- Page 1 ASSEMBLY INSTRUCTIONS Description : MISSION MAGAZINE TABLE Item No. : 9836 ITEM NO.: 9836 Printed in Vietnam REVISED AUG 21 , 2014 - 1 -...
- Page 2 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Bolt Allen Key (M6x35mm) (4x80mm) Lock washer Flat washer (6.5x11mm) (6.5x16mm) ITEM NO.: 9836 Printed in Vietnam REVISED AUG 21 , 2014 - 2 -...
- Page 3 Attach the side frame (B) to the top panel (A) with bolts (1) and washers (2 ) and (4), as shown below. Tighten with Allen key (3 ). STEP 2 Carefully attach front and back frames (C) between side frames (B) as shown below. ITEM NO.: 9836 Printed in Vietnam REVISED AUG 21 , 2014 - 3 -...
- Page 4 Allen key (3). Attach the other side frame (B) to the unit with bolts (1) and washers (2) and (4) as shown below. Tighten with Allen key (3). ITEM NO.: 9836 Printed in Vietnam REVISED AUG 21 , 2014...
