Pin-Out
The pin-out for the PoE ports is as follows:
8
Figure 4.7
Specifications
For specifications on the available PoE ports, refer to
Specifications (Page
For PoE power output specifications, refer to
23)".
4.3

Fiber Optic Ethernet Ports

Optional 1000Base-SX and 1000Base-LX fiber optic Ethernet ports are available for
ports 9 and 10 with either LC (Lucent Connector) and SC (Standard or Subscriber
Connector) connectors. Make sure the Transmit (Tx) and Receive (Rx) connections of
each port are properly connected and matched to establish a proper link.
Available Ports
1
1
2
Figure 4.8
LEDs
Each port features an LED that indicates its link/activity state.
RUGGEDCOM RS900GPF
Installation Manual, 01/2021, C79000-G8976-1353-05
1
RJ45 Ethernet Port Pin
Configuration
24)".
Tx Connector
Rx Connector
SC Connector
4.3 Fiber Optic Ethernet Ports
Pin
1
2
3
4
5
6
7
8
"Copper Ethernet Port
"PoE Output Specifications (Page
2
1
Tx Connector
1
Rx Connector
2
Figure 4.9
Communication Ports
Name Description
RX+ Receive Data+
RX- Receive Data-
TX+ Transmit Data+
V+ PoE
V+ PoE
TX- Transmit Data-
V- PoE
V- PoE
2
LC Connector
