- Page 1 OWNER’S MANUAL WARNING For safety reasons, please read the manual first before plugging in machine. Please keep this manual properly for convenient reference as needed.
- Page 2 About This Manual Thank you for purchasing this product. The manual describes how to install, set up, use and maintain the product. The main purpose of the manual is to instruct how to operate the product correctly and safely. Please follow all the safety and warning instructions in the manual to avoid personal injury and product damage.
-
Page 3: Table Of Contents
Table of Contents About This Manual 1. Safety Precautions ..........1 ............1.1 Warning Stickers ............. 1.2 Placing Site ............1.3 Safety Precautions ............. 1.4 Precaution during Play ..........1.5 Transporting and Moving ............. 1.6 Installing and Placing ..........1.7 Caution & Warning Stickers 2. - Page 4 ............4.4.2 Country ............. 4.4.3 Store ............. 4.4.4 Difficult setting ............. 4.4.5 Tunnel setting ............4.4.6 Coin settings ..........4.4.7 Multiplayer setting ............ 4.4.8 Volume setting ........... 4.4.9 Flow time setting ..........4.4.10 Ranking board reset ............4.5 System settings ..........
- Page 5 6. Assembly ............59 ............59 6.1 Assembly tree diagram ..........60 6.2 Final host-machine assembly ............61 6.3 Host-machine assembly .........63 6.3.1 Host-machine frame assembly ..........64 6.3.2 Host machine assembly ..........65 6.3.3 Power pack assembly ..........66 6.3.4 Power amplifier assembly ..........67 6.3.5 I/O board assembly ..........68 6.3.6 Coining frame assembly ...........69...
-
Page 6: Safety Precautions
1. Safety Precautions 1.1 Warning Stickers In order to avoid injury to related people and damage to property, please observe the followings: PLEASE READ FIRST PLEASE READ FIRST The following marks can be used to indicate the magnitudes of risk and damage caused by ignorance or improper operation: Warning Warning... -
Page 7: Safety Precautions
1.3 Safety Precautions The owner shall pay attention to the followings when placing, checking and repairing machine to insure player’s security and avoid damage: Warning Warning Make sure to plug the game into 110V or 220V main outlet to avoid fire and electric shock. -
Page 8: Precaution During Play
1.4 Precautions during Play Caution Caution In order to avoid injury and accident during play, the following people shall not play the game: People who are injured or less mobile. Person with poor health condition, such as hypertension or heart disease. Person wearing high-heeled or slippery shoes. -
Page 9: Installing And Placing
1.6 Installing and Placing Pay attention to the following when placing the machine. Caution Caution Place the machine on the flat and slip resistant area. Use the adjusters to fix the machine (See diagram 1) 1.Loosen the nuts for the adjusters (clockwise), tighten the bolts with a wrench (clockwise). 2.Tighten the nut firmly(counter clockwise) and fix it well. -
Page 10: Caution & Warning Stickers
1.7 Caution & Warning Stickers... -
Page 11: Product Introduction
2. Product Description 2.1 Product Specification Location Indoor Only Dimension 1108(W)×1693(D)×2335(H) Rated Voltage 220V Frequency 50Hz Power Consumption 750W Weight 280kg Temperature Range 5~40 。 C 1108mm 1693mm Front View Side View... -
Page 12: Overview
2.2 Overview Side View Rear View Top View Bottom View... -
Page 13: Spare Parts
2.3 Spare Parts Card-board components Billboard acrylic Right side of light box Display Steering wheel Shifting fork Seat Coining door Accelerator and the brake Host machine 4X exhaust pipes Host- machine base Light box Light box Display supporting frame Back service-door AC box... -
Page 14: Shipment List
2.4 Shipment List Packing Carton 1 7 HXK-9901E05 耐水3C 1100g T-10 座椅天盖 6 HXK-9901E04 耐水3C 1100g T-10 座椅围框 5 HXK-9901E03 实木40*20*767 座椅地台架限位木条二 4 HXK-9901E02 实木40*20*500 座椅地台架限位木条一 3 HXK-9901E01 座椅地台架 2 HXK-9903000 灯箱左右侧及豪卡板包装 HXK-0200000A 座椅组件 图 号 名 称 材料/规格 数量 序号... - Page 15 Packing Carton 2 345*255*110mm 附属品纸箱 6 HXK-9902E05 耐水3C 1100g T-10 机台主体天盖 5 HXK-9902E04 耐水3C 1100g T-10 机台主体围框 4 HXK-9902E03 实木40*20*700 机台主体地台架限位木条二 3 HXK-9902E02 实木40*20*1020 机台主体地台架限位木条一 HXK-0100000A 机台主体组件 HXK-9902E01 机台主体地台架 序号 图 号 名 称 材料/规格 数量 备注 10 10...
-
Page 16: Packing List
2.5 Packing List Please check the following items after purchasing our product. If any part missing or damaged, please contact our sales person! Description Specification Quantity Remarks Same-size key 5555 keys Power line (3 pins at both ends ) 3m（1.0m㎡) Flat gasket φ6*φ20*2.0（chrome-plated）... -
Page 17: Install Direction
2.6 Install Direction Step 1 1. First of all, the two pieces of reinforced-plastic sheet metals of exhaust-pipe are fixed to the base with the large cross-head flat screws (black-plated）. 2. After the right-side assembly of the exhaust pipe is fixed to the base with 3 large cross-head flat screws M4 * 12 (black-plated), then the wires on the exhaust pipe are connected properly. - Page 18 Step 3 1. First of all, hang the light-box framework onto the supporting frame and connect the wires on the light-box framework properly, then use 8 cross-head round screws M5 * 16 (black-plated) to fix the light-box framework to the display supporting frame. 2.
- Page 19 3. Put the long holes on either side of billboard acrylic onto the studs on either side of the light box, and then use M5 * 12 (chrome-plated) hexagonal-socket flat head screws to fix billboard acrylic decorative sheets onto billboard acrylic. Card board components Billboard acrylic Billboard acrylic...
-
Page 20: Warranty
2.7 Warranty Scope Inquiry regarding product can be assisted for free. The warranty scope for consumables and durables may differ from product to product. Please contact our after-sales service center for detailed information. The right of final interpretation is reserved. Exclusive Damage caused by force majeure such as god will. -
Page 21: Game Description
3. Game Description 3.1 Appearance Design The host-machine is used for racing game and its appearance design is very novel. Its main structure is yellow & black and provided with the racing decorative board. Its sides are decorated with the dynamic racing-car. -
Page 22: Connection And Turning On The Power
3.4 Connection and turning on the power ● Connecting 2 cabinets Connecting 2 cabinets 1. Use the key to open the maintenance door located in the back of the cabinet. 2. Plug in one side of the included Internet wire to the cabinet and the other side to the router(HUB). 3. -
Page 23: Setting The Group Number And Player Id
3.5 Setting the group number and player ID In order to launch a multi-player mode (a maximum of 4 cabinets is allowed) , you must assign the cabinets into the same group number but different player ID. If 4 cabinets are connected, then appoint their player ID as 1P, 2P, 3P, 4P. -
Page 24: Test And Setting
4. Test and Setting 4.1 Distinctive plays ■ Three game modes Multi-player mode: a maximum of 4 players is allowed. Race mode: to challenge each round and upgrade the vehicle. Time trial: to challenge the best record on the track. ■... -
Page 25: Game Control
4.1.1 Game control ■ Instructions of the Control buttons Steering wheel Control the car turning Start / Boost button Gear stick Sequential gear stick to shift View button Change view Throttle & brake Control the car speed ■ Instructions of the game display Connection Time counter down Rank / Total racer... -
Page 26: Game Control
4.1.2 Game control Except the basic operations such as speeding and stepping on the brake, other operations are as follows: Press to con rm. This button can also provide boost; when pressed twice, Turbo Jet will be initiated. Turning the steering wheel to the left or right could make turns. - Page 27 When the game is in process, and occurs, press the button to avoid event. When the manual transmission is selected, use the gear stick to change gears. When the game is in process, press at the same time to end the game. （This function does not work under multi-player mode）...
-
Page 28: Framework Of The Menu
4.2 Framework of the menu I / O test Coin Service Hardware test Test Start / Boost Connection status View I / O test Gear stick Force feedback test Lamp test Steering wheel Throttle Screen test Brake Speaker test Vibration seat test Keypad test Lamp test Counter test... -
Page 29: Using The Operator Settings
4.2.1 Using the operator settings Make sure the cabinet is turned on and the game is displayed on the screen. Open the door of the coin box and press the 【TEST】 button to enter operator settings. Then the screen will display as below: Enter the menu and follow the instructions. -
Page 30: Hardware Test
4.3 Hardware test You can enter 【Hardware test】 to test if all hardware is normally functioning or not. Enter 【Operator settings】 → 【Hardware test】 and the screen will display as below ： Use 【gear up】 and 【 gear down 】 to move the cursor and then press the 【Start】 button to enter the sub menu. -
Page 31: I/O Test
4.3.2 I/O test In the page of【I/O test】 , you can run the testing of specific application to see if it is normally functioning or not. Well-sensed devices will be shown with a corresponding picture, value or “on＂ icon. Enter 【Operator settings】 → 【Hardware test】 → 【I/O test】 . Then the screen will display as below ：... -
Page 32: Force Feedback Test
4.3.3 Force feedback test In the page of 【 Force feedback test 】 , you can test whether the force feedback is normally functioning or not. Enter 【 Operator settings 】 → 【 Hardware test 】 → 【 Force feedback test 】 , and the screen will display as below ：... -
Page 33: Lamp Test
4.3.4 Lamp test In the page of 【 Lamp test 】 , you can test if each light is normally functioning or not. Enter 【 Operator settings 】 → 【 Hardware test 】 → 【 Lamp test 】 , then the screen will display as below. -
Page 34: Screen Test
4.3.5 Screen test In the page of 【 Screen test 】 , you can test whether the white balance, color level, and lattice are normally functioning or not. Enter 【 Operator settings 】 → 【 Hardware test 】 → 【 Screen test 】 . After you enter the page of 【... -
Page 35: Speaker Test
4.3.6 Speaker test In the page of 【 Speaker test 】 , you can test whether the loudspeaker is normally functioning or not. Enter 【 Operator settings 】 → 【 Hardware test 】 → 【 Speaker setting 】 , and the screen will display as below ：... -
Page 36: Keypad Test
4.3.8 Keypad test In the page of 【 Keypad test 】 , you can test whether the keypad is normally functioning or not. Enter 【 Operator settings 】 → 【 Hardware test 】 → 【 Keypad test 】 , and the screen will display as below ：... -
Page 37: Game Settings
4.4 Game settings In the page of 【 Game settings 】 , you can set up all related features of the game. Enter 【 Operator settings 】 → 【 Game settings 】 , and the screen will display as below ： Use the 【... -
Page 38: I / O Adjustment
4.4.1 I / O adjustment In the page of 【 I / O adjustment 】 , you can adjust the minimum and maximum value of the throttle, brake and steering wheel. Enter 【 Operator settings 】 → 【 Game settings 】 → 【 I/O adjustment 】 , and the screen will display as follow ：... -
Page 39: Store
4.4.3 Store In the page of 【 Store 】 , you can set up the name of your store. Enter 【 Operator settings 】 → 【 Game settings 】 → 【 Store 】 , and the screen will display as below ： When done, move the cursor to 【... -
Page 40: Tunnel Setting
4.4.5 Tunnel setting In this page of【Tunnel setting】 , you can set up the tunnel for complex tunnel or straight tunnel only. Enter 【Operator settings】 → 【Game settings】 → 【Tunnel setting】 ¸ and the screen will display as below ： Use the 【Gear up】... -
Page 41: Multiplayer Setting
4.4.7 Multiplayer setting In the page of 【 Multiplayer setting 】 , you can determine the maximum bonus game allowed and the timing to join a certain game. Enter 【Operator settings】 → 【Game settings】 → 【Multiplayer setting 】 , and the screen will display as below ：... -
Page 42: Volume Setting
4.4.8 Volume setting In the page of【Volume setting】, you can determine the start time of daytime and evenings and the corresponding volume. Enter 【Operator settings】 → 【Game settings】 → 【Volume setting】 , and the screen will display as follow ： Use the 【Gear up】... -
Page 43: Flow Time Setting
4.4.9 Flow time setting In the page of【Flow time setting】 , you can determine the duration of each process. Enter 【Operator settings】 → 【Game settings】 → 【Flow time setting】 , and the screen will display as below ： Use the 【Gear up】 and 【Gear down】 functions on the gear stick to choose the item, and press the 【Start】... -
Page 44: System Settings
4.5 System settings In the page of of【System settings】, you can set up the system or set the system to the default setting. Enter 【 Operator settings】 → 【System settings】 , and the screen will display as below ： Use the 【Gear up】 and 【Gear down】 functions on the gear stick to choose the item, and the item chosen will appear in red. -
Page 45: Time Setting
4.5.2 Time setting In the page of【Time setting】 , you can set up your local time. Enter 【Operator settings】 → 【System settings】 → 【Time setting】 , and the screen will display as below ： Use the 【Gear up】 and 【Gear down】 functions on the gear stick to choose the item to set up, and press the 【Start】... -
Page 46: Player Data Setting
4.5.4 Player data setting In the page of【Player data setting】 , you can set the player data automatic delete time or delete player data manually. Enter 【Operator setting】→ 【System setting】→ 【Player data setting】 , and the screen will display as below： Use the 【Gear up】... -
Page 47: Income Data
4.6 Income data In the page of【Income data】 , you can check the daily, monthly and total revenue. Enter 【Operator settings】 → 【Income data】 , and the screen will display as below ： Use the 【Gear up】 and 【Gear down】 functions on the gear stick to move the cursor, and the item selected will appear in red. -
Page 48: Daily Income
4.6.1 Daily income In the page of【Daily income】 , you can check the daily revenue of each cabinet. Enter 【Operator settings】→ 【Income data】→ 【Daily income】 , and the screen will display as below ： Descriptions of each item: Item descriptions Date Date of data Coin(s) -
Page 49: Monthly Income
4.6.2 Monthly income In the page of【Monthly income】 , you can check the daily revenue of each cabinet. Enter 【Operator settings】 → 【Income data】 → 【Monthly income】 , and the screen will display as below ： Descriptions of each item: Item descriptions Date... -
Page 50: Total Income
4.6.3 Total income In the page of【Total income】 , you can check the total revenue of each cabinet. Enter 【Operator settings】→ 【Income data】→ 【Total income】 , and the screen will display as below ： Descriptions of each item: item descriptions Coin(s) The total number of coins inserted Total game... -
Page 51: Income Data Reset
4.6.4 Income data reset In the page of【Income data reset】 , you can delete the data of daily income and monthly income. Enter 【Operator settings】→ 【Income data】→ 【Income data reset】 , and the screen will display as below. Use the 【 Gear up】 and 【 Gear down】 functions on the gear stick to choose between 【 Yes】 and 【No】... -
Page 52: Troubleshooting
4.7 Troubleshooting Problems Easy troubleshooting Enter【 Operator settings 】→【 Hardware test 】→【 I/O test 】to run the testing. If testing results are shown, enter【 Operator settings 】→【 Game The throttle, brake or the settings 】→【 I/O adjustment 】to adjusting I/O. steering wheel fail to work. -
Page 53: Maintenance And Service
5. Maintenance and Service 5.1 Maintenance and service Even though the machine works normally for a long time, the fault will occur. Therefore, please perform routine check and maintenance concerning the following to ensure a long-term use. External Inspection Stick “Warning” stickers correctly, keep it legible. Firmly tighten the bolt for each adjuster. -
Page 54: Replacing Parts
5.2 Replacing parts 5.2.1 Replacing fl uorescent tube Remove 4 M5 inner hex screws and disassemble the acrylic plate. Fluorescent tube Remove 8 M4 cruciform screws and disassemble the side acrylic plate before the light box. Replace the fl uorescent tube. -
Page 55: Replacing The Boost Button And The Light Plate
5.2.3 Replacing the boost button and the light plate Remove 4 M5 inner hex screws and disassemble the shift lever. Gear stick Remove 4 M4 inner hex screws and disassemble the acrylic plate behind the boost button. Remove 2 M3 cruciform screws and disassemble the LED light plate behind the boost button. -
Page 56: Replacing The Exhaust Light Plate
5.2.5 Replacing the exhaust light plate Remove 5 M4 inner hex screws and open the cap of the exhaust pipe. LED light plate Remove 2 M4 cruciform screws and disassemble the LED light plate. Then take off the LED light plate and 2 M3 cruciform screws, then replace the LED light plate. -
Page 57: Replacing The Vibration Speaker Under The Seat
5.2.7 Replacing the vibration speaker under the seat Remove 4 M6 inner hex screws and lift up the Vibration speaker chair. Remove 4 M8 screws. Remove 4 M4 cruciform screws and replace the vibration loudspeakers. When done, reassemble according to the reversed assembly sequence. -
Page 58: Replacing The Speaker Behind The Seat
5.2.9 Replacing the speaker behind the seat Speaker Remove 6 plastic screws and take off the cover. Remove 8 M4 cruciform screws and replace the loudspeakers. Speaker When done, reassemble according to the reversed assembly sequence. 5.2.10 Replacing the bottom seat back light Remove 6 plastic screws and open the cover. -
Page 59: Replacing The Dashboard Led Light Plate
5.2.11 Replacing the dashboard LED light plate Remove 4 M3 inner hex screws and take off the cap in the center of the Dashboard cover steering wheel. Dashboard LED light plate Remove M12 screws and take off the steering wheel. Remove 10 M4 inner hex screws and the cover of the steering wheel. -
Page 60: Replacing The Pedals Of The Throttle And Brake
5.2.13 Replacing the pedals of the throttle and brake Remove 4 M4 inner hex screws and the left foot Pedals of the throttle and brake rest pedal cap. Remove 4 M4 cruciform screws and take off the left foot rest pedal. Remove 8 M4 inner hex screws and the decorative pedal. -
Page 61: Replacing The Vr Of The Pedals Of The Throttle And Brake
5.2.15 Replacing the VR of the pedals of the throttle and brake Remove 4 M4 cruciform VR holder screws and take off the caps in the front and the back. Remove 4 M4 cruciform screws and take off the VR set. Remove 4 M3 screws on the VR set and the electric VR and replace... -
Page 62: Maintaining The E3100
5.2.17 Maintaining the E3100 Remove 2 M4 butter y screws. Take out the xed set to maintain or repair. When done, reassemble E3100 holder according to the reversed assembly sequence. 5.2.18 Maintaining the full-range AMP Remove 2 M4 cruciform screws and take out the full-range AMP. -
Page 63: Replacing The Power Supply And Isolation Transformer
5.2.19 Replacing the power supply and isolation transformer Remove 2 M4 cruciform screws and take out the electricity supply appliance. Remove 4 M4 cruciform screws take out the isolation transformer. When done, reassemble according to the reversed assembly sequence. In some regions, the isolation transformer 900VA is not a required part. -
Page 64: Assembly
6. Assembly 6.1 Assembly tree diagram Final host-machine assembly Host-machine assembly Host-machine frame assembly Host machine assembly Power pack assembly Power amplifier assembly I/O board assembly Coining frame assembly AC assembly-box Back service-door assembly Steering-wheel and lamp-plate assembly Control panel assembly (Chinese version - card reader) Control panel assembly (English version - digital buttons Pedal assembly High-pitched sound box assembly... -
Page 65: Final Host-Machine Assembly
6.2 Final host-machine assembly 60 60... -
Page 66: Host-Machine Assembly
6.3 Host-machine assembly 61 61... - Page 67 Host-machine assembly (2） 62 62...
-
Page 68: Host-Machine Frame Assembly
6.3.1 Host-machine frame assembly 63 63... -
Page 69: Host Machine Assembly
6.3.2 Host machine assembly 64 64... -
Page 70: Power Pack Assembly
6.3.3 Power pack assembly 65 65... -
Page 71: Power Amplifier Assembly
6.3.4 Power amplifier assembly 66 66... -
Page 72: I/O Board Assembly
6.3.5 I/O board assembly 67 67... -
Page 73: Coining Frame Assembly
6.3.6 Coining frame assembly 68 68... -
Page 74: Ac Assembly-Box
6.3.7 AC assembly-box 69 69... -
Page 75: Back Service-Door Assembly
6.3.8 Back service-door assembly 70 70... -
Page 76: Steering-Wheel And Lamp-Plate Assembly
6.3.9 Steering-wheel and lamp-plate assembly... -
Page 77: Control Panel Assembly (Chinese Version - Card Reader)
6.3.10 Control panel assembly (Chinese version - card reader) 72 72... -
Page 78: Control Panel Assembly (English Version - Digital Buttons)
6.3.11 Control panel assembly (English version - digital buttons) 73 73... -
Page 79: Pedal Assembly
6.3.12 Pedal assembly 74 74... -
Page 80: High-Pitched Sound Box Assembly
6.3.13 High-pitched sound box assembly 75 75... -
Page 81: Motor Assembly
6.3.14 Motor assembly. 76 76... -
Page 82: Bass Loudspeaker Assembly
6.3.15 Bass loudspeaker assembly 77 77... -
Page 83: Transformer Assembly
6.3.16 Transformer assembly 78 78... -
Page 84: Steering-Wheel Assembly
6.3.17 Steering-wheel assembly 79 79... -
Page 85: Base Assembly
6.4 Base assembly 80 80... -
Page 86: Base-Frame Assembly
6.4.1 Base-frame assembly. 81 81... -
Page 87: Lamp Base-Plate Assembly
6.4.2 Lamp base-plate assembly 82 82... -
Page 88: Ransformer Base-Plate Assembly
6.4.3 Ransformer base-plate assembly 83 83... -
Page 89: Left-Side Exhaust-Pipe Assembly
6.4.4 Left-side exhaust-pipe assembly 84 84... -
Page 90: Right-Side Exhaust-Pipe Assembly
6.4.5 Right-side exhaust-pipe assembly 85 85... -
Page 91: Fan Assembly
6.4.6 Fan assembly 86 86... -
Page 92: Light Box Assembly
6.5 Light box assembly 87 87... -
Page 93: Light-Box Frame Assembly
6.5.1 Light-box frame assembly. 88 88... -
Page 94: Light-Box Left-Side Assembly
6.5.2 Light-box left-side assembly 89 89... -
Page 95: Light-Box Right-Side Assembly
6.5.3 Light-box right-side assembly 90 90... -
Page 96: Card-Board Assembly
6.5.4 Card-board assembly 91 91... -
Page 97: Display Assembly
6.6 Display assembly 92 92... -
Page 98: Seat Assembly
6.7 Seat assembly 93 93... -
Page 99: Seat Frame Assembly
6.7.1 Seat frame assembly 94 94... -
Page 100: Seat-Cover Assembly
6.7.2 Seat-cover assembly 95 95... -
Page 101: Seat-Base Assembly
6.7.3 Seat-base assembly 96 96... - Page 102 6.7.4 Back-speaker assembly 97 97...
-
Page 103: Display Supportingg Frame
6.8 Display supportingg frame 98 98... -
Page 104: Printing Pattern
7. Printing Pattern 99 99... -
Page 106: Wiring Diagram
8. Wiring Diagram... - Page 107 COM21 5557-04R 250VA 变压器 VL4P 1100VA 变压器 红 红 红 AC10V AC110V 白 白 AC10V 白 马达板（1/2） AC70V AC220V AC110V 红 红 VL3P 红 FUSE 6A AC220V NOISE K4 VL4P 黄 棕 棕 棕 白 白 白 白 白 AC70V 白...
- Page 108 XH6P YL6P YL8P YL8P CON3 XH12P 红 红 2芯屏蔽线 芯线24＃ 测试 服务 DATA6 DATA6 XH6P YLR-06V 蓝 蓝 YL3P 白 白 CLK3 CLK3 绿 绿 紫 紫 YLP-08V 投币器、 红 红 LATCH LATCH 橙 橙 右侧灯板 黑 绿 绿 黑 黑...
-
Page 109: After-Sales Service
9. After-sales Service Honorable customer ！ Thank you for purchasing our product ！ For your benefits, if you find any fault during the operation of the product, please use a technician who obtains a certificate related to mechanical engineering, electrical engineering or who engages in routine maintenance, repair and management of amusement machine to check the machine and inform us the fault in a timely manner. - Page 110 The specifications and operation instructions in this Manual are subject to change without notice for reasons such as performance.
