RETURN TO SERVICE PROCEDURE TABLE OF CONTENTS
RETURN TO CD-ROM TABLE OF CONTENTS
North
American
Dräger
Field Service Procedure
Part Number: SP00173
Rev: B
Date: 30 December 1999
© 1999 Draeger Medical, Inc.
Installation of Novametrix
SpO
Module in Narkomed 4
2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Dräger Novametrix
Summary of Contents for Dräger Novametrix
- Page 1 RETURN TO SERVICE PROCEDURE TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS North American Dräger Field Service Procedure Part Number: SP00173 Rev: B Date: 30 December 1999 © 1999 Draeger Medical, Inc. Installation of Novametrix Module in Narkomed 4...
-
Page 2: Installation Procedure
INSTALLATION PROCEDURE NOTE: The following instructions apply to installation of a Novametrix pulse oximeter module in place of an existing Nellcor module on a Narkomed 4. The location of the pulse oximeter assembly within the monitor box is shown in Figure 1. - Page 3 RETURN TO SERVICE PROCEDURE TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS INSTALLATION PROCEDURE (continued) PULSE OXIMETER SPO2 SPEAKER ASSEMBLY AND AMPLIFIER LATER DESIGN NARKOMED 4 MONITOR BOX TOP VIEW WITH COVER REMOVED SV40438 PULSE OXIMETER ASSEMBLY Figure 1: PULSE OXIMETER ASSEMBLY LOCATION...
- Page 4 RETURN TO SERVICE PROCEDURE TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS INSTALLATION PROCEDURE (continued) SPEAKER WIRE CONNECT WIRE HARNESS TO HARNESS TO BACKPLANE J21 BACKPLANE J21 BACKPLANE J43 CABLE FROM SpO2 INTERFACE PANEL WIRE HARNESS TO BACKPLANE J43 MOUNTING SCREWS (2X) RIBBON CABLE...
- Page 5 RETURN TO SERVICE PROCEDURE TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS INSTALLATION PROCEDURE (continued) Figure 3: NOVAMETRIX PULSE OXIMETER MODULE...
- Page 6 J12 to J101 on the connector) of the SpO module toward Novametrix module. Add a 3½ in. the bottom of the chassis captive grommet strip supplied in the kit on screws. the card cage chassis at the point where J12 exits the backplane.
- Page 7 Figure 4 shows BP cuff and BP gauge lines, and the front panel of the Novametrix the oximeter sensor cable at the left TB500B Sensor Simulator, with a description of its controls.
- Page 8 RETURN TO SERVICE PROCEDURE TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS INSTALLATION PROCEDURE (continued) S P 1 7 3 0 4 S E N S O R T Y P E O U T P U T T B 5 0 0 B 8 6 X X 8 7 X X S I G N A L A T T E N U A T I O N...
- Page 9 Novametrix Monitor SpO2 Calibration Check: Plug the SpO2 sensor extension cable into the machine interface. Disconnect the finger probe from the extension cable and attach a Novametrix TB500B sensor simulator to the extension cable. Turn the System Power switch to ON. press and hold the Selection Dial, and simultaneously press the MONITOR and SYSTEM CONFIG keys to enter the main service screen.
- Page 10 RETURN TO SERVICE PROCEDURE TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS INSTALLATION PROCEDURE (continued) The caution message OXI PULSE HIGH shall appear on the central alarm display and an intermittent audible alarm shall sound. Return the pulse high alarm limit to its previous setting. Note the SpO2 SAT high and low alarm settings.
- Page 11 RETURN TO SERVICE PROCEDURE TABLE OF CONTENTS RETURN TO CD-ROM TABLE OF CONTENTS North American Dräger DrägerService 3122 Commerce Drive Telford, PA 18969 (215) 721-5402 (800) 543-5047 (215) 723-5935 Fax...
