Contents Page 3 1 Contents Contents ........................... 3 Important References ....................... 4 Basic safety instructions ..................... 4 Warranty and Liability ......................5 Explanation of Symbols and notes for the user ..............5 Right of origin (Copyright) ....................5 Special safety notes for the user ..................6 Product information ........................
All Wall of Flame Rotisseries are built for the preparation of food only. Any other use of the unit are only allowed after consulting UBERT GASTROTECHNIK GMBH. Damages which result out of wrong use UBERT GASTROTECHNIK GMBH cannot be held responsible. Part of the due use is also: the consideration of all references of the operating manual and •...
Important References Page 5 2.2 Warranty and Liability All products from the manufacturer are manufactured to the high nowadays technical standards and comply with all valid regulations. The manufacturer will grant a warranty to compensate all recog- nized valid claims. All other Warranty and Liability claims for people and appliances are excluded, especially if a possible damage is caused: •...
Page 6 Important References 2.5 Special safety notes for the user 2.5.1 Safety devices (Protection units) • Before setting the appliance into operation all safety devices and all removable parts have to be fitted and must operate in working order. •...
Page 7
Important References Page 7 2.5.8 Maintenance, Trouble Shooting • All prescribed adjustment-, maintenance- and service works must be carried out by an authorized service technician on a regular basis. • Before starting these maintenance- and service works the personnel must be clearly informed.
Page 8 Product information 3 Product information 3.1 Introduction The most important feature of the FF-series rotisseries is the high functionality with very attractive optical effects. That guarantees an optimum food processing and presentation, which is the basis for every selling success. 3.2 Special Features Enamelled execution •...
Page 9
Product information Page 9 3.3.4 Electrical Details, Power Consumption, Noise Emission Type el. connection [EA] power cons. noise emission all types 230V, 1/N, 50Hz 0.7 kW < 70 dB (A) 3.3.5 Nozzle table Model Kind of gas Number Size of Size of minimum Opening of Size of nozzle...
Page 10
Page 10 Product information Model Kind of gas Number Size of Size of minimum Opening of Size of nozzle main noz- nozzles [mmx100] primary air ignition burner main zles [mm] [mmx100] nozzles [mmx100] =number of burn- FF 42 LPG 50mbar 80 (screwed tightly) open 20 (screwed tightly)
Page 11
Product information Page 11 3.3.6 Indication of consumption Model Kind of gas Max. Min. Consumption Consumption Consumption Nominal Nominal flow of LPG on flow Natural flow Natural Heat Heat Load HuB=12,68 gas H on gas L on Load [kW] kwh/kg HuB=9,45 HuB=8,125 [kW]...
Page 12
Page 12 Product information Model Kind of gas Max. Min. Consumption Consumption Consumption Nominal Nominal flow of LPG on flow Natural flow Natural Heat Heat Load HuB=12,68 gas H on gas L on Load [kW] kwh/kg HuB=9,45 HuB=8,125 [kW] [kg/h] kwh/m³...
Page 13
Page 13 3.3.8 Name Plate The installation and operation manual is made for the Ubert Wall of Flame Rotisserie of the model series FF with the categories of natural gas and LPG mentioned under point 3.3.8. The units corre- spond to kind of construction "A".
Page 14 Initial Installation Procedure 4 Initial Installation Procedure Our Wall of Flame Rotisseries are packed for safe transport, so that they can reach their destination without any damages. However, we advise an examination of the Wall of Flame Rotisserie right after delivery. Attention! Do report visible damages immediately! 4.1 Unpacking •...
Initial Installation Procedure Page 15 4.2.3 Special advices regarding the gas exhaust Attention! The rotisserie has to be set up in sufficiently ventilated rooms and below an existing ventilation hood. The unit corresponds to kind of construction "A". The installa- tion to an exhaust gas device (ventilation hood) is necessary in order to lead out the exhaust gas immediately.
If no indication has been made, the units are principally adjusted for LPG. If the unit is to be re-adjusted it has to be observed that this is made by an approved technician or by the Ubert service technicians. The corresponding nozzles sizes are to be find in the nozzle table. For re-ad- justment the following measures have to be made: •...
Initial Installation Procedure Page 17 • Unscrew the pilot flame device. • Unscrew the nozzle after removal of the union and replace it according to the nozzle table. The assembling is to be made in reversed sequence. Afterwards the function has to be checked. 4.5.2 Replacement of main nozzle •...
Page 18 Operation 5 Operation 5.1 Operation elements Following you find explanations regarding all important position and function components for the operation of the unit: 1. Spit for taking up the grill products 2. Fat Drawer catches the meat juice and fat coming out of the grill product 3.
Operation Page 19 5.2 Operation / handling Please observe the following check list for starting the operation of the unit. Attention! The ignition process takes place principally from downwards to upwards. • For igniting you have to turn the knob one eighth (1/8) rotation to the left towards the ignition symbol.
Disregarding follows defect bearings and breakdown of the spit rotation! (Heat- resistant grease (part no. 412221) and grease guns (part no. 550408) are available at Ubert.) 6.1.4 Detergents To make the cleaning fast and easy we have integrated some cleaners in our pro- gram: •...
Maintenance Page 21 6.1.5 Daily Cleaning 1. Let the unit cool down. (down to ambience temperature). 2. Unplug the unit. 3. Close the main gas supply. 4. Remove the spits. 5. Catch the drain water. (Water remaining from the cleaning catch up in the fat drawers). 6.
Page 22 Maintenance 6.2.2 Working principles for devices made of "stainless steel" • The surface of the device made out of stainless steel has to be clean and accessible for air. If the device is not in use, please open the door, so the air is able to circulate. •...
Maintenance Page 23 6.3.2 Burner reaction Checking of the burner reaction has to be made by sight and function control. The flames have to burn stable and not yellow, not to lift up or flash back. 6.3.3 Heat Load and Test for leakages For this check the right nozzles and the correct connection pressure.
If your Rotisserie Wall of Flame does not work satisfactorily, we would like to give a first help with the following checklist. Only after checking these points you should contact: a) your responsible service partners b) directly the company: UBERT GASTROTECHNIK GmbH Werk II Gewerbegebiet Nord Vennekenweg 17 46348 Raesfeld Tel.:(49) 02865 / 602-226...
Maintenance Page 25 6.6.1 Trouble Shooting If you have problems with processing the grill products or generally with the operation of the unit, please check firstly the following points: Failure Possible reason Solution Uneven flames burner is narrowed Clean the burner supply of primary air does work Protect from draft correctly...
Page 26
Maintenance FF26 6.8.1 List of Spare Parts Description Part No. Amount FF24 scale light / motor 360203 scale gas valve 360215 Description Part No. Amount drive shaft 180596 scale light / motor 360203 burner 180590 scale gas valve 360215 cast iron fin 180577 drive shaft 180596...
Page 27
Maintenance FF28 FF34 Description Part No. Amount Description Part No. Amount scale light / motor 360203 scale light / motor 360203 scale gas valve 360215 scale gas valve 360215 drive shaft 180596 drive shaft 180543 burner 180590 burner left 180570 cast iron fin 180577 cast iron fin...
Page 28
Maintenance FF36 FF38 Description Part No. Amount Description Part No. Amount scale light / motor 360203 scale light / motor 360203 scale gas valve 360215 scale gas valve 360215 drive shaft 180543 drive shaft 180543 burner left 180570 burner left 180570 cast iron fin 180577...
Page 29
Maintenance FF44 FF46 Description Part No. Amount Description Part No. Amount scale light / motor 360203 scale light / motor 360203 scale gas valve 360215 scale gas valve 360215 drive shaft 180597 drive shaft 180597 burner left 180590 burner 180590 cast iron fin 180577 cast iron fin...
Page 30
Maintenance FF48 Description Part No. Amount scale light / motor 360203 scale gas valve 360215 drive shaft 180597 burner left 180590 cast iron fin 180577 Ball handle Ø30 301953 Ball handle Ø50 301955 spit support 306800 grommet 10x12x18 333105 lamp socket 340412 halogen-lamp 340620...
