Brief Introduction
Apera Instruments 201T-F pH/Temp. Electrode is featured with a proprietary lithium glass membrane for
fast and stable readings and a built-in temperature sensor for automatic temperature compensation. The
gel inner reference solution does not need to be refilled. This electrode is designed for testing in general
water solutions. The electrode may not work well in the following situations:
1.
Long-term testing in high temperature solutions (>122°F or 50°C)
2.
Frequent testing in strong alkaline (>12 pH) or acid (<2 pH) solutions
3.
Testing low ionic strength solutions like distilled or deionized water
4.
Testing caustic solutions that will corrode the polycarbonate housing of the electrode
Technical Specifications
Range
Housing
Junction
Reference electrode
Reference solution
Connector
Cable length
Dimension
Temperature sensor
Operating
temperature
How to Install the Electrode
1.
Find the BNC socket (where it shows pH ORP) on the pH meter; Open the rubber cap; Insert the
blue BNC connector of the electrode to the BNC socket while twisting clockwise until it's locked.
2.
Find the RCA socket (where it shows temp.) on the pH meter; Open the rubber cap; Insert the black
RCA connector of the electrode to the RCA socket directly.
3.
After installing the new electrode to your meter, a 3-point calibration must be performed to ensure
the accuracy.
How to Use the Electrode
1.
There is a proper amount of storage solution in the cap on top of the electrode. The pH glass
sensor tip is soaked in it to keep its sensitivity.
2.
Before measuring, loosen the bottle cap, then pull out the electrode while twisting
counterclockwise. Place the storage bottle at a safe position.
3.
Rinse the electrode with purified water and shake off excess water or blot-dry it with clean tissue
or filter paper. Never rub the glass membrane.
201T-F pH/Temp. Electrode
User Manual
0 to 14 pH; 32 to 176°F (0 - 80°C)
Polycarbonate
Single fiber ceramic
Ag/AgCl
Gel KCL
BNC/RCA
3 Ft
ø12*160 mm
30KΩ thermistor
32 to 176°F (0 - 80°C)
Advertisement
Table of Contents
Related Manuals for Apera 201DJ-C
Summary of Contents for Apera 201DJ-C
- Page 1 User Manual Brief Introduction Apera Instruments 201T-F pH/Temp. Electrode is featured with a proprietary lithium glass membrane for fast and stable readings and a built-in temperature sensor for automatic temperature compensation. The gel inner reference solution does not need to be refilled. This electrode is designed for testing in general water solutions.
- Page 2 1-2 years. If you feel like the response of your pH electrode is much slower, or the slope is lower than 90% (most Apera portable/benchtop pH meters will show the slope data between every two points of calibration), it’s time to replace with a new electrode to ensure accuracy.
