- Page 1 Courtesy of DiscountCarStereo.com Serving the internet community since 1995 JAG97CD-HF QUICK START BLUETOOTH INSTALLATION GUIDE FOR SELECT 1986-97 JAGUAR WITH CD CHANGER Created May 15, 2016 Revised: March 14, 2021...
- Page 2 Safety comes first when you’re on the road, so having an intuitive and easy to use Bluetooth kit is essential to reducing driver distraction. The JAG97CD-HF kit is compatible with virtually all Bluetooth phones, and sounds great whether you are using it for mobile conversations or streaming music. In addition, the JAG97CD-HF works in select pre-1997 Jaguars with a functioning 6-disc CD changer in trunk/hatch.
- Page 3 8. Consider install locations for push-to talk button with built-in microphone. Keep in mind, button must be within driver reach (cable is 6ft. long). We recommend completing the rest of the install prior to securing button to dash. Once location has been decided simply remove tape backing (See Fig.
-
Page 4: Usb Charging Port
Insert 3.2ft. (1 Meter) USB male terminal (See Fig. 10) through ¾” hole created in step 1 and connect to Module USB port (See Fig. 11) Note: Find a clean power/ground supply behind the dash. If noise is present consider alternate location or purchase a noise filter. - Page 5 Fig. 13 Flush mounted to dash Fig. 15 Tuck and secure any extra wire from moving parts Snap USB head to bracket until flush (See Fig. 16) Note: Many have reported a flush install to the back wall of the storage compartment.
-
Page 6: Bluetooth Pairing And Connection
Bluetooth Pairing and Connection Bluetooth Operation This process is required the first time you use the JAG97CD-HF. After initial Turn ignition and radio “ON. pairing, the JAG97CD-HF will automatically reconnect with smartphone upon Press “CD” button on radio. (at least one DISC must be loaded into entering vehicle. -
Page 7: Feature Comparison
Enjoy! CD Changer Operation The JAG97CD-HF retains CD changer functionality. To play the CD’s, simply press “CD” button on radio (if not already in that mode), then press control button 4 times. To exit CD changer playback mode, press and release button. (Module returns to streaming audio) Use radio CD changer buttons to change tracks or disc as customary. -
Page 8: Frequent Asked Questions
Where does the JAG97CD-HF connect in my vehicle? After installing and testing the system everything works, but there is The JAG97CD-HF connects to the back of the radio and because of that, engine “whine”. What can I do to fix this? radio removal is required.
