  • Page 1 NEW TECHNOLOGY PC380-KT USER’S MANUAL ed. 05/2020 cod. 000516 Rev.02 ELECTRONICS FOR CARAVANNING...

  • Page 3: Table Of Contents

    Main parts of the electrical system dvice and checks ONTROL PANEL “PC380- ” Descriptions Main visualizations Functions Users’s setting DISTRIBUTION BOX “DS520-AN” Protection fuses Connections Electrical system functions INSTALLATION “PC380- ”...

  • Page 4: Main Parts Of The Electrical System

    MAIN PARTS OF THE ELECTRICAL SYSTEM > CONTROL PANEL “PC380-KT” - mains’ control, battery test, tank test and clock function. > 12V DISTRIBUTION BOX “DS 520-AN ” - main relays, battery parallel relays (12V - 70A), fridge relays, pump relays, car battery recharging device, ampere meter, protection fuses.

  • Page 5: Control Panel "Pc380-Kt

    CONTROL PANEL “PC380-KT” DESCRIPTIONS «12V» b utton to switch the light circuit on and off “PROG” button for system setting (see (lights and awning light). SETTING). Button to switch the water pump on and off. Button for the control of fresh and waste water...

  • Page 6: Main Visualizations

    MAIN VISUALIZATIONS It indicates that the engine is on It displays that the tones are off. It displays that the battery parallel is on when 10) It displays that alarm clock is set. engine is on. Fresh water tank status display. It displays that the chassis battery recharging “...

  • Page 7: Functions

    FUNCTIONS To measure the charging of a sole source (battery CHASSIS BATTERY ALARM (B1) charger, alternator or solar panels), turn off all When the chassis battery voltage drops down to 12V, items and other charging sources. the Chassis Battery Discharge alarm goes on and To measure the consumption of a sole user, symbol ref.

  • Page 8: Users's Setting

    USER’S SETTING To enter the set mode, press the PROG” button “ By using the arrow keys ref. 7 and 8 you can modify the setting of the parameters. (ref. ) for more than 2 seconds from the main Confirm the setting by pushing the PROG”...
  • Page 9 DISPLAY BUTTONS BACKLIGHT SETTING Intensity setting of the buttons LED backlight in a “night” situation (see also the “TWILIGHT” function) : - (0÷100 %) DISPLAY BACKLIGHT SETTING Display’s backlight setting when control panel is in stand-by: - (0÷100 %) DISPLAY BACKLIGHT COLOUR Display backlight colour selection COLOUR DISPLAY CONTRAST...
  • Page 10 SETTING ACOUSTIC ALARMS Activation/Deactivation of acoustic alarms: tones - ON (activation) - OFF (deactivation) TEMPERATURES Setting internal temperature, step 0.5°C INT. TEMP. Setting external temperature, step 0.5°C EXT. TEMP. CALIBRATION AMMETER Calibration of « » in ammeter (A). Setting steps: 0.1A. 0 AMP...
  • Page 11 VOLTMETERS SETTING Setting of the leisure battery “B2” voltmeter. b2 set Max. value +/- 0.5V, step 0.1V. Setting of the car battery “B1” voltmeter. b1 set Max. value +/- 0.5V, step 0.1V. SMITTER Activation/Deactivation visualization in bars of the leisure battery and fresh water tank status in the SmITTER starting page.

  • Page 12: Distribution Box "Ds520-An

    DISTRIBUITION BOX “DS520-AN” RE-VI RE-EL 1 2 3 4 1 2 3 4 + OUT 12V PROTECTION FUSES 5A fuse to give power the AUX auxiliary exit 10) 3A fuse spark ignitions for the fridge, oven & awning light , turns automatically off when stove, it is connected directly to the leisure engine is on.

  • Page 13: Connections

    + input signal “S” net coming from the CBE battery charger. SIGNALS (OPTION “B”) - input “D+” negative signal (-) + input signal contact key engine starting. 26B) 1) + input signal “S” net coming from the CBE battery charger. NOT CONNECTED...
  • Page 14 EARTH To connect to the mains' earth. - B2 EARTH To connect to the negative pole of the leisure battery or to the chassis of the vehicle. + B2 LEISURE BATTERY To connect to the positive pole of the leisure battery + OUT 12V 12V EXIT...

  • Page 15: Electrical System Functions

    ELECTRICAL SYSTEM FUNCTIONS Operation with SMART ALTERNATOR (present on CHASSIS BATTERY (B1) RECHARGING all DS distribution boxes manufactured since When the battery charger is charging, an electronic September 2019) device allows a recharging ( nominal current 2 A) of For vehicles equipped with SMART ALTERNATOR the c hassis battery (B1), the system gives priority to...

  • Page 16: Installation "Pc380-Kt

    INSTALLATION “PC380-KT”...
  • Page 17 NOTE...
  • Page 18 NOTE...
  • Page 19 NOTE...
  • Page 20 CBE S.r.l. Via Vienna 4 z.i. Spini (settore D) 121 Trento - Italy Tel. +39 0461 991598 Fax +39 0461 960009 cbe@cbe.it www.cbe.it ELECTRONICS FOR CARAVANNING...
