WISE Paragon d
Instructions for Use
Content
Symbol key ................................................................. 1
Application area .................................................. 2
General .................................................................... 2
Contents ................................................................... 2
Protective equipment ................................................ 2
Electrical safety ......................................................... 2
Handling ................................................................... 2
Installation ................................................................ 2
Dimensions and weight...................................... 3
Installation .......................................................... 4
Water connection ....................................................... 7
Connecting water ....................................................... 7
Air connection ............................................................ 9
Commissioning .................................................. 11
Air distribution ...........................................................11
Connections ....................................................... 12
LED - Explanation .................................................... 12
Use ......................................................................... 14
Trouble shooting ..................................................... 14
Cleaning ................................................................. 14
Service/maintenance ............................................... 14
Materials and surface treatment .............................. 14
Disposal .................................................................. 14
Product warranty .................................................... 14
Technical data ......................................................... 15
Electrical data ......................................................... 15
Declaration of Conformity ............................... 16
References .............................................................. 16
Maintenance ...................................................... 17
The document was originally written in Swedish
Symbol key
Symbols on the machine
This product complies with applicable
EU directives
Symbols in this user manual
Warning/Caution!
22/11/2021
Art. 942428073
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swegon WISE Paragon d
Summary of Contents for Swegon WISE Paragon d
-
Page 1: Table Of Contents
WISE Paragon d Instructions for Use 22/11/2021 Art. 942428073 Content Symbol key Symbols on the machine Symbol key ..............1 This product complies with applicable Application area ..........2 EU directives General ..............2 Contents ..............2 Protective equipment ..........2 Electrical safety ............ -
Page 2: Application Area
The product must be handled with care. indoors within Swegon’s ventilation system WISE. The product is used to ventilate, cool and heat premises Installation exactly as needed. -
Page 3: Dimensions And Weight
2.46 1400 R 23.0 27.6 2.47 0.65 1400 L 23.0 27.6 2.46 0.64 1400 R 23.0 27.6 2.47 1400 R 23.0 27.6 2.46 * Weights above are excl.: Control equipment: 0,74 kg 22/11/2021 Swegon reserves the right to alter specifications. -
Page 4: Installation
8 0 5 / > 2 5 0 5 / 1 3 8 5 ± 7 8 5 / 1 0 8 23,5 569 (+ 0-20) 92,5 92,5 23,5 569 (+ 0-20) 92,5 92,5 Swegon reserves the right to alter specifications. 22/11/2021... - Page 5 222,5 146,6 23,5 778,2 222,5 1100 1078,2 222,5 1400 1378,2 222,5 > 2 5 > 1 4 2 2 3 / / 1 1 > 2 8 2 3 > 2 5 22/11/2021 Swegon reserves the right to alter specifications.
- Page 6 WISE Paragon Swegon reserves the right to alter specifications. 22/11/2021...
-
Page 7: Water Connection
A1 = Cooling water, supply A2 = Cooling water, return A2 = Cooling water, return B1 = Heating water, supply B1 = Heating water, supply B2 = Heating water, return B2 = Heating water, return 22/11/2021 Swegon reserves the right to alter specifications. - Page 8 Water connection - CCO-valve. A1 = Cooling water, supply A2 = Cooling water, return B1 = Heating water, supply B2 = Heating water, return C = CCO valve D = Flexible hose Swegon reserves the right to alter specifications. 22/11/2021...
-
Page 9: Air Connection
WISE Paragon, view from the back WISE Paragon suite, view from the back Connection dimensions air Variant Length Air connetion (mm) 1 x Ø 125 2 x Ø 125 1: Standard 800, 1100, 1400 2: Suite 1400 22/11/2021 Swegon reserves the right to alter specifications. - Page 10 WISE Paragon Supply and extract air Supply air kit Extract air kit Swegon reserves the right to alter specifications. 22/11/2021...
-
Page 11: Commissioning
ADC. Air distribution Vertical air distribution with adjustable slats in the supply air grille. Horizontal air distribution with ADC 22/11/2021 Swegon reserves the right to alter specifications. -
Page 12: Connections
White Permanent Selected in TuneWISE White Flashing, fast There are different types of actuators • For connection of the thermal actuator such as Swegon’s Prepared to be added to White Flashing, slowly actuator ACTUATORc, see figure a the system To be added to the system White Flashing, fast for 5 s •... - Page 13 WISE Paragon Mounting grills C l i c C li c k ! 22/11/2021 Swegon reserves the right to alter specifications.
-
Page 14: Use
(1) The product is repaired, modified or changed, unless such repair, modification or change has been approved by Swegon AB; or (2) the serial number on the product has been made illegible or is missing. -
Page 15: Technical Data
Actuator for cooling and heating as well as WISE SMA, gives a total power consumption of 4.3 + 6 + 0.8 = 11.1 VA *Valid for products with CU ver. 2, delivered from 01/10/2019 22/11/2021 Swegon reserves the right to alter specifications. -
Page 16: Declaration Of Conformity
Date: Arvika 21/10/2021 This declaration is applicable only if the product has been installed according to the instructions in this document and if no modifications or changes have been made on this product. Swegon reserves the right to alter specifications. 22/11/2021... -
Page 17: Maintenance
WISE Paragon Maintenance 22/11/2021 Swegon reserves the right to alter specifications. - Page 18 WISE Paragon C l i c C li c k ! Swegon reserves the right to alter specifications. 22/11/2021...
