Summary of Contents for Fusion PowerPlant PP-AM120040
- Page 1 POWERPLANT AMPLIFIER MANUAL PP-AM300010 PP-AM200010 PP-AM120040 PP-AM60020 PP-AM100010...
-
Page 2: Table Of Contents
CONTENTS AMPLIFIER SPECIFICATIONS .......pg 4 • AMPLIFIER INSTALLATION ....... . .pg 5 •... -
Page 3: Amplifier Specifications
Failure to do so could result in permanent damage to the audio system. When wiring the FUSION amplifier ensure that the cable is protected from sharp objects and always use rubber grommets when wiring through metal panels. Ensure all terminals and connections are protected from the vehicle chassis and from each other as failure to do so could result in permanent damage to the audio system. -
Page 4: Four Channel Amplifier
2. Fuses Ensure fuses are replaced with the same type and rating. 3. Power FUSION amplifiers should be connected directly to the 12V battery terminal with an inline fuse or circuit breaker as close to the battery as possible. Ground When grounding/earthing your amplifier ensure that the location is a good source of ground (preferably the floor pan). -
Page 5: Two Channel Amplifier
2. Fuses Ensure fuses are replaced with the same type and rating. 3. Power FUSION amplifiers should be connected directly to the 12V battery terminal with an inline fuse or circuit breaker as close to the battery as possible. Ground When grounding/earthing your amplifier ensure that the location is a good source of ground (preferably the floor pan). -
Page 6: Monoblock Amplifiers
PP-AM300010 40A x 4 3. Power FUSION amplifiers should be connected directly to the 12V battery terminal with an inline fuse or circuit breaker as close to the battery as possible. Ground When grounding/earthing your amplifier ensure that the location is a good source of ground (preferably the floor pan). - Page 7 TROUBLESHOOTING PROBLEM POSSIBLE REASON SOLUTION Amplifier not • No +12V to power wire • Check fuses and connections to battery switching on. • No power to remote • Check Remote Turn ON connection(s) Power LED wire to head unit not ‘ON’ •...
- Page 8 NOTES PUBLISHED BY FUSION ELECTRONICS LIMITED: YOU CAN HELP PROTECT THE ENVIRONMENT! © Copyright 2008 by FUSION Electronics Limited. Please remember to respect the local regulations: All rights reserved. Specifications and design are Hand in the non-working electrical equipment subject to change without notice.
