Summary of Contents for Simpli Home WyndenHall brooklin+max AXCMON-03
-
Page 5: Part Description
PART DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF BACK PANEL DRAWER FRONT QTY 1 QTY 1 QTY 1 LEFT DRAWER SIDE RIGHT DRAWER SIDE DRAWER BACK QTY 1 QTY 1 QTY1 DRAWER BOTTOM QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. -
Page 6: Hardware Description
HARDWARE DESCRIPTION DOWEL ALLEN KEY BOLT 8 X 25mm M6 X 30mm ALLEN KEY QTY 14 QTY 1 QTY 8 ALLEN KEY SCREW M6 X 30mm QTY 4 Required - Flathead screwdriver Phillips screwdriver Rubber mallet Not Included NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. - Page 8 1. Attach 4 Cam Lock Pins 5 to pre-drilled holes at back of Drawer Front E . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides FL , FR . 3. Insert 2 Cam Locks 5 into pre-drilled holes on each Drawer Side FL , FR . 4.
- Page 9 1. Align Drawer Back G with Drawer Bottom H and press firmly into slot. 2. Attach Drawer Back G using 2 Allen Key Screws 4 through pre-drilled holes on each Side FL , FR . 3. Use Allen Key 2 to tighten screws. Do not over-tighten.
-
Page 15: Warranty
WARRANTY...
