Certification
6.2 EMC and Environmental Type Tests
61000-4-5
61000-4-6
61000-4-8
61000-4-29
61000-4-12
61000-4-16
61000-4-17
IEC 60255-5
IEC 60255-5
EMC Immunity Type Tests per IEEE 1613
Note
The RUGGEDCOM RS900GPF meets Class 2 requirements for an all-fiber
configuration and Class 1 requirements for copper Ports. Class 1 allows for
34
Test
IEC Surge
IEC Induced (Conducted) RFI
IEC Magnetic Field
IEC Voltage Dips and Interrupts
IEC Damped Oscillatory
IEC Mains Frequency Voltage
IEC Ripple on DC Power Supply
Dielectric Strength
HV Impulse
Description
DC Power
Ports
Earth
Ground Ports
Signal Ports
DC Power
Ports
Signal Ports
DC Power
Ports
Earth
Ground Ports
Enclosure
Ports
DC Power
Ports
Signal Ports
DC Power
Ports
Signal Ports
DC Power
Ports
DC Power
Ports
Signal Ports
DC Power
Ports
Signal Ports
DC Power
Ports
Test Levels
± 1.5 kV
± 2 kV
± 500 V Line-to-Earth
± 500 V Line-to-Line
± 500 V Line-to-Earth
± 500 V Line-to-Line
10 V
10 V
10 V
40 A/m Continuous
1000 A/m for 1 s
30% for 0.1 s
60% for 0.01 s
100% for 0.01 s
2.5 kV Common
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
2.5 kV Common
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
30 V Continuous
30 V Continuous,
300 V for 1s
± 15%
2 kV (Fail-Safe
Relay output)
1.5 kV
5 kV (Fail-Safe
Relay output)
5 kV
