- Page 1 LORY HOLD User Manual 0123 EN 358:2018...
-
Page 2: Brief Description
Subject to technical changes BRIEF DESCRIPTION INTENDED USE All other uses are deemed improper. The company BORNACK will not be liable for The LORY HOLD is part of personal pro- any ensuing damages. The user bears tective equipment (PPE) of category III to the sole risk. - Page 3 BRIEF DESCRIPTION EQUIPMENT • LORY HOLD holding rope type: LOH01 - LORY HOLD securing device, cannot be opened - Connector acc. to EN 362 made of aluminium or steel - LORY STOP positioning rope 11 mm with/without rope protector and connector acc.
- Page 4 4 | 5 LORY HOLD HOLDING ROPE TYPE: LOH01 Connector acc. to EN 362 D-ring for karabiner Identification rope Identification securing unit Clamping Safety rope Rope Sewn rope end protector...
- Page 5 LORY HOLD HOLDING ROPE TYPE: LOM01 Connector acc. to EN 362, stationary Connector acc. to EN 362 Identification securing unit Control lever Clamping Safety rope Label Rope protector Sewn rope end...
-
Page 6: Information Before Use
• Product identification legible. paired by BORNACK or in a workshop • The last inspection by an expert was authorised in writing by BORNACK. carried out within the past 12 months. - Page 7 LORY HOLD TYPE: LOH01 IN USE PREPARATION CAUTION: RISK TO LIFE! This device is not designed to arrest a fall (free fall)! It does not have an energy absorber. Observe the User Manual of the full body harness. A Use the connector acc. to EN 362 to hook the LORY HOLD into a D-ring acc.
- Page 8 8 | 9 LORY HOLD TYPE: LOH01 IN USE C Opening and closing the safety karabi- ner with a striking plate and snapper: apply pressure to the striking plate with the ball of your thumb and, at the same time, open the snapper with your index finger.
- Page 9 LORY HOLD TYPE: LOH01 IN USE APPLICATION E Guide the LORY HOLD around a mast or other structural element and hook the karabiner of the holding rope into the other side D-ring of the safety har- ness. Check the karabiner lock! F Make sure that the connection and holding function are taut by pulling on the loose end of the holding rope.
- Page 10 Compatibility must be assessed during the risk analysis. Only combine with personal protective equipment that bears a CE symbol. If you have any questions about compatibility or you require help with the risk analyses, feel free to contact BORNACK.
- Page 11 LORY HOLD TYPE: LOM01 IN USE PREPARATION Observe the User Manual of the safety harness EN 361 or the seat harness EN 813. H LORY HOLD type: hook the LOM01 into the sternal D-ring of a safety harness or the ventral D-ring of a sit harness (central to the body axis) using a lan- yard acc.
- Page 12 12 | 13 LORY HOLD TYPE: LOM01 IN USE J Positioning by lowering Set the rope to a short length and hand in the positioning system (sit- ting). Descend in a controlled manner using the control lever until the re- quired position is reached.
- Page 13 LORY HOLD TYPE: LOM01 IN USE CAUTION: RISK TO LIFE!: Material D-rings/loops may never be used to secure persons! Otherwise there is a risk to life! ATTENTION: The conditions of wet or frozen areas are different than normal! ATTENTION: If sand or dirt enter the device, this may impact on its function and cause dam- age.
- Page 14 Compatibility must be assessed during the risk analysis. Only combine with personal protective equipment that bears a CE symbol. If you have any questions about compatibility or you re- quire help with the risk analyses, feel free to contact BORNACK.
- Page 15 Accident Insurance) principle 312-906, • Calculation of the possible fall path if by BORNACK or by a workshop author- all necessary PPE components are used ised in writing by BORNACK. This must correctly: (if necessary braking path be documented in the test card.
-
Page 16: Safety Regulations
Casualties must be rescued within 20 minutes. BORNACK can help you draw up tai- lor-made rescue plans and includes these in the necessary training courses. E-mail hotline: info@bornack.de •... -
Page 17: Regular Inspections
TÜV SÜD Product Service GmbH SERVICE Ridlerstr. 65, D-80339 München CE 0123 If you have any further questions about this PPE or other BORNACK services, Quality management system certified to such as: ISO 9001:2015. • Risk analyses Production monitoring by notified office •... -
Page 18: Maintenance
• If disinfection is necessary, please con- strictly observed. tact the e-mail hotline: • Protective equipment that is clean and info@bornack.de well looked after will last longer! • If the personal protective equipment comes into contact with salt-water, keep it wet until it can be rinsed with plenty of distilled water. - Page 19 • For reasons of liability, repairs may only The service life can only be prolonged by be carried out by BORNACK or in a means of regular expert inspections and workshop authorised in writing by the replacement of age-related worn BORNACK.
- Page 20 20 | 21 OTHER STORAGE • Dry wet PPE before storage. • Store in a dry place away from direct sunlight. • Do not store PPE near radiators. Perma- nent exposure to temperatures below 0 °C or above +50 °C has a negative im- pact on the strength of the textile ma- terial and shortens the life span.
-
Page 21: Product Identification
OTHER PRODUCT IDENTIFICATION The following identification is on the product: Identification securing unit: Logo Manufacturer address Product name CE symbol and number of the test office Observe/read the Production date User Manual. Charge Serial number EN norm... - Page 22 22 | 23 OTHER Identification safety rope: Max. user weight CE symbol and number of the test office Product name Logo Product category Product type Observe/read the Rope length User Manual. Art. No. Charge Serial number Manufacturer Production date address EN norm Data matrix...
-
Page 23: Eu Declaration Of Conformity
EU DECLARATION OF CONFORMITY... - Page 24 24 | 25 TEST CARD FOR ANNUAL MONITORING The test list must be Type LORY HOLD: _________________________ completed in full by the expert during the annual Production date: _________________________ inspection. Charge: _______________ _______________ This test list does not Device Rope claim to cover all test cri- Serial No.: ______________...
- Page 25 TEST CARD FOR ANNUAL MONITORING Please complete: Year 1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th No deformation of metal parts? Clamping cam in place & fully functional? Connector acc. to EN 362 in place and functional Smooth snapper function? No corrosion damage?
- Page 26 26 | 27 TEST CARD FOR ANNUAL MONITORING Please complete: Year 1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th Control lever in place/ fully functional (only for type: LOM01)? Identification legible? User Manual available? Blocked...
- Page 27 Notes:...
- Page 28 Tel + 49 (0) 70 62 / 26 90 0-0 Fax + 49 (0) 70 62 / 26 90 0-550 info@bornack.de www.bornack.de © BORNACK – Subject to technical changes Reprinting or duplication, even of excerpts, is only permitted with written consent Status: 05/2021 GAL Art. No. 8000148_EN ebo/anh...
