- Page 1 MODEL 2400 RAISED BED PLASTIC MULCH LAYER ASSEMBLY INSTRUCTIONS Rain-Flo Irrigation 929 Reading Road East Earl, Pa 17519 717-445-3000...
- Page 2 STEP 1 Standard parts shipped with equipment: Yellow Arm Set Cover Disk Set Dirt Shield Set Press Wheel Set...
- Page 3 STEP 2 & P ellow ress heels See Operating Manuel for adjustments. ynch Remove lynch pin from hole on yellow arm and slide yellow arm through press wheel and into hinge on bed press. Fasten in Yellow Arm place with lynch pin. Secure chains to holes as shown.
- Page 4 STEP 3 isks AnD hielDs See Operating Manuel for adjustments. Dirt Shield Cover Disk Slide disk bracket over end of yellow bar and tighten in place with ell lock handle. Install dirt shield as shown, by sliding end through hole and fastening with tee lock handle.
- Page 5 STEP 4 rActor The Model 2400 has category I and II lift pins (A) on a 3-point hitch. Hook up 3-point top link to top of A-frame (B) and adjust top link to level machine. Use top hole for higher lift.
- Page 6 STEP 5 nstAlling See Operating Manuel for adjustments. Drip Tape Drip Tape Drip Tape Guides / Rollers Rollers Rollers Remove plate with locking clamp(A). Slide drip roll onto rod, press plate(A) tight against roll and tighten tee-handle on clamp. Feed drip tape through swing arm guide and stationary guide(B) (also see sketch) then into drip line down pipe(C).
- Page 7 STEP 6 nstAlling lAstic See Operating Manuel for adjustments. Place plastic rolls on top of rollers(A). Pull end of plastic down in between rollers and underneath bottom roller(B). Secure plastic and drip tape at end of row. Only feed from one roll at a time. Plastic Plastic Roll...
- Page 8 ~2015 Edition~ Rain-Flo Irrigation (717) 445-3000...
