Jenson
Gloss
341/1304 310/4642
Spare Parts
Visit: www.argos-support.co.uk
Email: Help@ClickSpares.co.uk
Call: 0330 016 1114
C R
Customer Support
Call: 0345 640 2020
C R
Issue 1 - 04/12/19

Advertisement

loading
Need help?

Need help?

Do you have a question about the HOME Jenson Gloss 341/1304 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos HOME Jenson Gloss 341/1304

  • Page 1 Jenson Gloss 341/1304 310/4642 Spare Parts Customer Support Visit: www.argos-support.co.uk Call: 0345 640 2020 Email: Help@ClickSpares.co.uk Call: 0330 016 1114 Issue 1 - 04/12/19...
  • Page 2: Care Advice

    Safety Important - Please read these instructions fully before starting assembly • WARNING: To prevent • Warning: This unit weighs possible overbalancing this unit approximately 17kgs. must be secured to a wall using Please lift with care. the overbalance protector kit •...
  • Page 3: Cabinet Panels

    Cabinet Panels 3 10 x 35.3cm 1 71.8 x 38.8cm 2 71.8 x 38.8cm 4 90.7 x 9.2cm 5 98.3 x 39.1cm 6 90.7 x 36.6cm Drawer Panels Note: the internal drawer panels are grey 7 90.15 x 10.8cm 8 35 x 6.8cm 9 35 x 6.8cm 11 39.7 x 6.8cm 10 40.8 x 34.1cm...
  • Page 4 Fittings Use these drawings to correctly identify the fittings Bag 1 x 12 Bag 2...
  • Page 5 Fittings Tools Only used for drilling walls...
  • Page 6 Bag 1 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q x 12...
  • Page 7 Screw directly into panel as illustrated Screw directly into panel as illustrated...
  • Page 9 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Screw directly into panel as illustrated Finished Finished Finished Finished front edge front edge front edge front edge Finished Finished front edge front edge Finished front edge Turn the panel over for the Finished Finished next step front edge front edge...
  • Page 10 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Finished Finished front edge front edge Finished front edge...
  • Page 11 Finished front edge Finished front edge Finished bottom edge Finished front edge...
  • Page 12 Finished front edge...
  • Page 14 WARNING! In order to prevent overturning this product must be used with the wall attachment device provided See the next section for a guide to wall mounting and fixings Example s t y Washer Screw Washer Wall fixing (not supplied) Screw (not supplied) To prevent possible overbalancing this unit must be secured to a suitable wall by fitting of...
  • Page 15: A Guide To Wall Mounting & Fixings

    A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
  • Page 16: Drawer Assembly

    Drawer Assembly Bag 2...
  • Page 18 Ensure the drawer bases sit flush by turning the shelf studs clockwise or anti-clockwise...
  • Page 19 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Screw directly into Drawer Side as illustrated...
  • Page 20 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Screw directly into Drawer Side as illustrated...
  • Page 21 Fixing Bottom Mounted Runners https://www.youtube.com/watch?v=Z6lGMy19h7Q Slide the wheels of the 4 Runners fitted to the Drawer, over the wheels of the Runners fitted to the panels and push the drawer into position. Assembly is complete Please remove any blue protective film from panel edges and clear protective film from panel surfaces...
  • Page 22 ALR3597...
  • Page 24 ALR3597...
