Ubert KT 700 User Manual

Kt series cold display cabinet
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
COLD DISPLAY CABINET
KT-Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KT 700 and is the answer not in the manual?

Questions and answers

Related Manuals for Ubert KT 700

Summary of Contents for Ubert KT 700

  • Page 1 User Manual COLD DISPLAY CABINET KT-Series...

  • Page 3: Table Of Contents

    Contents 1 Contents Contents ........................... 3 Important References........................ 4 Fundamental Safety Notes ....................4 Warranty and Liabilities ...................... 5 Symbols and Notes ......................5 Copyright ..........................5 Special safety references ....................6 Introduction ..........................8 Introduction ......................... 8 Special features ........................8 Technical details .........................

  • Page 4: Important References

    The Cold Display Cabinets are built exclusively for the cooling of food only. Any other use of the unit are only allowed after consulting UBERT GASTROTECHNIK GMBH. Damages which result out of wrong use UBERT GASTROTECHNIK GMBH cannot be held responsible. Part of the due use is also: ...

  • Page 5: Warranty And Liabilities

    Help to use all functions at your unit optimally 2.4 Copyright The copyright on this operating manual remains at the company UBERT GASTROTECHNIK GMBH This operating manual is intended only for the operator and his personal. It contains instructions and references wich neither completely nor partially: ...

  • Page 6: Special Safety References

    Important References 2.5 Special safety references 2.5.1 Safety devices  Before operating the unit all protective devices as well as all removable parts must be installed correctly and be fully workable.  Protective devices may only be removed:  after stand still and ...
  • Page 7 Do not perform any changes, extensions or conversions to the unit without the manu- facturers permission, especially welding work at supporting parts.  For all conversions a written permission of the company UBERT GASTROTECHNIK GMBH is necessary.  Change all parts of the unit, that are in impropper condition.

  • Page 8: Introduction

    Introduction 3 Introduction 3.1 Introduction All Cold Display Cabinets are synonymous in construction and therefore you will have the possibility of an optimum integration in a com- plete display conception. An adjustable tem- perature control enables you to set the desired cooling temperature.

  • Page 9: Technical Details

    Introduction 3.3 Technical details 3.3.1 Dimensions [mm] KT 700 / KT 700 DB: printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...
  • Page 10 Introduction KT 1100 / KT 1100 DB: printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...
  • Page 11 Introduction KT 1400 / KT 1400 DB: printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...
  • Page 12 Introduction 3.3.2 Weight Type weight [kg] KT 700 KT 1100 KT 1400 KT 700 DB KT 1100 DB KT 1400 DB 3.3.3 Electrical details Type electrical connection (EA) power KT 700 230V, 1/N, 50Hz 0.31 kW KT 1100 230V, 1/N, 50Hz 0.42 kW...

  • Page 13: Installation And Putting Into Operation

    4.3 Electrical connection Note! In general, only service technicians of the company: UBERT GASTRO- TECHNIK GMBH or service technicians of your responsible service partner are al- lowed to perform el. connection and other service! All national and lokal rules and regulations concerning electricity, fireprotection and the like have to be concidered.

  • Page 14: Preparation Of Using / Starting Up

    Installation and putting into operation 4.4 Preparation of Using / Starting up Note! To ensure compensation of refrigerant, keep the unit switched off at least two hours after installation. After transporting (moving) the unit in an upright position wait at least 30 minutes before restart.. Before operating the Cold Display Cabinet you have to clean the unit and all removable parts (e.

  • Page 15: Operation

    Operation 5 Operation Following you will find explanation and location of all components and their function for the use of the cabinet. 5.1 Operation elements Control panel The control panel with switches for illumination and fan as well as temperature control is located un- derneath the stainless steel cover.

  • Page 16: Operation

    Operation Switch - lighting: The lighting of the unit supports efficient illumination of the unit and ensures product presentation at its best. The lights are activated when the light in the switch is illuminated. Temperature control: With the temperature control switch you can choose the desired cool- ingpower.

  • Page 17: Maintenance

    Maintenance 6 Maintenance Following we will show you some advices concerning maintenance, care, trouble shooting and ser- vice for your Cold Display Cabinet. 6.1 Cleaning and care 6.1.1 Safety advices  Before you start to clean and care switch off the appliance and disconnect it from the mains.
  • Page 18 Maintenance 6.1.4 Special cleaning hints Please find below some special cleaning tips for this specific unit: Lamps:  To be cleaned only with soft paper or cloth and alcohol. Glass:  Lift the cuved front glass to clean the inside. Remove dust and dirt from the glass surface with soft cloth to avoid scratches.

  • Page 19: Trouble Shooting

    If your Cold Display Cabinet does not work satisfactorily we would like to give a first help with the following checklist. Only after checking these points you should contact: a) your responsible service partner b) directly the company: UBERT GASTROTECHNIK GmbH Werk II Gewerbegebiet Nord Vennekenweg 17 46348 Raesfeld Tel.:(49) 02865 / 602-226...

  • Page 20: Wiring Diagrams

    Maintenance 6.3 Wiring Diagrams 6.3.1 KT 700 230V / 50Hz / 1/N 6.3.2 KT 700 DB 230V / 50Hz / 1/N printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...
  • Page 21 Maintenance 6.3.3 KT 1100 230V / 50Hz / 1/N 6.3.4 KT 1100 DB 230V / 50Hz / 1/N printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...
  • Page 22 Maintenance 6.3.5 KT 1400 230V / 50Hz / 1/N 6.3.6 KT 1400 DB 230V / 50Hz / 1/N printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...
  • Page 23 Maintenance 6.3.7 KT 700-2 (UL) 120V / 50Hz / 1/N 6.3.8 KT 700-2 DB (UL) 120V / 50Hz / 1/N printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...
  • Page 24 Maintenance 6.3.9 KT 1100-2 (UL) 120V / 50Hz / 1/N 6.3.10 KT 1100-2 DB (UL) 120V / 50Hz / 1/N printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...
  • Page 25 Maintenance 6.3.11 KT 1400-2 (UL) 120V / 50Hz / 1/N 6.3.12 KT 1400-2 DB (UL) 120V / 50Hz / 1/N printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...

  • Page 26: Spare Parts

    Maintenance 6.4 Spare Parts Defect parts are to be replaced only by original spare parts of UBERT GASTROTECHNIK GMBH; the replacement is to be carried out only by their service personal or by your authorized Service companies. If you do not observe this note or...
  • Page 27 KT 700 / KT 700 DB 346104 cooling unit KT 700-2 / KT 700-2DB 346115 thermometer -40°C to +40°C KT 700 / KT 700 DB 342908 thermometer -40°F to +100°F KT 700-2 / KT 700-2DB 342911 tumber switch 341108 thermostat -3°C to +12,5°C...
  • Page 28 Maintenance 6.4.3 Spare Parts List KT1100 / KT1100DB Pos. Description Part No. Amount front glass 121061 glass holder for side glass, above 121042 lamp socket 340103 ornamental glass 420110 cover for evaporator 150017 evaporator 346107 side glass 420306 glass support 361113 door stopper, teflon 361503...
  • Page 29 Maintenance 6.4.4 Spare Parts List KT1400 / KT1400DB Pos. Description Part No. Amount front glass 121062 glass holder for side glass, above 121042 lamp socket 340103 ornamental glass 420111 cover for evaporator 150027 evaporator 346108 side glass 420306 glass support 361113 door stopper, teflon 361503...

  • Page 30: Declaratoin Of Conformity

    Maintenance 6.5 Declaratoin Of Conformity printed: 02/2015 Subject to change!  TopLineUserManualKT.docx...

This manual is also suitable for:

Kt 1100Kt 700 dbKt 1400Kt 1100 dbKt 700-2Kt 1400 db ... Show all
