- Page 1 OPERATING MANUAL MODEL 1670 WATER WHEEL TRANSPLANTER...
- Page 2 Table Of Contents Axle, Tire..............3 Features ..............13 Foot Rest ..............4 Hand Wheel ............. 4 Helpful Tips ............14 Options ..............13 Parts Breakdown, Description ......10-12 Parts Breakdown, Exploded Views .......6-9 Planter Seat ............. 4 Planting Wheel ............3 Safety First ..............
-
Page 3: Safety First
Do not add chemicals to water tank unless planters wear hand protection. Planter operators must keep their feet on foot rest when planting. Tractor operator is responsible for extra worker(s) around machine. Rain-Flo Irrigation is not responsible for accidents if any should occur. - Page 4 PLANTING WHEEL ADJUSTMENTS S.S. Axle Shaft Collar Plumbing Valve Water Shut-Off Handle (S.S. Axle Shaft) To hold planting wheels and plumbing. (Collars-2) To hold position of plumbing valves. (Plumbing Valves) To adjust water flow. (Water Shut-Off Handle) To shut off water supply. One to four planting wheels can be used at a time;...
-
Page 5: Seat Adjustments
SEAT ADJUSTMENTS To adjust foot rest, loosen tee handle(A) and slide foot rest to de- sired place. Turn handles(B) to adjust seat height and handle(C) to adjust seat’s “left-to-right” position for maximum comfort. nstallIng rd and eats Seat with heavy bar needs to be mounted toward the front and the seat with light bar to the back. - Page 6 OPTIONAL SUPER WHEEL The super wheel is a very universal planting wheel. Spike size and spacing can be changed as preferred. A rubber grommet is used to close unused holes. Note; lock pin is used in heavy or rocky soil conditions to avoid spike detaching.
- Page 11 308.........Frame 309....(2) ....½” Quick Pin 309A ...(2) ....Safety Pin for ½” Quick Pin 310....(2) ....Support Stand 311 ....(2) ....Model 1670 Label 312.........Seat Adjustment Label 313.....(50) .....¼” x ¾” Zinc Elevator Bolt 314....(2) ....Top Expanded Metal [20” x 43”] 314A ...(2) ....Bottom Expanded Metal [20” x 55”] 316....(2) ....2”...
- Page 12 Model 1670 Transplanter esCrIptIon 328C ......Complete Valve Assembly 328D ......Valve Spring 328H ......Water Shut Off Handle 330....(2) ....Axle Stem 331....(2) ....Seal 332....(4) ....Tapered Bearing 333....(2) ....Metal Hub 334....(2) ....¾” SAE Washer 336....(2) ....¾” Fine Thread Lock Nut 337....(2) ....Cap 338....(2) ....20.5 x 8.0 - 10 Tire & Rim 339.....(10) .....½”...
- Page 13 Model 1670 Transplanter esCrIptIon 382.........⅜” Hydraulic Ball Valve 383.........1” x 5” Bolt 384.........Draw Bar Tongue 384A ......Trailer Kit Complete 385.........⅜” x 99” Hydraulic Hose 386.........⅜” x 106” Hydraulic Hose 387.........3rd and 4th Seat Top Tray 388....(2) ....Hub Complete 389....(2) ....Tire Assembly Complete 390.........Top Tray Complete (Includes Brackets)
-
Page 14: Warranty
Features • Capability of 8” to 36” Row Spacing and One to Four Planting Wheels. (Standard) • Four Slanted Galvanized Expanded Metal Trays • Specialty Designed Tanks so Tractor Operator Can See People Planting; Making it Easier to Communicate • More Water Capacity, Two 80 Gallon Tanks (Total 160 Gallons) •... -
Page 15: Helpful Tips
Helpful Tips For best crop stand, planting operators should firmly press plants into water-filled hole. If plenty of water is used, potted plants will be sealed and do not need to be covered with soil. When using starter fertilizer, it needs to be agitated. Fertilizer is heavier than water and will settle to the bottom of the tank, resulting in possibly burning or killing the first couple hundred plants. - Page 16 ~ 2021 Edition ~ Rain-Flo Irrigation (717) 445-3000...
