Summary of Contents for IGS DIGGIN' DEEP

  • Page 3: Table Of Contents

    Table of Contents 1. Hardware ..................2 Hardware Connection ..................2 Connecting Touch Panel (Optional) ............... 3 Connection Diagram ..................4 DIP Switch Settings ..................5 36 & 10 PIN Button Layout ................7 Solving Ticket SSR Error ................7 Reset ......................

  • Page 4: Hardware

    1. Hardware Hardware Connection 10-Pin Connector SD Card Slot 36-Pin Connector Audio Jack COM 1. RS-232 Connects to optional Citizen printer/ticket dispenser. * Use Belkin #F2L044 (serial printer cable/null modem) for Citizen printer. DIP Sw 2 COM 3. RS-232 Connects to Bill Acceptor DIP Sw 1 VGA port Connects to screen...

  • Page 5: Connecting Touch Panel (Optional)

    Connecting Touch Panel (Optional) Type A Power +5V Connector Monitor Connector (Female) (15PIN Female)  Refer to the diagram below to connect the touch screen.  After the connection, remember to adjust the Pin 1 of DIP SW2 to ON to enable touch mode.

  • Page 6: Connection Diagram

    Connection Diagram 36 Pins (6 Buttons) 10 Pins (6 Buttons) SOLDER SIDE PARTS SIDE SOLDER SIDE PARTS SIDE SPEAKER_R SPEAKER_L +12V +12V HOP-VCC TICKET OUT TICKET SSR TICKET SWITCH START / ALL STOP STOP4/SMALL/HELP STOP5/BET STOP1/TAKE STOP3/DOUBLE/SELECT LINE STOP2/BIG/HOLD PAIR COIN A KEY IN COIN C...

  • Page 7: Dip Switch Settings

    DIP Switch Settings DIP SWITCH 1 SLAVE ID SINGLE LINK MODE LINK...
  • Page 8 DIP SWITCH 2 TOUCH PLUSE BILL ACCEPTOR MODE RS232 25 LINE LINE MODE 9 LINE Remark: Please reset after adjusting LINK MODE or LINE MODE.

  • Page 9: 10 Pin Button Layout

    36 & 10 PIN Button Layout 6 Button START TAKE DOUBLE SMALL ALL STOP STOP1 STOP 2 STOP 3 STOP 4 STOP 5 TAKE (HOLD) (SELECT (HELP) LINE) Solving Ticket SSR Error After powering on the machine, if the ticket dispenser keeps working and can’t be stopped, it could be that the Ticket SSR’s jump setting is incorrect.

  • Page 10: Reset

    Reset Power off the machine and then power on. Press and hold the 【 TEST 】 button until the game enters the CHECKING SYSTEM page. Enter the 「 TEST 」 page. Press the 【 BET 】 button to enter the 「 TEST 2 」 PAGE (PAGE 2).
  • Page 11 Press the 【 STOP3 】 button to enter the 「 RESET 」 page. Press the 【 BET 】 button to RESET the game to default value.
  • Page 12 Press the 【 BET 】 button again to confirm RESET or press ANY button to EXIT. After RESET is completed, it displays SYSTEM RESET COMPLETED on the screen. Power off the machine and then power on to complete the Reset procedure.

  • Page 13: Bookkeeping & Adjustment

    2. Bookkeeping & Adjustment Access Flow Chart [RECORD] [STOP2] [STOP3] [STOP4] LAST HAND SHORT-TERM SYSTEM LAST CURRENT Enter DATA DATA Password Default password: Press [START] 8 times [STOP3] [STOP2] DOUBLE GAME MAIN GAME [STOP1] [STOP2] [STOP3] [STOP4] INTERFACE MAIN GAME DOUBLE GAME ADJUSTMENT [STOP2]...

  • Page 14: System Settings (9 Lines)

    System Settings (9 LINES) ITEMS SETTING SELECTION DEFAULT MAX. LINE BET 5, 10, 20, 30, 40, 50 1, 5, 7, 9, 10, 15, 18, 20, 25, 27, 36, 45, 50, 72, MIN. BET (TOTAL) 75, 90, 100, 125, 144, 150 1, 5, 9, 10, 15, 18, 20, 25, 36, 45, 75, 90, 100, MIN.

  • Page 15: System Settings (25 Lines)

    System Settings (25 LINES) ITEMS SETTING SELECTION DEFAULT MAX. LINE BET 2, 4, 8, 10, 12, 15, 20 1, 5, 7, 9, 10, 15, 18, 20, 25, 27, 36, 45, 50, 72, MIN. BET (TOTAL) 75, 90, 100, 125, 144, 150 1, 5, 9, 10, 15, 18, 20, 25, 36, 45, 75, 90, 100, MIN.

  • Page 16: Chance Settings

    Chance Settings ITEMS SETTING SELECTION DEFAULT LEVEL1(Easiest), LEVEL2,LEVEL3, MAIN GAME LEVEL LEVEL 6 LEVEL4,LEVEL5,LEVEL6(Hardest) DOUBLE GAME LEVEL 85%, 90%, 95% Touch Screen Calibration 1. If a touch screen is connected, press [RECORD]> [SYSTEM]>[INTERFACE]> [TOUCH] and follow the on-screen prompts to enter the calibration screen.

  • Page 17: Introduction

    3. Introduction Features  9/25 Lines.  Win paid from left to right and right to left to increase the winning possibility.  Max. Win up to 500,000.  Touch screen / Auto play support.  Hold Pair Feature: When there is no win in a game, a player can press Hold Pair button to keep the desired symbol and then re-spin again with the same played amount.
  • Page 18 Minecart Feature Game  In Main Game, the minecart is only activated in 1st, 3rd, and 5th reel.  appears, will win the prize shown on the minecart.

  • Page 19: Scatter Game

    Scatter Game  symbols can trigger the Scatter Game.  Player can select to play Bonus Game or Free Game.

  • Page 20: Bonus Game

    Bonus Game  The game ends when the warning sign is picked.  First, the player will pick 3 gems in the mine.  These 3 mines have different multipliers.  Then, the minecart will deliver 1 more gem, which is the average of the 3 multipliers.

  • Page 21: Free Game

    Free Game  During Free Game, the minecart will be activated for all reels to increase the winning chance.  appears, the player will win the prize which the minecart carries.

  • Page 22: Double Game

    Double Game  After winning in a game, a player can press [DOUBLE] button to play Double Game.  Press [START] button to select  Double your wins if your guess is correct. The game ends if your guess is wrong.

  • Page 23: Win Rules

    4. Win Rules Encouraging Higher Play MIN. BET JACKPOT 100% Odds Table 9 LINES...

  • Page 24: Lines

    25 LINES...

  • Page 25: Line Chart

    Line Chart 9 LINES 25 LINES...
  • Page 26 S102US...
