IGS Pirate Falls Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Ver.2.00
For safety reasons, please read the manual first before plugging in machine.
Please keep this manual properly for convenient reference as needed.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pirate Falls and is the answer not in the manual?

Questions and answers

Related Manuals for IGS Pirate Falls

Summary of Contents for IGS Pirate Falls

  • Page 1 Ver.2.00 For safety reasons, please read the manual first before plugging in machine. Please keep this manual properly for convenient reference as needed.

  • Page 3: Table Of Contents

    Table of Contents About This Manual 1. Safety Precautions ..........1 1.1 Warning Stickers 1.2 Placing Site 1.3 Safety Precautions 1.4 Precaution during Play 1.5 Transporting and Moving 1.6 Installing and Placing 1.7 Caution & Warning Stickers 2. Product Description ..........2.1 Product Specification 2.2 Overview 2.3 Parts Name...
  • Page 4 5.1 Maintenance and service 5.2 Part Replacement 5.2.1 Replacement of light-bar on the side board 5.2.2 Replacement of light-bar on the light-box 5.2.3 Replacement of light-bar on control panel 5.2.4 Replacement of light-bar on the barrel 5.2.5 Replacement of the decorating light-bar 5.2.6 Replacement of button on the control panel 5.2.7 Replacement of the loudspeaker 5.2.8 Replacement of LCD...

  • Page 5: Safety Precautions

    1. Safety Precautions 1.1 Warning Stickers In order to avoid injury to related people and damage to property, please observe the followings: PLEASE READ FIRST PLEASE READ FIRST The following marks can be used to indicate the magnitudes of risk and damage caused by ignorance or improper operation: Warning Warning...

  • Page 6: Safety Precautions

    1.3 Safety Precautions This equipment has been tested and found to comply with the limits for a Class A of EN 55032. Operation of this equipment in a residential environment could cause radio interference. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Precaution During Play

    1.4 Precautions during Play 1.5 Transporting and moving...

  • Page 8: Installing And Placing

    1.6 Installing and Placing Warning Warning If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance...

  • Page 9: Caution & Warning Stickers

    1.7 Caution & Warning Stickers...

  • Page 10: Product Description

    2. Product Description 2.1 Product Specification Location Indoor Only Dimension 800(W)×1100(D)×2475(H) AC220V 50HZ /60HZ Rated Voltage、 Frequency AC110V 50HZ /60HZ Power Consumption 230W Weight 190kg * 110V voltage can be set through the transformer and fuse. Please contact the distributor for details. NOTE:The contents herein described are subject to change without notice.

  • Page 11: Overview

    2.2 Overview Side View Rear View Top View Bottom View...

  • Page 12: Parts Name

    2.3 Parts Name Light box pirate decorations Signboard arcylic Light box Game-machine frame Barrel assembly Loudspeaker Control panel Ticket door Coin door Upper access door Lower access door Filter...

  • Page 13: Shipment List

    2.4 Shipment List Packing Carton 1 PT-P0001E Signboard arcylic PMMA-5.0T 1.7.IG31B00120 PT-P0002E Light box pirate decorations PMMA-5.0T 1.7.IG31B00130 PT-9901E04 Cover Water resistance 2C 850g T - 7 1.9.ZX030016 PT-9901E03 Coaming Water resistance 2C 850g T - 7 1.9.ZX020019 Accessories box PT-9902000 Light-box assembly PT-9901E02...
  • Page 14 Light-box assembly PT-9902E01 POP packing carton 1.9.ZX010090 light-box assembly Draw No. Name Material/Spec. Qty. Product Code...

  • Page 15: Packing List

    2.5 Packing List Please check the following items after purchasing our product. If any part missing or damaged, please contact our sales person! Description Specification Quantity Remarks 5555 key Cross the big flat head M4*8（black） screw ad(advertisement) nail 19×50 (stainlesssteel ) Connector Q235 AC cable...

  • Page 16: Install Direction

    2.6 Install Direction Step 1 Take out the light box assembly, decorate the light box pirate with 3 advertisement snails fixed in the light box assembly, then take out the advertisement nail assembly from the attached product box, install in the light box to assemble the remaining 4 advertisement nails, and finally use the advertisement snail wire to hold the machine type of pressure fixed.

  • Page 17: Warranty

    2.7 Warranty Scope Inquiry regarding product can be assisted for free. The warranty scope for consumables and durables may differ from product to product. Please contact our after-sales service center for detailed information. The right of final interpretation is reserved. Exclusive Damage caused by force majeure such as god will.

  • Page 18: Game Description

    3. Game Description 3.1 Appearance Design Pirate Falls game-machine is a pirate-themed game machine. The game machine is designed very simply and elegantly. The game-machine is coated with blue paint, with 3D game characters to create the sea world. The light box is a layered-design part, which can make the pattern more distinctive.
  • Page 19 Rotate the cask and move the pirate to catch treasure in the box. 2.Introduction to the Main Game 1) Collect：Collect letters "PIRATES" and win the biggest prize. 2) Tickets：Accumulated prize. 3) Credits：Plays of Game.
  • Page 20 3.ICON Picture Name Instruction PIRATES Letters Catch and collect them all. Diamond Catch and win the prize. Catch and enter the BONUS game. Rocket Bonus Catch the shield and get the ability to Shield defend against the bomb once. Catch the bomb and game over. Bomb 4.Rocket Bonus 1) Rotate the cask and move the pirate to catch...

  • Page 21: Test And Setting

    4.Test and Setting 4.1 MENU NAVIGATION I/O Test Light Test Hardware Test Sound Test Payout Test Screen Test Game Setting Time Setting System Setting Password Check Main Menu Password Setting System Reset Daily Income Bookkeeping Monthly Income...

  • Page 22: Operating Mode Of Main Menu

    4.2 Main Menu 1.Press the Test Key on the Control Box to enter the Main Menu screen for configuration options. 2.Use the Cask and OK Button to operate. 3.Press the Select Key to move between options. Press the Confirm Key to select the option. 4.Select Exit after configuration to return to the game screen.

  • Page 23: Hardware Test

    4.3 Hardware Test Test the cabinet’s hardware devices. 1.Enter【Main Menu】＞【Hardware Test】 and you will see the screen shown as below： 2.Hardware Test includes the following items： 1)I/O Test: Test if the I/O feature and coin acceptor function normally. 2)Light Test: Test if the light functions normally. 3)Sound Test: Test if the music can be played normally.

  • Page 24: I/O Test

    4.3.1 I/O Test Test if the I/O feature and coin acceptor function normally. 1.Enter【Main Menu】＞【Hardware Test】＞ 【I/O Test】 and you will see the screen shown as below： 2.Use the Cask,OK Button,Test Key and Service Key to perform tests. 3.Exit:Rotate the Cask and Press the OK Button to exit.

  • Page 25: Sound Test

    4.3.3 Sound Test This is allowed to test sound output devices and make sure they function normally. 1.Enter【Main Menu】＞【Hardware Test】＞ 【Sound Test】and you will see the screen shown as below： 2.Rotate the Cask to change the options. Use the OK Button to switch the music number. 3.Exit:Rotate the Cask to choose the option and go back to the previous page.

  • Page 26: Screen Test

    4.Five tickets are dispensed during machine test. 5.If the menu can not be quit, the menu is as shown in the right figure： 6.For troubleshooting, please refer to Page 33 in this manual. 7.Exit:Rotate the Cask to choose the option and go back to the previous page.

  • Page 27: System Setting

    4.4 System Setting This is allowed to adjust various system settings. 1.Enter【Main Menu】＞【System Setting】and you will see the screen shown as below： 2.The following describes the details of System Settings： 1)Game Setting: This is allowed to adjust all the related game settings. 2)Time Setting: This is allowed to adjust the system time.

  • Page 28: Password Check

    4.4.1 Password Check Enter password first to enter the System Setting, The system's default password [00000000] 1.Enter【Enter Password】and you will see the screen shown as below： 2.Enter the wrong password screen as shown below, and then automatically return to the 【Main Menu】.

  • Page 29: Game Setting

    4.4.2 Game Setting To set up parameter regarding the game. 1.Enter【Main Menu】→【System Setting】→【Game Setting】Please see the below game setting. 2.List of setting and parameter: Item Available Range Default Free Play ON/OFF Coin Rate 1、2、3、4 Coins 1 Coin Ticket ON/OFF ON、OFF OFF、1、2、3、4、5、6、7、8、9、...
  • Page 30 Item Available Range Default Mercy Ticket 0、1、2、3、4、5 Tickets Game Volume Demo Volume ※When「Free Play」is ON, the function of ticket out will be closed (automatically clear the tickets). 3.Ticket On/Off Setting this to off will prevent the ticket dispenser from dispensing tickets. All other game features will remain the same, and the Score Ranking will be also listed on the screen.

  • Page 31: Time Setting

    4.4.3 Time Setting This is allowed to adjust the system time. 1.Enter【Main Menu】＞【System Settings】＞ 【Time Setting】and you will see the screen shown as below： 2.Rotate the Cask to select the column of options you like to modify. Press OK Button to adjust the numbers.
  • Page 32 4.Please enter the「New Password」. The 「New Password」will have to be entered again to check for accuracy. 5.When the「Enter New Password」and「Confirm New Password」 are verified, a notification message will appear stating「Password changed Please use this new password next time」. 6.When the「Enter New Password」and「Confirm New Password」do not match, a 「Wrong Password」message will appear.

  • Page 33: System Reset

    4.4.5 System Reset The is allowed to restore the system to its default value. 1.Enter【Main Menu】＞【System Setting】＞【System Reset】and you will see the screen shown as below： 2.The following is a description of the options for system reset: 1)Reset settings to factory defaults, but keep bookkeeping records. 2)Reset settings to factory defaults, and clear bookkeeping records.

  • Page 34: Bookkeeping

    4.5 Bookkeeping This provides related operation data for user inquiry. 1.Enter【Main Menu】＞【Bookkeeping】and you will see the screen shown as below： 2.The following describes the details of bookkeeping： 1)Daily Income:This provides daily income for user inquiry. 2)Monthly Income:This provides monthly income for user inquiry. 3.Exit:Rotate the Cask to choose the option and go back to the previous page.

  • Page 35: Daily Income

    4.5.1 Daily Income This provides daily income for user inquiry. 1.Enter【Main Menu】＞【Bookkeeping】＞【Daily Income】and you will see the screen shown as below： 2.Rotate the Cask can switch page and press the OK Button can exit this page. 3.Statement reports can keep data logs for the previous 90 days. The General Ledger can display up to 15 records, totaling 6 pages.

  • Page 36: Monthly Income

    4.5.2 Monthly Income This provides monthly income for user inquiry. 1.Enter【Main Menu】＞【Bookkeeping】＞【Monthly Income】and you will see the screen shown as below： 2.Rotate the Cask can switch page and press the OK Button can exit this page. 3.Statement reports can keep data logs for the previous 30 months. The General Ledger can display up to 15 records, totaling 2 page.

  • Page 37: Troubleshooting

    4.6 Troubleshooting Error status Message Icon Troubleshooting Instructions Please check if the ticket dispenser is jammed or out of tickets. Go to[Main Menu] > [Hardware Test] > TICKET ERROR [Payout Test] to test the ticket dispenser. If the test is non-responsive, please contact the local dealership to exchange the ticket dispenser for assistance.

  • Page 38: Maintenance And Service

    5. Maintenance and Service 5.1 Maintenance and service Even though the machine works normally for a long time, the fault will occur. Therefore, please perform routine check and maintenance concerning the following to ensure a long-term use. External Inspection Stick “Warning” stickers correctly, keep it legible. Firmly tighten the bolt for each adjuster.

  • Page 39: Part Replacement

    5.2 Part Replacement 5.2.1 Replacement of light-bar on the side board 1.Remove 11 screws from the side-board 2.Remove the screws on the side acryl assembly and remove the side-board and remove the side acryl to replace assembly; the light-bar. Reinstall in a reverse order after replacement.

  • Page 40: Replacement Of Light-Bar On Control Panel

    5.2.3 Replacement of light-bar on control panel 1.Remove 8 screws from the control panel and remove the control panel to replace the light-bar;Reinstall in a reverse order after replacement. Control-panel button assembly Light-bar. 5.2.4 Replacement of light-bar on the barrel 1.Remove 4 screws on the cover board, open the cover board and remove the corresponding screws to replace the light-bar;Reinstall in a reverse order after replacement.

  • Page 41: Replacement Of Button On The Control Panel

    5.2.6 Replacement of button on the control panel 1.Remove 8 screws from the control 2.Remove the button on the control panel panel and remove the control panel for replacing.Reinstall in a reverse order button assembly; after replacement. Control-panel button assembly Button 5.2.7 Replacement of the loudspeaker 1.Remove 4 screws from the loudspeaker mesh assembly to remove the loudspeaker...

  • Page 42: Replacement Of Lcd

    5.2.8 Replacement of LCD 1.Remove 4 screws from the upper access door and open the access door with the key. Unscrew the rubber-head screws and remove the light box. Light-box Upper access door 2.Remove the screws from the glass frame, remove the glass frame, and then remove the fixed screw at the back of LCD to replace LCD;Reinstall in a reverse order after replacement.

  • Page 43: Assembly

    6. Assembly 6.1 Assembly tree diagram PT-0101000 Wooden frame assembly PT-0102000 Left wooden-frame assembly PT-0103000 Right wooden-frame assembly PT-0100000 PT-0104000 LCD assembly Frame assembly PT-0105000 AC power-box assembly PT-0106000 Transformer assembly PT-0107000 Host assembly PT-0108000 Glass-frame assembly PT-0109000 Right loudspeaker mesh assembly PT-0110000 Left loudspeaker mesh assembly PT-0111000 Decorative light-bar assembly PT-0112000 Control-panel button assembly...

  • Page 44: General Assembly Drawing(Pt-0000000)

    6.2 General assembly drawing(PT-0000000)
  • Page 45 M6*35 Plactic screw 1.6.LSU63024 （Galvanization） Hex Socket Cap Screws M4*25（chrome） 1.6.LS142022 Hex Socket Cap Screws M4*30（Black） 1.6.LS143011 Hex head Cap Screw M4（Colour） 1.6.LM204013 Carriage Bolts M4*30（chrome） 1.6.LSP43012 Hex Socket Cap Screws M4*12（chrome） 1.6.LS141022 Hex Head Cap Screw(BS) M8*30（Black） 1.6.LSM83011 Spring washer M8（Black）...

  • Page 46: Frame Assembly(Pt-0100000)

    6.2.1 Frame assembly(PT-0100000)
  • Page 47 M8*30（Black） 1.6.LSM83011 Hex Head Cap Screw(BS) φ8*φ16*2.0（Black） 1.6.DP108011 Plain washers M8*40（Black） 1.6.LSM84011 Hex Head Cap Screw(BS) M8（Black） 1.6.DP208011 Spring washer φ8*φ22*2.0（Black） 1.6.DP108031 Plain washers Control-panel button 23 PT-0112000 assembly 22 PT-0111000 Decorative light-bar assembly 21 PT-0100D02 Console Side acryl B PMMA-15.0T 1.7.IG31A00020 20 PT-0100D01...
  • Page 48 43 PT-0100A05S Stencil-1.0T Power box cover 42 PT-0100A04S AC box cover Stencil-1.0T M4*35(chrome) 1.6.LS143022 Hex Socket Cap Screws Cross recessed countersunk M4*30(chrome) 1.6.LSC43012 head screws Hex Socket Cap Screws M8*50(Black) 1.6.LS185011 M4*16（chrome） 1.6.LS141032 Hex Socket Cap Screws M5*12（Black） 1.6.LS251021 Cross the big flat head screw M4*30（Black）...

  • Page 49: Wooden Frame Assembly(Pt-0101000)

    6.2.1.1 Wooden frame assembly(PT-0101000) 16 16 16 Hexagon nuts M16（Colour） 1.6.LM116013 Hex Head Cap Screw(BS) M6*30（Black） 1.6.LSM63011 Spring washer M6（Black） 1.6.DP206011 φ6*φ12*2.0 Plain washers 1.6.DP106021 （Black） Casters 2.5" 1.4.JL302520 M16*Y100 LEG Adjuster 1.6.LSV99013 （Colour） WAH-0000A06 M16 anchor nut of fixed iron 1 SPCC-2.0T 1.1.AA09000010 2.5"...

  • Page 50: Left Wooden-Frame Assembly(Pt-0102000)

    6.2.1.2 Left wooden-frame assembly(PT-0102000) Hex Socket Cap Screws M4*25（chrome） 10 1.6.LS142022 Cross the big flat head screw M6*12（Black） 10 1.6.LS261021 PT-0102D04 Side acryl D PMMA-15.0T 1.7.IG31A00060 PT-0102D03 Side acryl C PMMA-15.0T 1.7.IG31A00050 PT-0102D02 Side acryl B PMMA-15.0T 1.7.IG31A00040 PT-0102D01 Side acryl A PMMA-15.0T 1.7.IG31A00030 UYG-0102A02...

  • Page 51: Right Wooden-Frame Assembly(Pt-0103000)

    6.2.1.3 Right wooden-frame assembly(PT-0103000) Hex Socket Cap Screws M4*25（chrome） 10 1.6.LS142022 Cross the big flat head screw M6*12（Black） 10 1.6.LS261021 PT-0103D04 Side acryl H PMMA-15.0T 1.7.IG31A00100 PT-0103D03 Side acryl G PMMA-15.0T 1.7.IG31A00090 PT-0103D02 Side acryl F PMMA-15.0T 1.7.IG31A00080 PT-0103D01 Side acryl E PMMA-15.0T 1.7.IG31A00070 UYG-0102A01...

  • Page 52: Lcd Assembly(Pt-0104000)

    6.2.1.4 LCD assembly(PT-0104000) cross recessed fillister head M6*16（chrome） 1.6.LS861032 three-combination screw PT-0104A02 LCD bracket B 1.1.IG31A00060 PT-0104A01 LCD bracket A 1.1.IG31A00050 LED(47 inch led with frame) 1.4.XS404740 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 53: Ac Power-Box Assembly(Pt-0105000)

    6.2.1.5 AC power-box assembly(PT-0105000) Hex head Cap Screw M4（Colour） 1.6.LM204013 Cross the big flat head screw M3*8（Black） 1.6.LS230081 Filter with switch YB11C1-10A-Q 1.4.LB100090 PT-0105A01 AC Power Box SPCC-1.2T 1.1.IG31A00070 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 54: Host Assembly(Pt-0107000)

    6.2.1.6 Host assembly(PT-0107000) cross recessed fillister head M6*12（chrome） 1.6.LS861022 three-combination screw cross recessed fillister head M5*16（chrome） 1.6.LS851032 three-combination screw PT-0107000A Host(English) 2.1.IG31B010# Lanhe shaped foot shock 1.8.AA000250 Main pc set mounted wooden PT-0107B01 MDF-15.0T 1.2.IG31A00050 plate Draw No. Name Material/Spec. Qty.

  • Page 55: Pirate Treasure House(Pt-0107000A)

    6.2.1.6.1 Pirate treasure house(PT-0107000A) cross recessed fillister head M3*8（Black） 1.6.LS830021 three-combination screw The main board 1.3.IG31A00010# MH-0000000 The case 2.1.AA030200 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 56: Glass-Frame Assembly(Pt-0108000)

    6.2.1.7 Glass-frame assembly(PT-0108000) Hex head Cap Screw M4（Colour） 18 1.6.LM204013 PT-0108A02 Glass plate SECC-1.5T 1.1.IG31A00100 WAH-0000C07 47-inch LED glass A Glass-5.0T 1.8.AA030070 PT-0108A01 Glass frame SPCC-1.2T 1.1.IG31A00090 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 57: Right Loudspeaker Mesh Assembly(Pt-0109000)

    6.2.1.8 Right loudspeaker mesh assembly(PT-0109000) PT-P0004 Right side horn PMMA-5.0T 1.7.IG31A00150 Hex head Cap Screw M4（Colour） 1.6.LM204013 PT-0109A01 Horn cover 1.1.IG31A00110 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 58: Left Loudspeaker Mesh Assembly(Pt-0110000)

    6.2.1.9 Left loudspeaker mesh assembly(PT-0110000) PT-P0005 Left side horn PMMA-5.0T 1.7.IG31A00160 Hex head Cap Screw M4（Colour） 1.6.LM204013 PT-0109A01 Horn cover 1.1.IG31A00110 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 59: Decorative Light-Bar Assembly(Pt-0111000)

    6.2.1.10 Decorative light-bar assembly(PT-0111000) DC12V White 60 5050 strip light 1.4.ZM9E0515 Lamp L=350mm PT-0100A01 Article lamp bracket SPCC-1.0T 1.1.IG31A00020 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 60: Control-Panel Button Assembly(Pt-0112000)

    6.2.1.11 Control-panel button assembly(PT-0112000) 12V White Three LED lamp for button 1.4.AJA01040 lights (T103W-12V- SMD) Micro switch D3V-01-1C23 1.4.SW103011 Round push button with led BLC-BL-BK-H-CW- 1.4.AJ350015 lamp D(White) PT-P0006E Key base cover PMMA-5.0T 1.7.IG31A00170 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 61: Barrel Assembly(Pt-0200000)

    6.2.2 Barrel assembly(PT-0200000) 16 PT-P0007 Bucket stick PVC-0.2T 1.7.IG31A00180 Hex Head Cap Screw(BS) M8*20（Black） 1.6.LSM82011 Spring washer M8（Black） 1.6.DP208011 Hex Socket Cap Screws M4*12（chrome） 1.6.LS141022 cross recessed fillister head M4*8（Black） 1.6.LS840021 three-combination screw cross recessed fillister head M6*12（Black） 1.6.LS861021 three-combination screw Socket Set Screw M4*4（chrome）...

  • Page 62: 1 Bearing Assembly(Pt-0201000)

    6.2.2.1 No.1 bearing assembly(PT-0201000) Cross recessed cheese head M4*10（Black） 1.6.LS741011 screws cross recessed fillister head M6*16（Black） 1.6.LS861031 three-combination screw PT-0201A03 Tooth slice Q235 1.1.IG31A00180 Bearing pedestal 6006zz 1.4.ZC000030 PT-0201A02 Bearing block A Q235 1.1.IG31A00170 PT-0201A01 Bearing hardware A SPCC-2.5T 1.1.IG31A00160 Draw No.

  • Page 63: 2 Bearing Assembly(Pt-0202000)

    6.2.2.2 No.2 bearing assembly(PT-0202000) cross recessed fillister head M6*16（Black） 1.6.LS861031 three-combination screw Bearing pedestal 6005zz 1.4.ZC000040 PT-0202A02 Bearing block B Q235 1.1.IG31A00200 PT-0202A01 Bearing hardware B SPCC-2.5T 1.1.IG31A00190 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 64: Sensor Assembly(Pt-0203000)

    6.2.2.3 Sensor assembly(PT-0203000) 12 PT-0203A05 Bearing plate SECC-1.2T 1.1.IG31A00250 Hex head Cap Screw M3（Colour） 1.6.LM203013 Cross the big flat head screw M3*8（Black） 1.6.LS230081 Hex head Cap Screw M4（Colour） 1.6.LM204013 PT-0203A02 Inductor shaft Q235 1.1.IG31A00220 PT-0203A04 Gear Q235 1.1.IG31A00240 Socket Set Screw M4*4（chrome）...

  • Page 65: Light Box Assembly(Pt-0300000)

    6.2.3 Light box assembly(PT-0300000) 11 PT-0300A02 Connector Q235 1.1.IG31A00270 10 PT-P0001E Signboard arcylic PMMA-5.0T 1.7.IG31B00120 PT-P0002E Light box pirate decorations PMMA-5.0T 1.7.IG31B00130 Hex head Cap Screw M4（Colour） 1.6.LM204013 DC12V White 5050 strip light 1.4.ZM9E0026 60lamp L=300mm DC12V White 5050 strip light 1.4.ZM9E0605 60lamp L=550mm Cross the big flat head screw M4*8（Black）...

  • Page 66: Ticket-Door Assembly(Pt-0400000)

    6.2.4 Ticket-door assembly(PT-0400000) UYG-0400A05 Lottery door limit hardware B SECC-1.5T 1.1.IG26C00310 UYG-0400A04 Lottery door limit hardware A SECC-1.5T 1.1.IG26C00300 Cross the big flat head screw M3*8（chrome） 1.6.LS230032 Hex head Cap Screw M4（Colour） 1.6.LM204013 Curved skew baffle lock plate （NO.001） 1.4.SJ500060 Lock 5555S 1.4.SJ120110...

  • Page 67: Control Panel Assembly(Pt-0500000)

    6.2.5 Control panel assembly(PT-0500000) cross recessed fillister head M3*8（chrome） 1.6.LS830022 three-combination screw Hex head Cap Screw M3（Colour） 1.6.LM203013 Hex head Cap Screw M4（Colour） 1.6.LM204013 RED SDP-103C- Sanwa sdp-103c-22rb 1.4.AJ500012# 22RB Rocker switch 4P KCD7-2211N 1.4.SW604010 Amplifier 0989_00_KG_D-VR 1.4.GF100024 Electronic double show DC5-24V 7 G037 1.4.JS100040 counter (reset）...

  • Page 68: Lower Access Door Assembly(Pt-0600000)

    6.2.6 Lower access door assembly(PT-0600000) Flat baffle lock plate 1.4.SJ500010 5cm(NO.004） Lock 5555Lock-K 1.4.SJ120120 PT-0600B01 Lower maintenance door MDF-15.0T 1.2.IG31A00060 Draw No. Name Material/Spec. Qty. Product Code...

  • Page 69: Upper Access Door Assembly(Pt-0700000)

    6.2.7 Upper access door assembly(PT-0700000) Hex head Cap Screw M4（Colour） 1.6.LM204013 Cross recessed cheese head M4*70（chrome） 1.6.LS747012 screws Flat baffle lock plate 5cm(004) 1.4.SJ500010 Lock 5555Lock-K 1.4.SJ120120 Fan cover 120*120 1.4.FS300020 Fan with bearing 120*120/AC110V 1.4.FS200042 PT-0700B01 Upper maintenance door MDF-15.0T 1.2.IG31A00070 Draw No.

  • Page 70: Printing Pattern

    7. Printing Pattern...

  • Page 71: Wiring Diagram

    8. Wiring Diagram...
  • Page 72 This diagram shows: GN/YL AWG16 OTHER COLOR AWG18 AWGXX AWGXX COIN METER COM WIDE LINE: PT-L0012 12VDC NARROW LINE: ALL COLOR AWG22 AWGXX AWGXX 5050 Strip Light The wiring diagram for reference only, change without prior notice DC12V WT 60 L=550mm PT-L0031 A2545-50P(2/2) CON8...
  • Page 74 - SEGA TOTAL SOLUTIONS - 42 Barwell Business Park Leatherhead Road, Chessington, Surrey, KT9 2NY United Kingdom Parts/Customer Service : +44 (0) 208 391 8060 Technical Support : +44 (0) 208 391 8072 - PLAY IT AMUSEMENTS - 252 Beinoris Drive, Wood Dale, 60191, United States of America...
  • Page 75 PT-P0022S Ver. 2.00 The specifications and operation instructions in this Manual are subject to change without notice for reasons such as performance.
