it has been misused, neglected, improp- erly installed, physically damaged or altered, either...
- Page 21 SHOULD NOT BE USED IN CONNECTION WITH LIFE SUPPORT SYSTEMS OR OTHER MEDICAL EQUIPMENT OR DEVICES. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, POWERBRIGHT MAKES NO REPRESENTATIONS OR WARRANTIES REGARDING THE USE OF THE ENERGIZER EN150 IN CONNECTION WITH LIFE SUPPORT SYSTEMS OR OTHER MEDICAL EQUIPMENT OR DEVICES.
-
Page 22: Return Material Authorization Policy
Return Material Authorization Policy Before returning a product directly to PowerBright you must obtain a Return Material Authorization (RMA) number and the correct factory "Ship To" address. Products must also be shipped prepaid. Product shipments will be refused and returned at your expense if they are unauthorized, returned without an RMA number clearly marked on the outside of the shipping box, if they are shipped collect, or if they are shipped to the wrong location. -
Page 23: Return Procedure
Return Procedure Package the unit safely, preferably using the original box and packing materials. Please ensure that your product is shipped fully insured in the original packaging or equivalent. This warranty will not apply where the product is damaged due to improper packaging.
