  • Page 1 User Manual Multi Level Counters (hot)
  • Page 3: Table Of Contents

    Content 1 Content Content ............................. 3 Important notes ......................... 4 Fundamental safety instructions ..................4 Warranty and liability ......................5 Explanation of symbols and notes ..................5 Copyright ..........................5 Special safety instructions ....................6 Product information ........................8 Special features and advantages ..................8 Technical data ........................
  • Page 4: Important Notes

    2.1.4 Hazards when handling the device Ubert Multi Level counters are built according to the state of the art and recognized technical safety regulations. Nevertheless, hazards to the life and limb of the user or third parties or damage to the device or other material assets may occur if the device is not used properly and in accordance with the instructions.
  • Page 5: Warranty And Liability

    They will help you to make optimum use of all the functions on your device! 2.4 Copyright The copyright to these operating instructions remains with UBERT GASTROTECHNIK GMBH. These operating instructions are only intended for the operator and his personnel. It contains regulations and instructions which are neither completely nor partly: •...
  • Page 6: Special Safety Instructions

    Important notes 2.5 Special safety instructions 2.5.1 Protective devices • Before starting up the unit, all protective devices and all removable parts must be properly attached and in working order. • Protective devices may only be removed • after the unit has come to a standstill and has been secured against restarting. •...
  • Page 7 • Do not make any modifications, additions or conversions to the unit without the manu- facturer's approval. This also applies to welding on load-bearing parts. • All modification measures require a written confirmation of the company UBERT GASTROTECHNIK GMBH. • Immediately replace device parts that are not in perfect condition.
  • Page 8: Product Information

    3.1 Special features and advantages • uniform cold distribution • easy cleaning 3.2 Technical data 3.2.1 Dimensions (All dimensions in [mm]) DMLH 21 530 and DMLH 21 530SS: DMLH 21 700 and DMLH 21 700SS:  MultilevelUserManualDMLH.docx printed: 04/2022 Subject to change without notice!!
  • Page 9 Product information DMLH 21 870 and DMLH 21 870SS: DMLH 31 530 and DMLH 31 530SS:  MultilevelUserManualDMLH.docx printed: 04/2022 Subject to change without notice!!
  • Page 10 Product information DMLH 31 700 and DMLH 31 700SS: DMLH 31 870 and DMLH 31 870SS:  MultilevelUserManualDMLH.docx printed: 04/2022 Subject to change without notice!!
  • Page 11 Product information DMLH 41 530 and DMLH 41 530SS: DMLH 41 700 and DMLH 41 700SS: DMLH 41 870 and DMLH 41 870SS:  MultilevelUserManualDMLH.docx printed: 04/2022 Subject to change without notice!!
  • Page 12 Product information DMLH 51 530 and DMLH 51 530SS: DMLH 51 700 and DMLH 51 700SS: DMLH 51 870 and DMLH 51 870SS:  MultilevelUserManualDMLH.docx printed: 04/2022 Subject to change without notice!!
  • Page 13 Product information 3.2.2 Electrical values, power type electrical connection [EA] power DMLH21530 230V, 1/N, 50Hz 0,75kW DMLH21530SS 230V, 1/N, 50Hz 0,75kW DMLH21700 230V, 1/N, 50Hz 1,09kW DMLH21700SS 230V, 1/N, 50Hz 1,09kW DMLH21870 230V, 1/N, 50Hz 1,43kW DMLH21870SS 230V, 1/N, 50Hz 1,43kW DMLH31530 230V, 1/N, 50Hz...
  • Page 14: Installation And Commissioning

    When setting up the counter, please pay particular attention to the following instruc- tions: • Ubert Multi Level counters are to be aligned horizontally. Check this by means of a spirit level. • The lateral distance to other devices must be at least 10cm.
  • Page 15: Preparing For Operation

    Installation and commissioning 4.4 Preparing for operation Before operating your unit, wash the Ubert Multi Level counter with a grease-dissolving cleaning agent (e.g., with a mild soap solution). Then wipe all surfaces dry. Attention! Do not use any flammable liquids to clean the unit. Refrain from cleaning with water jets, steam jets or high-pressure cleaners! Detailed instructions are given in the chapter on cleaning and care.
  • Page 16: Operation

    Operation 5 Operation The position and function of all components important for operating the instrument are listed and ex- plained below. 5.1 Operating elements and control instruments Digital control 5.2 Operation ON/OFF key: Pressing the key switches the device on or off. LIGHTING key: Pressing the key switches the lighting on or off.
  • Page 17: Maintenance

    Maintenance 6 Maintenance In the following, you will find information on maintenance and care, possible troubleshooting as well as a service case for your Multi Level Counter. 6.1 Cleaning and maintenance • Before you start cleaning and maintenance work, the unit must be disconnected from the power supply (pull out the mains plug or switch off the automatic circuit breaker)! •...
  • Page 18: Recommendations For The Treatment Of "Stainless Steel" Catering Equipment

    Maintenance Make sure that no water can penetrate into the housing, as this can cause damage to the device, as well as harm to the operating personnel. Avoid contact between water and electrical components at all costs. Danger of short circuit! 6.1.4 Cleaning intervals: 6.1.4.1 Windows / storage surfaces:...
  • Page 19 Maintenance • ferrous particles (e.g. grinding dust) • Contact with non-ferrous metals (element formation) • Lack of oxygen (e.g. no air access, oxygen-poor water). 6.2.2 Working principles for "stainless steel" devices “ • Always keep the surface of stainless-steel equipment clean and accessible to air. Keep equip- ment door open when equipment is not in use to allow good air access.
  • Page 20: Troubleshooting

    Maintenance 6.3 Troubleshooting If your Ubert Multi Level counter should ever fail to operate satisfactorily, we would like to use the following checklist to provide initial assistance for an independent check. Only after checking these points, please contact: a) to the service center responsible for you or your specialist dealer or...
  • Page 21: Circuit Diagrams

    Maintenance 6.4 Circuit diagrams 6.4.1 DMLH all models  MultilevelUserManualDMLH.docx printed: 04/2022 Subject to change without notice!!
  • Page 22: Spare Parts

    Defective parts are to be replaced exclusively by original spare parts of the company UBERT GASTROTECHNIK GMBH; the exchange is permitted only by their service personnel or by the service personnel of the service station responsible for you. In case...
  • Page 23 Maintenance 6.5.2 Exploded view  MultilevelUserManualDMLH.docx printed: 04/2022 Subject to change without notice!!
  • Page 24: Ce- Declaration Of Conformity

    Maintenance 6.6 CE- Declaration of Conformity  MultilevelUserManualDMLH.docx printed: 04/2022 Subject to change without notice!!
