- Page 1 SureShade 2000 Series ® Forward Facing Power Bimini OEM INSTALLATION MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Safety Resources Required Preparation Actuator Mounting Locations Wiring the Forward Facing Bimini System Post-installation Check Notes Introduction The SureShade® 2000 Series Forward Facing Power Bimini is a pre-assembled electric actuator-driven bimini top system powered by a 12V DC source. The forward facing shade can be easily operated by a helm-mounted momentary switch. -
Page 3: Safety
Failure to correctly follow the provided instructions may result in death, serious personal injury, severe product and/or property damage, including voiding of the Lippert limited warranty. The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death or serious personal injury and/or severe product or property damage if not performed safely and within the parameters set forth in this manual. -
Page 4: Resources Required
Resources Required • 1-2 persons, depending on task • 9/16" wrench • Cordless or electric drill or screw gun • Tape measure • 3/8" drill bit • Pencil Preparation Actuator Mounting Locations When installing the complete forward facing bimini system onto the boat's railing, make sure: •... - Page 5 If the boat's frame is pre-drilled, go to step 2 to continue installation. If the boat's frame is NOT pre-drilled, do as follows: Move the port and starboard actuator assemblies forward and aft until the actuators are in-line with each other (Fig. 3). Make sure the actuators are mounted square, level and plum to one another.
-
Page 6: Wiring The Forward Facing Bimini System
Wiring the Forward Facing Bimini System The SureShade 2000 Series Forward Facing Power Bimini actuators, mast light and the light strip MUST be wired to a control switch independent of each other. Do NOT combine any of these wire harnesses prior to their connection to a dedicated control. - Page 7 Connecting the Mast Light Locate the dedicated switch for the mast light. From the mast light, connect the gray wire to one side of the switch and the black wire to ground (Fig. 6). Make sure the switch is properly connected to the positive and then to the circuit protection as shown in the Wiring Diagram (Fig.
- Page 8 Connecting the LED Courtesy Light Strip Locate the dedicated switch for decorative lighting. From the light strip, connect the white wire to one side of the switch and the black wire to ground (Fig. 7). Make sure the switch is properly connected to the positive battery lead and to the circuit protection as shown in the Wiring Diagram (Fig.
-
Page 9: Post-Installation Check
Post-installation Check Make sure actuators are securely fastened to the railings. Make sure all actuator wires are loomed and secured in-place. If necessary, remove the protective boot from the forward facing bimini. Before operating the power bimini top, thoroughly inspect the area around the entire bimini assembly. - Page 10 III. Install the boot over the bimini top then press and hold the forward facing bimini helm switch until the bimini is in the Radar Position and stops itself (Fig. 10). Release switch. Note: The canvas boot MUST be installed to achieve Radar Position. The bimini top will NOT stop automatically in the Radar Position without the boot installed.
-
Page 11: Notes
Notes Page 11 Rev: 12.11.23 CCD-0007745... - Page 12 Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. Revised editions are available for free download from lippert.com.
