SureShade
Power Bimini
®
OEM INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SureShade Power Bimini and is the answer not in the manual?

Questions and answers

Related Manuals for Lippert SureShade Power Bimini

Summary of Contents for Lippert SureShade Power Bimini

  • Page 1 SureShade Power Bimini ® OEM INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    Notes Introduction The SureShade Power Bimini is an electric actuator-driven Bimini top powered by a 12V DC source, controlled by a helm-mounted momentary switch or an optional RF remote control system. For information on the assembly or individual components of this product, please visit: https://support.lci1.com/marine-products/...

  • Page 3: Safety

    Safety Read and understand all instructions before installing or operating this product. Adhere to all safety labels. This manual provides general instructions. Many variables can change the circumstances of the instructions, i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This manual cannot begin to plot out instructions for every possibility, but provides the general instructions, as necessary, for effectively interfacing with the device, product or system.

  • Page 4: Resources Required

    Resources Required • 1-2 persons, depending on task • Tape measure • Pencil • 1/2" wrench • Cordless or electric drill or screw gun • Phillips screwdrivers (x2) • 3/8" drill bit • Wire cutter/stripper • 3/8" nut-driver bit • Wire crimper •...
  • Page 5 Fig. 1 Bimini Frame Actuator Assemblies Fig. 2 Rear Frame Assemblies Align Actuators Even Starboard Make Port Actuator Parallel Actuator 1/4" Max Offset Fig. 3 Frame Assembly Rear Port Bimini Mounting Holes Frame Assembly Rear Starboard Bimini Frame Assembly Page 5 Rev: 07.06.21 CCD-0003657...
  • Page 6 Slide a rear strut assembly (Fig. 4A) over each actuator's rear receiver handle (Fig. 4B). Fig. 4 Secure each rear strut assembly using 1/4" hex cap screws (Fig. 5A), then tighten using a 5/32" hex wrench (Fig. 5B). Fig. 5 Page 6 Rev: 07.06.21 CCD-0003657...
  • Page 7 Place each rear strut/actuator assembly onto the boat's frame/railing (Fig. 6). Note: Proper rear strut assembly positioning is generally determined by locating the assembly so that when the top is down, the struts are just behind the rear seats. Too far forward and the top will interfere with rear seating;...
  • Page 8 Adjust the width spacing between the rear strut/actuator assemblies (Fig. 8, Dim A) until the bimini width matches the boat’s rear frame/railing width (Fig. 8, Dim B). Fig. 8 Dim A Strut/Actuator Assembly Dim B Frame/Railing Move the port and starboard actuator assemblies (Fig. 2) forward and aft until the actuators are in-line with each other.

  • Page 9: Wiring Actuators

    For each strut/actuator assembly, put a tape measure on the pencil line made at the front of the actuator (Fig. 10). Measure back 1/2" and 16 1/2" and mark these locations on the frame/railing with a pencil (Fig. 10). Fig. 10 16 1/2"...

  • Page 10: Mounting Actuators

    Option 2 - bottom of frame For each actuator: Drill a third hole all the way through the boat’s rear frame/rail to accept the actuator wire. Run the wire under the top frame using fastener-mount zip ties (not included) to support the wire, then run the wires to the helm.

  • Page 11: Installing Stand-Offs

    Adjust the width spacing between the rear strut/actuator assemblies (step 6 of the Installing Actuator's section and Fig. 8) until the bimini width matches the boat’s rear frame/railing width. Note: When installed, each stand-off leg should rest as near the center as possible of the frame's side rail. Use a 1/2"...
  • Page 12 Align pre-drilled holes in stand-off leg (Fig. 15A) with holes in the nylon bushings (Fig. 15B). Note: Stand-off leg has a slight miter that should angle towards the end of the rear strut assembly. Insert a Phillips nut (Fig. 15C) through one side of the H-bracket and into the bushing. D.

  • Page 13: Installing Helm Switch

    Installing Helm Switch Note: A helm switch and RF Remote Control are provided, but both do not need to be installed for the system to operate. If the helm switch and the RF Remote Control are both installed, refer to the wiring diagram in that section.
  • Page 14 Secure starboard and port front struts using 1/4" socket hex cap screws (Fig. 17C). Tighten hex screws with 5/32" hex wrench. Fig. 18 Starboard Front Strut Rear Strut Center Bow Middle Strut Center Bow Fig. 19 Front Strut Center Bow Port Rear Strut Port Middle Strut...

  • Page 15: Final Assembly

    Final Assembly Use a cordless or electric drill or screw gun and the #10 self-drilling Phillips screws (Fig. 18A) to fasten all struts and bows together. The middle strut assembly gets two screws as shown in figure 18B. Repeat this process for both sides (port and starboard).
  • Page 16 Fig. 21 Canvas Top Securing Strap Female Snap Strut Fig. 22 Strut Fig. 23 Female Snap Installed Male Snap Page 16 Rev: 07.06.21 CCD-0003657...

  • Page 17: Wiring Diagram

    Wiring Diagram #10 insulated ring 3/16" flag terminal, terminal, 2 req'd. fully insulated, 4 req'd. DPDT reversing toggle switch, Philmore #30 - 125. Battery Ground (–) Battery Note red dot on or near one motor Positive (+) 1/4" spade terminal, terminal.

  • Page 18: Rf Remote Control Installation - Optional

    RF Remote Control Installation - Optional The RF Remote Control is an optional control, but not required to be installed for the system to operate. Resources Required • Cordless or electric drill or screw gun • 3/16" insulated flag spade terminal •...
  • Page 19 Connect the battery and motor wires according to the schematic diagram shown in figure 27. Note: If a helm-mounted switch is installed, connect it to the RF receiver as shown in the schematic (Fig. 27). Fig. 27 Override Switch Battery Ground (-) Battery Positive (+) Motor #1 White Wire Motor #1 Dark Blue Wire...

  • Page 20: Rf Remote Control Operation - Optional

    RF Remote Control Operation - Optional Key Fob Remote The up and down motion of the actuator is controlled by the key fob remote (Fig. 28). The Open (Fig. 28A) and Close (Fig. 28B) buttons are latching, meaning once pressed, motion will automatically continue until the commanded position is reached.

  • Page 21: Notes

    Notes Page 21 Rev: 07.06.21 CCD-0003657...
  • Page 22 Lippert representative has been provided.  Any unauthorized use shall void any applicable warranty.  The information contained in this manual is subject to change without notice and at the sole discretion of Lippert .  Revised editions are available for free download from lci1.com.
