Black Wide CD DVD Multimedia Unit
Assembly Instructions -
900/2566
Please keep for future reference
Dimensions
Width - 63.3cm
Depth - 20cm
Height - 113.1cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
08456 400800
Issue 1 - 9/07/08
Advertisement
Related Manuals for Argos 900/2566
Summary of Contents for Argos 900/2566
- Page 1 Black Wide CD DVD Multimedia Unit Assembly Instructions - 900/2566 Please keep for future reference Dimensions Width - 63.3cm Depth - 20cm Height - 113.1cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 and 3.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Base Adjustable Shelves x 12 (13.2 x 60.6cm) (20 x 63.3cm) (10.6 x 20.85cm) Left side panels Right side panels Back board x 2 (13.1 x 110.8cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 38mm Screw x 8 Dowel x 8 Glue x 1 Stability brackets x 8 14mm Screw x 8...
- Page 5 Assembly Instructions Step 1 Top assembly Using a drop of glue attach eight dowels the underside of the top Attach the sides & and centre sections & to the top ensuring that they are the right way up (as per the diagram) and the grooves cut into the panels for the back boards are all to the rear...
- Page 6 Assembly Instructions Step 3 Bottom assembly Attach the base using eight screws Before tightening ensure the back boards locate correctly in the groove cut into the base. Step 4 Using the screws attach the Stability brackets the approximate positions shown in the diagram to ensure the assembled unit is stable and rigid.
- Page 7 Assembly Instructions Step 5 Carefully turn the unit the correct way up. Insert the shelf supports pins at the appropriate level for the media you wish to store and then insert the shelves Step 6 Setting CD or DVD Compartments For CD: CD is partitioned into 7 compartments.
- Page 8 Assembly Instructions Step 7 Finishing the unit NOTE: It would be useful to ask someone to help you at this stage. It is strongly recommended that the unit is attached to the wall using Wall Strap Drill a hole in the wall at an appropriate position and insert a suitable Wall plug .
- Page 10 Wide DVD and CD Multimedia Storage Unit Assembly Instructions - 900/2566 Please keep for future reference Dimensions Width - 63.3cm Depth - 20cm Height - 113.2cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
- Page 11 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 and 3.
- Page 12 If you have damaged or missing components, Components - Panels call the Customer Helpline: 08456 400800 Please check you have all the panels listed below Top(13.2x60.6cm) Base (20x63.3cm) (13.1x110.8cm) Left side panel (13.1x110.8cm) Right side panel (13.1x110.8cm) Left center panel (13.1x110.8cm) Right center panel Adjustable shelf x 10...
- Page 13 Components - Fittings Please check you have all the fttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fttings may be supplied than are required. 38mm Screw x 16 Stability bracket x 8 15mm Screw x 8 Shelf support x 40 Cam bolt x 8...
- Page 14 Assembly Instructions Step 1 Fitting Cam bolt Screw the Cam bolts into the panel & Step 2 Fitting Cam lock NOTE: Ensure center panel & are in the right way up (as per diagram ). lnsert the Cam lock into Fixed shelf Turn the Cam lock clockwise until tightened.
- Page 15 Assembly Instructions Step 3 Fitting Top Attach the Top using Screws Before tightening ensure the grooves of the panels for the back boards are all in the rear of the unit. Use Cap to cover the screw. Step 4 Use 12mm Screw to fix Wall strap onto the unit.
- Page 16 Assembly Instructions Step 6 Fitting Base Attach the Base using Screw Before tightening ensure the back boards locate correctly in the groove cut of the base. Step 7 Attached the Stability bracket using Screw in the approximate positions shown in the diagram to ensure the assembled unit is stable and rigid.
- Page 17 Assembly Instructions Step 8 Fitting Shelf support Insert Shelf support at the appropriate level for the media you wish to store. Step 9 Fitting Shelf Carefully insert the Shelf onto the unit.
- Page 18 Assembly Instructions Step 10 Fixing to wall NOTE: It would be useful to ask someone to help wall you at this stage. It is strongly recommended that the unit is attached to the wall using Wall strap Drill a hole in the wall at an appropriate position and insert Wall plug Warning:...
-
Page 19: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
