Summary of Contents for Ubert RoFry RF-300-CC
- Page 1 User Manual ® RoFry RF-300/330/360-CC...
-
Page 3: Table Of Contents
Contents 1 Contents Contents ........................... 3 Important References ....................... 4 Fundamental Safety Notes ....................4 Warranty and Liabilities ...................... 5 Symbols and Notes ......................5 Copyright ..........................5 Special Safety References ....................6 Introduction ..........................8 Introduction ......................... 8 Special features ........................8 Technical details ......................... -
Page 4: Important References
Important References 2 Important References 2.1 Fundamental Safety Notes 2.1.1 WARNING: Do not open the side cover of this unit! “WARNING To reduce the risk of electric shock, do not remove or open cover. No user serviceable parts inside. Refer servicing to qualified personnel.” 2.1.2 Consider notes in the operating manual Precondition for the safe and trouble free use of this unit is the knowledge of the fundamental safety notes and safety regulations. -
Page 5: Warranty And Liabilities
Help for optimum use of all functions of the unit ! 2.4 Copyright The copyright on this operating manual remains at the company UBERT GASTROTECHNIK GMBH. This operating manual is intended only for the operator and his personnel. It contains instructions and references which neither completely nor partially: •... -
Page 6: Special Safety References
Important References 2.5 Special Safety References 2.5.1 Safety devices • Before operating the unit all protective devices like door and exhaust-cover as well as all removable parts must be installed correctly and be fully workable. • Protective devices may only be removed: •... - Page 7 Do not perform any changes, extensions or conversions to the unit without the manu- facturer’s permission, especially welding work at supporting parts. • For all conversions a written permission of the company UBERT GASTROTECHNIK GMBH is necessary. • Change all parts of the unit, which are in improper condition.
-
Page 8: Introduction
Introduction 3 Introduction 3.1 Introduction ® RoFry offers due to its unique technology the possibility to fry regular products completely without oil. The quality of the products fried without oil will always be the same high standard, no matter if you take deep frozen or fresh goods, French fries or chicken nuggets, Asian specialties or fast food products from USA. - Page 9 Introduction 3.3.3 Weight Type Net weight: RF-300/330/360-CC: 88,5 kg 3.3.4 Electrical details Type Version Load per Ph: RF-300/330/360-CC: Europe-Version 400V / 15,5kW / 50-60Hz / 3Ph with N 25 A 3.3.5 Noise emission Type noise emission all types < 70 dBA ...
-
Page 10: Installation And Putting Into Operation
Installation and putting into operation 4 Installation and putting into operation ® In general all RoFry units will be packed for safe transport after the final control in or- der to reach you properly. Nevertheless we ask you to have a look at the machine on arrival to detect any transport damages. -
Page 11: Tap
The following regulations have to be observed: DIN EN 1717 (alt DIN 1988, Part4, technical regulations for drinking water installation/TRW. • The appliance needs an open sewage-connection, preferably ending in a funnel. UBERT recom- mends a common flexible sewage-hose with ¾ “diameter to be fixed to the sewage connection coming with the machine. -
Page 12: Operation
Operation 5 Operation ® 5.1 How RoFry works Once the device has been turned on, RoFry initializes. After pushing the STANDBY key is pushed, RoFry enters the cold standby level. After confirming a program selection with the START key, RoFry enters the hot standby level and is preheating to set temperature. This takes app. 2 minutes. To fry food products, pull out the basket, put in the food to be prepared, push in the basket and push the START key. -
Page 13: Description Of Operating Elements
Operation 5.2 Description of operating elements Following you will find the description of all operating elements. Controller Basket Handle Door Lock Main Switch Computer control (Controller): The controller is used to control the complete cooking process automatically, including cooking time period, cooking tempera- ture and cooking end time.: Main Switch: to switch RoFry ON and OFF... -
Page 14: Explanation Of The Computer Control (Overview)
Operation 5.3 Explanation of the computer control (overview) The computer control offers 6 keys on the home menu that represent the main sections: In the coocing section, you can: - select from and run various predefined cooking programs In the cleaning section, you can: - select from and run various predefined cleaning programs such as Clean 1: a short rinse with clear water- Clean 2-6: a combination of up to 5 washing cycles plus a rinsing cycle-... - Page 15 Operation 5.3.1 Cooking section To operate the RoFry via the computer control, press the ON/OFF switch. The controller will start, showing the manufacturer logo and will boot into the home screen. Once the controller is ready, press the cooking sction key. Use the UP- and DOWN-key to scroll through the list of programs.
- Page 16 Operation 5.3.3.3 Copy: Select the source program that you want to copy from the list. Select the position in the list, to which you want to copy the program to. 5.3.3.4 Move: Select the source program that you want to move in the list. Select the position in the list, to which you want to move the program to.
-
Page 17: Maintenance
Maintenance 6 Maintenance ® Following some advises concerning maintenance, care, trouble shooting and service for RoFry 6.1 Cleaning and Care 6.1.1 Safety advices • Do not use inflammable detergents cleaners. Never use high-pressure-, water pressure- or steam jet- cleaning devices. •... -
Page 18: Weekly Cleaning
Maintenance Unlock and open the door / Remove basket-holder, lamella-sheet, strainer Remove crumbs from gaskets and bottom of chamber, empty strainer Insert strainer + lamella sheet, insert basket-holder Close and lock the door Insert basket completely Program runs until signal sounds Remove basket completely Unlock and open the door / Remove basket-holder, lamella-sheet, strainer Empty strainer / wipe gaskets thoroughly... -
Page 19: Trouble-Shooting
Only after checking these points you should contact: a) Your responsible service partner b) Directly the company: UBERT GASTROTECHNIK GmbH Zum Osterkamp 19 46348 Raesfeld GERMANY Tel.: +49 (2865) 602-0... -
Page 20: Wiring Diagram
Maintenance 6.5 Wiring Diagram 6.5.1 RF-300/330/360-CC 400V / 50-60Hz / 3Ph with N RoFryUserManual.docx printed: 07/2023 Subject to change! -
Page 21: Replacement Of Gaskets
Maintenance 6.6 Replacement of gaskets: 1. Select a cleaning program 2-6, while in cleaning mode. The unit cools down below 50°C; ® remove the basket and then open the door. Switch off the RoFry at the main switch. 2. Remove the old gasket by pulling it out and clean the notch of the seal;... - Page 22 Maintenance 5. Finally check proper placement of the seal in the notch! 6. Insert lamella sheet and basketholder again. Close the door. Remove the old basket gasket by pulling it out. 7. Clean the notch of the seal; remove grease and other residues. ...
- Page 23 Maintenance 8. Put in the new seal. Place the splice of the seal in the middle of the upper notch. 9. Push the seal into the notch. Make sure neither to stretch nor to forge the seal. 10. Finally check proper placement of the seal in the notch! ...
-
Page 24: Spare Part List
Maintenance 6.7 Spare part list Bezeichnung Name 117051 Deckel Zu- und Abluftkanal Flap for air intake and exhaust channel 117129 Reduzierscheibe Assembly plate 117210 RoFry Stellfuß Leg assy RoFry 117241 Gegenflansch für Heizkörper RoFry counter flance for heating ele- ment 117311 Türscharnier oben RoFry Doorhinge top... - Page 25 Maintenance 333307 Wago Brücken Bridge for terminal block 333308 Wago Abschottung Separator for terminal block 335092 Sicherungsklemme Fuse holder 5x20 335095 Feinsicherung 5x20 - 0.5 A träge fuse 5x20 - 0.5 A träge 340814 Drehgeber UUS1-2 Encoder for UUS01 340819 Summer, Miniartur 5-12V Buzzer 5-12V 340841...
- Page 26 Maintenance 359121 Gleitschienen Korbführung PTFE/Glas Sliding rails (basket) PTFE/Glass 359123 Dichtung für ROFRY Heizkörperflansch gasket RoFry heating element flange 359125 Korbdichtung als Ring verklebt 920mm lang gasket (basket) L = 920 mm 359126 Carbondichtung Carbon seal for main fan 359128 Wellendichtung BA-PTFE 20*35*7 Shaft seal PTFE 359131...
-
Page 27: Exploded Views
Maintenance 6.8 Exploded views RoFryUserManual.docx printed: 07/2023 Subject to change! - Page 28 Maintenance RoFryUserManual.docx printed: 07/2023 Subject to change!
- Page 29 Maintenance RF-300 RF-330 RF-360 117397 117433 117433 Rückwand RF-300 Rückwand RF-360 / RF- Rückwand RF-360 / RF- Rear cover RF-300 Rear cover RF-360 / RF- Rear cover RF-360 / RF- 117432 117443 Seitenblende RF-330 Seitenblende RF-360 Side cover RF-330 Side cover RF-330 2 x 117396 Seitenblende RF-300 Side cover RF-300...
-
Page 30: Accessories
Maintenance 6.9 Accessories The following accessories are available on request: • Spare basket holder, complete Part. No.: RF 5003 • Spare basket, complete Part. No.: RF 5004 • RoFry ® -cleaner Part. No.: RF 8200 25kg-Container • RoFry ® -lime remover Part. -
Page 31: Declaration Of Conformity
Maintenance 6.10 Declaration of Conformity RoFryUserManual.docx printed: 07/2023 Subject to change!
