- Page 1 User instructions WAREMA slat roof Lamaxa L60/L70 Original instructions To be handed over to the opera- tor. Please keep for future use. Valid from 11 October 2021 Document number 2029839 [Rev. 9 - en]...
-
Page 2: Table Of Contents
Table of contents Table of contents Introduction........................3 Information on safety............................ 3 Information on the target group and application of these instructions............3 Explanation of the signal words........................3 Basic safety instructions..........................3 Product information......................5 Intended use..............................5 Parts description............................6 Electrical data............................... -
Page 3: Introduction
The instructions contain important information on the Possible risk during operation operation, care and maintenance of this item. They describe how to operate products with WAREMA standard Incorrect operation can result in personal injury. The drives. Other drives and special solutions are not dealt with. - Page 4 Introduction Operation in the event of a power supply failure Access to the radiant heater (if present) An electrically-operated product cannot be operated without The radiant heater is not intended for children. Children power. A lowered/extended product may be subjected to are unable to recognize the danger posed by the product.
-
Page 5: Product Information
Raindrops can enter the interior under the following malfunction. circumstances. Remove leaves and other foreign objects from the Heavier rain events than examined by WAREMA. beams, the inspection openings for the integrated When the slats are opened after a downpour. awnings and the awning fabrics. -
Page 6: Parts Description
Additional loads on the product in the form of hanging objects or guy ropes could damage the product or cause it to become detached from the wall and are therefore not permitted. WAREMA will not be liable for any ensuing damage. The intended use also includes observing these instructions and adhering to the service requirements they describe. -
Page 7: Wind Resistance Slat Roof
Product information Data for electric drive of integrated awning with Data for ZigBee RGB Dimmer smart (if present) easyZIP guidance (if present) Parameter ZigBee RGB Dim- Parameter Value mer smart 150 W Current consumption [A] 0.45-0.9 A Operating voltage [V AC] 200-240 Rated voltage 230 V/50 Hz Frequency [Hz]... -
Page 8: Wind Resistance Integrated Awning With Easyzip Guidance (Optional)
Resistance against water collection (slat In winds over 48 m/s, the slats must be closed. With the roof) slats closed, the WAREMA slat roof is designed for a wind load of 1.1 kN/m². The product fulfils performance class 2 in accordance with DIN EN 13561. -
Page 9: Key Assignment Of Slat Roof Hand-Held Transmitter(Individual Unit)
Operation Key assignment of slat roof hand-held transmitter(individual unit) Equipment Number of channels Drive – tilting (L60) slat roof/tilting and moving (L70) slat roof 1-channel Direct LED lighting in beam (optional) 1-channel Indirect LED lighting in beam (optional) 1-channel LED lighting in pole (1–4 fields) (optional) 1-channel Radiant heater field 1 (optional) 1-channel... - Page 10 Operation WMS Hand-held transmitter comfort Channel Assignment (standard) Assignment (customer-specific) drive Tab. 8: Standard assignment of WMS Hand-held transmitter comfort product button for external venetian blind (setting made at the factory) Channel Assignment (standard) Assignment (customer-specific) LED beam direct LED beam indirect LED pole Radiant heater field 1 Radiant heater field 3...
-
Page 11: Key Assignment Of Slat Roof Hand-Held Transmitter (Line)
Operation Key assignment of slat roof hand-held transmitter (LINE) Equipment Number of channels Drive – tilting (L60) slat roof/tilting and moving (L70) slat roof 1-channel Direct LED lighting in beam (optional) 1-channel Indirect LED lighting in beam (optional) 1-channel LED lighting in pole (1–4 fields) (optional) 1-channel Radiant heater field 1 (optional) 1-channel... - Page 12 Operation WMS Hand-held transmitter comfort Channel Assignment (standard) Assignment (customer-specific) Drive A1 Drive A2 or B1 Drive group A1 and A2 or A1 and B1 Tab. 11: Standard assignment of WMS Hand-held transmitter comfort product button for external venetian blind (setting made at the factory) A group is only formed if both units are executed as L60 or L70.
-
Page 13: Operating The Slat Roof With The Wms Hand-Held Transmitter
Operation Channel Assignment (standard) Assignment (customer-specific) Awning Direction Awning Direction Awning Direction Awning Direction Awning Direction Awning Direction Awning Direction Awning Direction Awning Direction Awning Direction Tab. 13: Standard assignment of WMS Hand-held transmitter comfort product button for awning (setting made at the factory) Enter the number of the channel. - Page 14 Operation Slat roof L60 INFO Select the right channel for the product on the hand-held transmitter. The exact description of the hand-held transmitter can be found in the accompanying instructions for the hand-held transmitter. Turn the slats step-wise into the selected direc- Press the DOWN button briefly.
- Page 15 Operation Slat roof L70 INFO The tilting process in slat roof L70 is executed after the product is fully extended (lower limit position). The motors interlock mutually, which prevents product damage from occurring. As soon as the slats are fully extended, the slats can be tilted or are tilted automatically.
-
Page 16: Operating The Integrated Awning With Easyzip Guidance With Wms Hand-Held Transmitter (If Present)
Operation Operating the integrated awning with easyZIP guidance with WMS Hand-held transmitter (if present) CAUTION Risk of crushing from failure to exercise care during operation. Persons who are located within the projection area may be injured. Keep the path of the product clear of people. Keep children away from the operating elements. - Page 17 In the winter months, the control function must be deactivated (only possible using WMS WebControl pro, the app or the browser). The end customer is fully responsible for compliance with the use conditions stipulated by WAREMA. The wind speed limit has top priority. If the slat roof is also covered in snow, the snow may need to be cleared off of the roof.
-
Page 18: Operating The Led Strip With The Wms Hand-Held Transmitter
Operation Operating the LED strip with the WMS Hand-held transmitter INFO Select the right channel for the product on the hand- held transmitter. The exact description of the hand-held transmitter can be found in the accompanying instructions for the hand-held transmitter. Press the UP button briefly. -
Page 19: Operating The Radiant Heater With The Wms Hand-Held Transmitter (If Available)
Operation Operating the radiant heater with the WMS Hand-held transmitter (if available) CAUTION Risk of burns on hot surfaces! The surfaces of the product are a burn hazard while the product is in use and after it has been switched off. -
Page 20: Incorrect Operation
Operation Incorrect operation Operation during a storm Slat roof: Accessibility of the operating elements Never let children play with the operating elements of The product must be closed the product, such as the hand-held transmitter or switch. by hand before a bad weather front passes over, Keep the hand-held transmitter out of reach of children. - Page 21 Operation Operation in wet weather Cleaning the drainage INFO Slat roof: If the drainage gutter is installed without an inclination, it must be inspected and cleaned more Close the slats of the frequently. product in rain. Drainage gutters and drains may clog with leaves, moss and dirt.
-
Page 22: Service
WAREMA void. To enhance the durability of the sun shading product, its surfaces should be cleaned regularly or at least once a Proper and regular cleaning and maintenance and the year. - Page 23 Bucket Tip/recommendation Low-calcium water (recommendation) Using the WAREMA cleaning glove together with WAREMA cleaning agent for sun shading products (do WAREMA cleaning agent concentrate for sun not use on wood products) shading products is an ideal way to properly clean WAREMA cleaning glove product surfaces.
- Page 24 Remove any loose soiling from Prepare a bucket with water the entire product (e. g. dust, and WAREMA cleaning agent leaves). A whisk broom or for sun shading products. vacuum cleaner can be used for Note the dosing quantities this.
- Page 25 Service Drying the product Cleaning the drain INFO extend the product into the lower limit position. If the drainage gutter is installed without an inclination, it must be inspected and cleaned more Open and close the slats to frequently. allow the water to drip off.
-
Page 26: Maintenance
Cleaning the weather station (if available) INFO To ensure proper functioning and your continued INFO enjoyment of the product, WAREMA recommends The weather station must be cleaned every three professional maintenance. months to ensure the measured values are accurate and ensure operating safety and reliability. -
Page 27: Repair
INFO To ensure that your product continues to function properly, and to prevent the loss of its approved status, only use original spare parts. To order, contact your WAREMA dealer. 4.3.1 Exchanging the heating element (only basic radiant heaters) De-energise the radiant heater before performing any work on it. -
Page 28: Wear Parts
"faults". Dismantling of the product must be undertaken by The blemishes described below have no influence on a qualified specialist. Ask WAREMA for any missing the usability and durability of the awning fabric [excerpt documents before commencing maintenance. from the Guideline for the Evaluation of Preassembled Awning Fabrics –... - Page 29 Dismantling WARNING Electric shock! When working in the immediate vicinity of potentially live parts, such as electrical lines, contact may result in an electric shock. De-energise the product and secure it against being switched on again. Disposal Should the product no longer be required, ensure that it is disposed of correctly in accordance with the relevant regulations.
-
Page 30: Troubleshooting
Troubleshooting Troubleshooting INFO Problems described here without reference to a qualified specialist or certified electrician may be resolved independently. All other problems listed must be handled by a qualified specialist or certified electrician. Fault: The motor is not functioning Cause Remedy Note The thermal protection switch on the... -
Page 31: Ec Declaration Of Conformity Slat Roof
EC Declaration of Conformity Slat roof The product: WAREMA slat roof Type: Lamaxa L60 Lamaxa L70 Lamaxa L60 Free Lamaxa L70 Free Lamaxa L50 Purpose: External sun shading system Meets the provisions of Machinery Directive 2006/42/EC in the case of motor drives. -
Page 32: Ec Declaration Of Conformity Integrated Awning With Easyzip Guidance
EC Declaration of Conformity Integrated awning with easyZIP guidance The product type: WAREMA window awnings (window/facade outside) Product line: Front-mounted awning Front-mounted awning Pure with easyZIP guidance Awning window system Top-mounted awning for new buildings Integrated awning with easyZIP guidance...
