Matrox Rainbow Runner Studio Installation & User Manual page 7

Attach Rainbow Runner Studio to
2
your Matrox graphics card
Position the Rainbow Runner Studio
a
add-on card over the Matrox graphics card
so the connectors line up.
WARNING: If the cards are not
properly aligned, they could be
damaged when combined.
Press the two cards together slowly and
b
evenly until the connectors meet
(connection
3
Visually inspect your combined card from
c
each edge to make sure there's no (or very
little) space between connectors
and (The Millennium II card doesn't
4.
have connector
Install your combined card
3
Position the card over the slot you
a
removed it from. (If you're installing your
Matrox graphics card for the first time, see
its Installation Guide.)
Push the card firmly and evenly into the
b
slot until it's fully seated. Secure the
bracket of the card with the screw you
removed earlier.
If you've purchased the Matrox Rainbow
c
Runner TV card, connect it to Rainbow
Runner Studio (see Matrox Rainbow
Runner TV – Installation Guide).
d Put your computer's cover back on. (If you
have a Millennium II AGP card,
first.)
may not completely join).
,
1 2
.)
4
see step 4
Matrox Rainbow Runner Studio – Installation & User Guide
2
Matrox
graphics card
,
Matrox graphics /
Rainbow Runner
Studio card
Rainbow Runner Studio
add-on card
(Mystique only)
1
4
3
7
