WISE Parasol EXa
Instructions for Use
Content
Symbol key ................................................................. 1
Application area .................................................. 2
General .................................................................... 2
Contents ................................................................... 2
Protective equipment ................................................ 2
Electrical safety ......................................................... 2
Handling ................................................................... 2
Installation ................................................................ 2
Dimensions and weights .................................... 3
Dimensions ............................................................... 3
Weight ..................................................................... 3
Installation, base module ................................... 4
Suspension ................................................................. 4
A: Suspended installation .......................................... 4
B: Surface mounted installation ................................. 4
Water ......................................................................... 6
Air .............................................................................. 7
Commissioning .................................................... 8
Nozzle setting ........................................................... 8
ADC ......................................................................... 8
Connections ......................................................... 9
components ............................................................. 9
Factory fitted components as an option .................... 9
LED - Explanation ...................................................... 9
Use ......................................................................... 10
Trouble shooting ..................................................... 10
Cleaning ................................................................. 10
Service/maintenance ............................................... 10
Materials and surface treatment .............................. 10
Disposal .................................................................. 10
Product warranty .................................................... 10
Technical data ..........................................................11
Electrical data ..........................................................11
The document was originally written in Swedish.
Declaration of Conformity ............................... 11
References ...............................................................11
Installation, design module ............................. 12
Maintenance ...................................................... 15
Symbol key
Symbols on the machine
This product complies with applicable EU direc-
tives
Symbols in this user manual
Warning/Caution!
23/06/2020
Article 942428036
Advertisement
Table of Contents
Related Manuals for Swegon WISE Parasol EX
Summary of Contents for Swegon WISE Parasol EX
-
Page 1: Table Of Contents
Warning/Caution! Commissioning ............ 8 Nozzle setting ............8 ADC ................. 8 Connections ............9 WISE Parasol EX with factory-fitted components ............. 9 Factory fitted components as an option ....9 LED - Explanation ............9 Use ................. 10 Trouble shooting ............. 10 Cleaning .............. -
Page 2: Application Area
The product must be handled with care. ors within Swegon’s ventilation system WISE. The product is Installation used to ventilate, cool and heat premises exactly as needed. -
Page 3: Dimensions And Weights
* When WISE SMB sensor module is installed in the face plate the height measure- Dimensions base module ment (H) increases by 12 mm (The example shows the base module WISE Parasol EX 1290) Dimensions, WISE Parasol EX 1290 Dimensions base module (mm) Dimensions complete (mm) (Ø125) -
Page 4: Installation, Base Module
WISE Parasol EX Installation, base module Suspension A: Suspended installation B: Surface mounted installation A1, B1 Swegon reserves the right to alter specifications. 20200901... - Page 5 WISE Parasol EX A3, B3 Ø125 Ø160 MF/HF 20200901 Swegon reserves the right to alter specifications.
-
Page 6: Water
Connection sizes Model Supplied / Connected Connection Coupling type Connection Coupling type WISE Parasol EX A only Cooling Actuators and valves Return DN15, male thread Supply pipe Plain pipe 12 x 1.0 mm WISE Parasol EX B Cooling/Heating Actuators and valves... -
Page 7: Air
WISE Parasol EX Base module with mounted valve kit (The example shows the base model for WISE Parasol EX 1290) Connection dimensions Unit Ø = WISE Parasol EX 690 HF Ø 125 WISE Parasol EX 690 PF Ø 160 WISE Parasol EX 1290 HF Ø... -
Page 8: Commissioning
Commissioning WISE Parasol EX is a part of the WISE system that demand-controls both air and water on a room level and guarantees the highest level of indoor climate with minimum energy consumption. This means that when the installation and inter- connection of the system is completed, no further trimming is required except for the nozzle setting and any adjust- ment of ADC. -
Page 9: Connections
WISE Parasol EX, connection. To be added to the system White Flashing, fast for 5 s There are different types of actuator. Paired • For connection of the thermal actuator such as Swegon’s Colour Type actuator ACTUATORb, see figure a. Normal operation Green Permanent •... -
Page 10: Use
(1) The product is repaired, modified or changed, unless such repair, modification or change has been approved by Swegon AB; or (2) the serial number on the product has been made illegible or is missing. -
Page 11: Technical Data
50 mW Swegon AB hereby affirms that Frequency band: 2.45 GHz, IMS band WISE Parasol EX with integrated radio, complies with the essen- (2400--2483 MHz) tial characteristic demands and relevant regulations specified in Temperature sensor: 0 - 50°C ± -0.5°C... -
Page 12: Installation, Design Module
WISE Parasol EX Installation, design module A7, B6 A8, B7 TORX T-25 / 1 x 8 A9, B8 Click! A10, B9 Swegon reserves the right to alter specifications. 20200901... - Page 13 WISE Parasol EX A11, B10 Click! A12, B11 A14, B13 20200901 Swegon reserves the right to alter specifications.
- Page 14 WISE Parasol EX A15, B14 A16, B15 Swegon reserves the right to alter specifications. 20200901...
-
Page 15: Maintenance
WISE Parasol EX Maintenance Opens side A or B Click! Click! 20200901 Swegon reserves the right to alter specifications. - Page 16 WISE Parasol EX Swegon reserves the right to alter specifications. 20200901...
