- Page 1 MODEL 1200 WATER WHEEL TRANSPLANTER OPERATING MANUAL Rain-Flo Irrigation 929 Reading Road East Earl, Pa 17519 717-445-3000...
-
Page 2: Table Of Contents
Table Of Contents Axle, Tire..............3 Features ..............13 Foot Rest ..............4 Helpful Tips ............14 Options ..............13 Parts Breakdown, Description ......10-12 Parts Breakdown, Exploded Views .......6-9 Planter Seat ............. 4 Planting Wheel ............3 Safety First .............. 2 Super wheel............. -
Page 3: Safety First
!! Safety First !! No riders beyond the speed of 3 MPH. Be sure you read and under- stand all the precautions. Keep people away when lifting and lowering the machine. Be careful when turning around; machine is 8’ long. Do not crawl under the machine while it is lifted. -
Page 4: Axle, Tire
PLANTING WHEEL ADJUSTMENTS Water Shut-Off Handle Collar Plumbing Valve S.S. Axle Shaft (S.S. Axle Shaft) To mount planting wheels and plumbing. (Collars-2) To hold position of plumbing valves. (Plumbing Valves) To adjust water flow. (Water Shut-Off Handle) To shut off water supply. One or two planting wheels can be used at a time. -
Page 5: Foot Rest
OmbinatiOn Note; This can be added to the Model 1200 anytime. (1)Reverse lift pins so that Cat II is on inside (A). (2)Install draw bar hitch by sliding onto the lifting pins (A). (3)Install lynch pins on the inside of Cat II lifting pin (A). -
Page 6: Super Wheel
OPTIONAL SUPER WHEEL The super wheel is a very universal planting wheel. Spike size and spacing can be changed as preferred. A rubber grommet is used to close unused holes. Note; lock pin is used in heavy or rocky soil conditions to avoid spike detaching. -
Page 11: Parts Breakdown, Description
Model 1200 Transplanter esCriptiOn 1....(2) .....Tee handle 5....(2) .....3/8” x 3/4” sq. head lock bolt 7....(3) .....1” SAE washer 12....(2) .....3/8” x 2½” bolt 13....(3) .....1/4” NFT straight grease zert 24....(2) .....Cushion seat 27....(8) .....5/16” x ½” seat bolt 31.... - Page 12 816.... (2) .....Seat adjuster side knob cap 817.... (2) .....Complete axle with tire 818.... (2) .....Complete seat adjuster 819.......1” Hose Extension 820.... (2) .....Model 1200 side decal 821.......Model 1200 serial number label 822.......Rain-Flo small oval logo 823.......1” Insert Male Adapter...
- Page 13 855.......Trailer lift handle mounting bracket 856.......Trailer handle lift lock in up position 857.......Model 1200 trailer fork bracket 858.......Model 1200 trailer fork bracket flat plate 3-100 ..(2) .....Planter stand rubber cap 3-101 ..(2) .....Planter water shut off handle rubber grip 3-115 ..
-
Page 14: Features
Features • Capability of 8” to 24” row spacing and one or two planting wheels. (Standard) • Two slant galvanized expanded metal trays. • Specialty designed tanks so tractor operator can see people planting. Easier to communicate. • Two 50 gallon tanks. (Total 100 gallons) •... -
Page 15: Helpful Tips
Helpful Tips For better crop stand, planting operators should firmly press plants into water-filled hole. If plenty of water is used, pot- ted plants will be sealed and do not need to be covered with soil. When using starter fertilizer, it needs to be agitated. Fertilizer is heavier than water and will settle to the bottom of the tank, resulting in possibly burning or killing the first couple hundred plants. - Page 16 ~2015 Edition~ Rain-Flo Irrigation (717) 445-3000...
