Installing the Device
2.3.2 Mounting the Device to a Panel
1
2
3
Figure 2.4
1.
2.
10
1
Rear Mount Orientation
Front Mount Orientation
Side Mount Orientation
Panel Mount Options
Secure the adapters to the device in the desired orientation.
Place the device against (side or rear mount orientation) or insert it into (front
mount orientation) the panel and align the adapters with the mounting holes.
1
1
Panel Adapter
1
Screw
2
Figure 2.5
Panel Mounting (Rear Mount Orientation Shown)
2
2
2
Installation Manual, 01/2021, C79000-G8976-1353-05
3
RUGGEDCOM RS900GPF
