- Page 1 X-Trek Stabilization System OEM INSTALLATION MANUAL...
-
Page 2: Table Of Contents
Failure to act in accordance with the following may result in death or serious personal injury. The use of X-Trek to support the trailer for any reason other than which it is intended is prohibited by Lippert’s limited warranty. The Lippert stabilizing system is designed as a “stabilizing” system only and should not be used to provide service for any reason under the trailer such as changing tires or servicing the stabilizing system. -
Page 3: Resources Required
The trailer MUST be supported per manufacturer's recommendations before working underneath. Failure to do so may result in death or serious personal injury. Do NOT exceed Gross Vehicle Weight Rating. Severe damage to product or property may occur. The "CAUTION" symbol above is a sign that a procedure has a safety risk involved that may cause personal injury and/or product damage, including voiding of warranty, if not performed safely and in accordance with the safety procedures stated herein. -
Page 4: Installation
Installation Brackets and Stabilizers Each stabilizer comes with two brackets attached: an exterior frame bracket (Fig. 1) and crossmember bracket (Fig. 2). Fig. 1 Fig. 2 To install the brackets: With brackets attached to the stabilizers, determine placement of brackets so front and rear stabilizers are oriented as shown in Figs. -
Page 5: Pump And Hydraulic Hoses
The brackets should be oriented to the frame as shown in Fig. 5. Mark with a grease pencil where the brackets will need to be attached to the frame. Fig. 5 Crossmember Exterior Frame Crossmember Bracket Exterior Frame Bracket Remove the brackets from the stabilizers and attach the brackets to the frame with OEM-supplied "... - Page 6 Determine where the T-fitting (Fig. 7A) will be located under the chassis with the single outlet pointing toward the front, centered between the two front stabilizers. Fig. 7 Front Roadside Curbside Rear 5/16 Measure the following areas (Fig. 8) to determine the length of five pieces of "...
- Page 7 Fig. 8 Front Roadside Curbside Rear 5/16 " pressure fittings to each end of the high pressure hose pieces, then attach hoses from: A. The pump (Fig. 8A) to the T-Fitting (Fig. 8B). B. The T-fitting (Fig. 8B) to the left and right front stabilizers (Fig. 8D). C.
-
Page 8: Post-Installation Check
Post-Installation Check Fill pump reservoir by removing the fill cap on the top of the pump (Fig. 9A) and fill with hydraulic fluid to within " of the bottom of the fill port. Fig. 9 Remove the cap from the valves (Fig. 10A) on the pressure cylinders (Fig. 10B) and pressurize each cylinder to 60-70 psi with an air pump, then cap the valves. -
Page 9: Extending Stabilizers
Insert the handle (Fig. 11A) into the collar (Fig. 11B) on the top of the pump (Fig. 11C) and actuate 40 full cycles (pump handle fully down and back to fully up is one cycle) after ground contact to force the hydraulic fluid to the stabilizers. -
Page 10: Troubleshooting
Retracting Stabilizers To retract the stabilizers, turn the release valve on the pump to the left (counterclockwise) (Fig. 12A). This will release the pressure in all of the stabilizers. NOTE: Stabilizers may not all retract at the same rate. Fig. 12 Troubleshooting If any of the following conditions occur during post-installation check, do as follows: Loss of Air Pressure... -
Page 11: Hydraulic Stabilization Schematic
Hydraulic Stabilization Schematic Roadside Curbside Front Front Roadside Curbside Manual Rear Rear Pump Legend Item # Description Roadside Front Cylinder Curbside Front Cylinder Roadside Rear Cylinder Curbside Rear Cylinder Roadside Front Stabilizer Curbside Front Stabilizer Roadside Rear Stabilizer Curbside Rear Stabilizer Manual Pump Pressure Release Valve Page 11 CCD-0001701... -
Page 12: Hose Routing Diagram
Hose Routing Diagram Front Curbside Roadside Pump T-Fitting High Pressure Hose from Pump to T-fitting C1 - Roadside C2 - Curbside Front Cylinder Front Cylinder High Pressure J1 - Roadside J2 - Curbside Hoses from T-fitting Front Stabilizer Front Stabilizer to Front Stabilizers High Pressure Hoses from Front Stabilizers... -
Page 13: Notes
Notes Page 13 CCD-0001701 Rev: 04.30.19... - Page 14 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
