- Page 1 System ATF Series Model number: AR Series Model number: OPERATING MANUAL 5011_System_UF_manual_aw.indd 1 5011_System_UF_manual_aw.indd 1 18/05/2021 16:45 18/05/2021 16:45...
-
Page 2: Important Safeguards
Electrical safety: or disconnecting the motorised brush bar. • Only use batteries and chargers supplied Battery safety: by Gtech. • This appliance includes Li-Ion batteries; do • Never modify the charger in any way. not incinerate batteries or expose to •... -
Page 3: Intended Use
• Never use the appliance without the • Only use replacement parts or accessories filter fitted. provided or recommended by Gtech. • Ensure the battery is removed before Intended use: changing tools. -
Page 4: What's In The Box
Thank you for choosing Gtech “Welcome to the Gtech family. I started Gtech to create sensible, easy to use products that do a great job, and hope you get many years of trouble-free performance from your new product.” Nick Grey –... - Page 5 AirRAM: Assembly Push the two parts of the lower handle Push the pivot poke to the upright position. together in the orientation shown above. They This might require some force. will only fit one way. They will click into place Attach the lower handle to the head assembly and remain permanently fixed.
- Page 6 Assembly (continued) Push the two parts of the upper handle Insert the upper handle into the lower handle. together in the orientation shown above. They You will need to press the button on the upper will only fit one way. They will click into place handle to fit it in.
-
Page 7: Operation
Operation Without pressing the power button, place The power button is located on the left hand your foot on the left side of the head (1) and side of the head assembly. pull the handle back (2). Press the power button with your foot to turn the product on. -
Page 8: Battery Charging
Battery charging When the state of charge indicator starts to To remove the battery, squeeze the latch flash one green LED, recharge the battery. underneath and pull upwards. hours The battery can be charged whilst it’s in the It is OK to charge for 1 hour for a burst of product, or when it’s off the product. - Page 9 Emptying the bin Holding onto the head with one hand, pull the Lift and release the latch marked with the green bin handle and lift the bin out of the product. arrow, to pull open the lid. Hold the product’s bin over a rubbish bin Pull the green lever back towards the bottom and push the green lever towards the lid to of the bin.
-
Page 10: Cleaning The Filters
Cleaning the filters - do this once a month or more frequently depending on use. Holding onto the head with one hand, pull the Pull the filter out of the filter housing. bin handle and lift the bin out of the product. Tap the dirt from the filter and tip any dirt from the filter housing. -
Page 11: Replacing The Filters
Replacing the filters Slide the filter onto the inner shroud. Slide the filter and inner shroud into the filter housing. Removing and cleaning the brush bar / jam or fault seconds If the brush bar jams during use, the product The product will not re-start until the red lights will stop and the LEDs will appear red. - Page 12 Before checking for a blockage, remove the Rest the product on its side and locate battery. the brush bar button on the right hand side. Press the button inwards and then pull the brush bar out from the bottom of the product.
- Page 13 While the brush bar is removed you can take Re-insert the brush bar, starting by the end the opportunity to remove any hair from the furthest away from the button. Then line up brush bar housing comb as indicated. and push the brush bar into the product until it clicks into place.
-
Page 14: Product Care
If these initial tips do not solve your problem we please visit our support area where you can find troubleshooting help including online manuals, FAQs and how-to-videos, as well as genuine spares and replacement parts compatible with your product. Visit: www.gtech.co.uk/support Online Live chat support support@gtech.co.uk... -
Page 15: Multi: Operation
Multi: Operation The dusting brush can be slotted onto the Press the button above the handle to turn the active nozzle. The crevice tool is stored on product on and off. board the product for easy access. An active nozzle is built into your Multi. The dusting brush, crevice tool, extension tube and power brush all attach to the active nozzle. -
Page 16: Power Brush
Power brush Make sure the terminals on the Power Brush Gently pull the Power Brush from the product and Active nozzle are correctly lined up and to remove. The battery should be removed gently push the Power brush onto the Active when changing attachments. - Page 17 Battery charging hours hour boost When a single green light flashes, recharge After 4 hours, the LEDs turn solid green and the battery. charging is complete. It is OK to charge for 1 hour for a burst of cleaning. The battery can be charged on or off the main unit 5011_System_UF_manual_aw.indd 17 5011_System_UF_manual_aw.indd 17 18/05/2021 16:46...
-
Page 18: State Of Charge
State of Charge 100% - 75% 75% - 50% 50% - 25% 25% - 1% The battery state of charge indicator shows While the battery is on charge, the LEDs will how much charge the battery has. As you use pulsate and in turn illuminate. -
Page 19: Cleaning The Filter
Wash the filter if Recommended water temperature 40°C. Do necessary. not use detergent or soaps. (You can buy more at www.gtech.co.uk) Never put the bin back without the filter inside. You could damage the motor. 5011_System_UF_manual_aw.indd 19 5011_System_UF_manual_aw.indd 19... -
Page 20: Removing The Battery
Press the green buttons and pull to remove the battery. The battery can be charged on or off the main unit. If you want to buy a spare battery go to www.gtech.co.uk or call 01905 345891 5011_System_UF_manual_aw.indd 20 5011_System_UF_manual_aw.indd 20... - Page 21 FAQs and how-to-videos, as well as genuine spares and replacement parts compatible with your product. Visit: www.gtech.co.uk/support Online Live chat support support@gtech.co.uk How to Videos GTECH MULTI TECHNICAL SPECIFICATION Battery model 113A1003 Battery 22V Li-Ion Charging period 4 hours...
- Page 22 If your product is within its warranty and has a fault that cannot be resolved from the troubleshooting section or online support, please do the following: • Contact our Gtech Customer Care Helpline on UK: 08000 308 794, who will go through any troubleshooting with you to identify the fault.
- Page 23 Call your local council, via amenity site, or symbol indicates that this product is covered by legislation for waste electrical and electronic recycling centre for information on the disposal products (EN2002/96/EC) and recycling of electrical products. Alternatively visit www.recycle-more.co.uk for advice on recycling and to find your nearest recycling When the vacuum has reached the end of its life, it and the Li-Ion battery it contains should not be disposed...
- Page 24 Grey Technology Limited Brindley Road, Warndon, Worcester WR4 9FB, UK email: support@gtech.co.uk telephone: 01905 345891 www.gtech.co.uk 5011_System_UF_manual_aw.indd 24 5011_System_UF_manual_aw.indd 24 18/05/2021 16:46 18/05/2021 16:46...
