- Page 1 MANUAL gebrauchsanweisungen INSTRUCTIONS D'EMPLOI PC-100 / PC-200 DS-300 000162.04 07/02/07...
-
Page 2: Table Of Contents
SCHEMA DI INSTALLAZIONE "PC-100" ........ -
Page 3: Main Parts Of The Electrical System
MAIN PARTS OF THE ELECTRIC AL SYSTEM CONTROL PANEL - mains’ control, battery test, tank test, (PC-100 and PC-200) - temperature test and clock function (only for “PC-200). 12V DISTRIBUTION BOX “DS-300” - main relais, battery parallel relais (12V - 70A), fridge relais, pump relais, car battery recharging device, protection fuses. -
Page 4: Control Panel "Pc-100
CONTROL PANEL “PC-100” P C - 1 0 0 C APTIONS Button to check the drink water tank. Button to check the leisure battery (B2). Button to check the car battery (B1). Awning light switch, it switches automatically off when you star tup the engine. -
Page 5: Control Panel "Pc-200
CONTROL PANEL “PC-200” C APTIONS Test button to check both internal and external temperature and to set the clock. Test button to check the voltage of the car battery(B1) and leisure (B2) battery and to set the clock. Test button to check the level in % of the drink and waste water tank and to set the clock. Awning light switch, it switches automatically off when you star tup the engine Main switch (see minimal voltage control). - Page 6 This was studied in order to avoid useless consumption. The tank probe has been already programmed by CBE, but it is still possible to check the correct working of the tankprobe and its setting by following these instructions: - activate the function “DRINK WATER TANK REFILLING”...
-
Page 7: Distribution Box "Ds-300
”DS-300” DISTRIBUTION BOX 1 2 3 4 5A fuse to give power to the awning light, it depends on the main switch and it switches automatically off when the engine is started. 10A fuse to give power to the water pump, it depends on the main switch. 10A fuse to give power to the heating/boiler, it depends on the lights main switch. - Page 8 To connect to the positive pole of the services battery. WHITE SIGNALS C AR BATTERY + input signal contact key engine To connect to the positive pole of the starting. car battery. + input signal “S” net coming from the CBE battery charger...
- Page 9 FUNCTIONS CAR BATTERY (B1) RECHARGING When the battery charger is charging, an electronic device allows a recharging (max 2A) of the car battery (B1), the system gives priority to the leisure battery (B2). LEISURE BATTERY (B2) RECHARGING by alternator: through the separating relais, when the engine is started. The +KEY engine starting controls electronically a small relais which controls the other relais: parallel, fridge, awning light, etc.
